Zanussi 200226 Specifications

Zanussi electric hobs product brochure.
Hide thumbs


Advertisement

RANGE
COMPOSITION
N 900: a range of over 150 models
for the professional caterer designed
to guarantee the highest level of
performance, reliability, energy
saving, safety standards and
ergonomic operation. These
concepts are reflected in the total
modularity of the range that ensures
innumerable configurations, either
free-standing, bridged or cantilever.
N900 demonstrates how advanced
technology can satisfy the needs of
the professional caterer.
The model detailed on this sheet is a
top electric versions ideal for uniform
cooking using pots and pans, even
large size ones.
FUNCTIONAL AND
CONSTRUCTION
FEATURES
Worktop in 20/10 stainless steel.
Front and side panels in stainless
steel with Scotch-Brite finish.
This model has right-angled side
edges to allow flush fitting joins
between units, eliminating gaps and
possible dirt traps.
2 indipendently controlled cooking
zones.
Cooking hob in smooth-surfaced
carbon steel, guaranteeing
temperature uniformity for low
temperature cooking, enabling either
uniform temperature across the
whole hob, 2 different temperature
zones on the same hob or heating of
only one section of the hob.
Removable hob plate.
The special design of the control
knob system guarantees against
water infiltration.
Main connections can be via the
base or the rear of the unit.
This model can be easily mounted
on the refrigerated base, open base
cupboards, bridging supports or
cantilever systems.
IPX5 water protection.
TECHNICAL DATA
CHARACTERISTICS
Power supply
External dimensions - mm
width
depth
height
Cooking surface
type
material
Thermostatic
Cooking surface dimensions - mm
width
depth
Working temperature - min/max - °C
Electrical power - kW
Net weight - kg.
Supply voltage
ELECTRIC HOBS
200226
N 900
ZANUSSI
P R O F E S S I O N A L
MODELS
NTRE400
200226
Electric
400
900
250
Smooth
Mild Steel
l
360
715
80, 450
7
60
400 V, 3N, 50/60

Advertisement

   Related Manuals for Zanussi 200226

   Summary of Contents for Zanussi 200226

  • Page 1

    Cooking surface dimensions - mm width depth Working temperature - min/max - °C Electrical power - kW Net weight - kg. Supply voltage 200226 N 900 ZANUSSI P R O F E S S I O N A L MODELS NTRE400 200226...

  • Page 2

    SIDE HANDRAIL-RIGHT/LEFT HAND WATER COLUMN EXTENSION FOR 900 LINE WATER COLUMN WITH SWIVEL ARM BACH2 2009-06-19 The Company reserves the right to alter technical specifications without prior notice. NTRE400 200226 400 V, 3N, 50/60 MODELS NTRE400 200226 206278 206303 206126...

This manual also for:

Ntre400, N 900
