Zanussi Electrolux TCE 7124 W Instruction Booklet

Zanussi owners manual compact dryer tce 7124 w.
Hide thumbs
TCE 7124 W
Unpacking: see page 14

   Related Manuals for Zanussi Electrolux TCE 7124 W

   Summary of Contents for Zanussi Electrolux TCE 7124 W

  • Page 1: Tumble Dryer

    TUMBLE DRYER TCE 7124 W CON NSER DRYER Unpacking: see page 14 INSTRUCTION BOOKLET 125992080...

  • Page 2: Important Safety Information, Installation, Child Safety

    Do not allow fluff to accumulate around the dryer. • Under no circumstances should you attempt to repair the machine yourself. Repairs carried out by inexperienced persons may cause injury or serious malfunctioning. Contact your local Service Force Centre. Always insist on genuine Zanussi spare parts.

  • Page 3: Table Of Contents

    Contents For the User Important Safety Information • Installation • Child Safety • Your New Tumble Dryer Description of the Appliance The Control Panel • Programme Chart • Mains-on Light • On/Off Button • Low Temperature Button • Buzzer Off Button •...

  • Page 4: Your New Tumble Dryer, Description Of The Appliance

    Your New Tumble Dryer This tumble dryer will give your wash that soft, relaxed feel whatever the weather. Extremely high quality standards both during development and manufacturing guarantee a long service life for your appliance. Maximum economy in the operation of your dryer is achieved through very frugal electricity consumption and short drying times.

  • Page 5: The Control Panel, Programme Chart, Mains-on Light, On/off Button, Low Temperature Button, Buzzer Off Button

    The Control Panel CON NSER DRYER 1 Programme Chart This will help you to select the correct programme for drying. 2 Mains-On Light Comes on when the appliance is switched on (ON/OFF button pressed down) and goes out when this button is released. 3 ON/OFF Button This button is used to switch the dryer on.

  • Page 6: Programme/time Selector Dial

    8 Programme/Time Selector Dial Allows you to select electronically controlled or time controlled drying. Turn the dial to the required programme or time. Electronically controlled drying (automatic) The appliance runs these programmes with the help of probes which detect the degree of dampness of the laundry.

  • Page 7: Programme Chart

    Programme Chart Automatic drying (electronic programmes) Type of laundry extra dry ready to wear store dry Cotton slightly damp iron dry wring dry extra dry store dry Synthetics iron dry Jumpers baby dry Jackets, trousers, dry fresh dresses, skirts. (*) According to CEI 1121 Standards. •...

  • Page 8: Operating Sequence

    Operating Sequence Before using your tumble dryer for the first time, we recommend to place a few damp cloths inside the appliance and dry for 30 minutes. There may be dust inside a brand new tumble dryer. Drying 1. Connect the appliance. 2.

  • Page 9: Hints & Tips On Drying

    Hints & Tips on Drying Before placing articles of laundry in your tumble dryer, check the care labels to ensure they are recommended for tumble drying. Care Labels you may find on your laundry may be tumble dried normal drying (high temperature) delicate drying (low temperature) do not tumble dry Do not overload the appliance.

  • Page 10: Maintenance And Cleaning, External Cleaning, Cleaning The Door, Cleaning The Condenser Unit

    Maintenance and Cleaning You must disconnect the appliance from the electricity supply, before you can carry out any cleaning or maintenance work. External cleaning Use only soap and water and then dry thoroughly. Important: do not use methylated spirit, diluents or similar products.

  • Page 11: Emptying The Water Reservoir, Cleaning The Drum, Cleaning The Air Intake Grille

    Clean it with a brush and rinse it under the shower if necessary. Also clean the outside, removing all fluff. Clean the rubber seal round the condenser cabinet and in the inner part of the small door with a damp cloth.

  • Page 12: Something Not Working, Service And Spare Parts

    For the address of your local Service Force Centre and further information about Service Force, please visit the website at For Customer Service in Ireland please contact us at the address below: Zanussi Electrolux Electrolux Group (Irl) Ltd Long Mile Road Dublin 12 Republic of Ireland Tel: +353 (0)1 4090751 Email:

  • Page 13: Customer Care, Guarantee Conditions

    Guarantee Conditions Standard guarantee conditions We, Zanussi Electrolux, undertake that if, within 12 months of the date of the purchase, this ZANUSSI ELECTROLUX appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option...

  • Page 14: Installation Instructions, Technical Specifications, Unpacking, Positioning

    Installation Instructions It is dangerous to alter the specifications or attempt to modify this product in any way. Care must be taken to ensure that the appliance does not stand on the electrical supply cable. Technical Specifications DIMENSIONS POWER SUPPLY VOLTAGE TOTAL POWER ADSORBED MAX LOAD CAPACITY DRUM VOLUME...

  • Page 15: Stacking Kit (optional Accessory), Door Reversal, Electrical Connection

    To make it easier to load or unload the laundry the door can be reversed. This operation must be carried out by qualified personnel. Please contact the nearest Zanussi Service Force Centre. Electrical connection Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person.

  • Page 16

    From the Electrolux Group. The world’s No. 1 choice The Electrolux Group is the world's largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx. USD 14 billion in more than 150 countries around the world.
