Summary of Contents for Der Koch KANDEL
- Page 1 Installation and use manual for induction hobs: KANDEL y SYKE...
-
Page 2: Table Of Contents
Installing the hob ........................5 Kandel - Installation ........................6 Syke- Installation ........................8 Kandel- Description of the appliance ..................11 Syke- Description of the appliance ................... 15 Fault code..........................17 Pots and pans and how to use them ..................18 Safety reminding ........................ -
Page 3: Safety Instructions
Safety instructions Important This appliance generates magnetic field in the direct vicinity. ATTENTION: People with PACEMAKERS must ensure that their pacemaker has been designed in conformity with the norms in force. It is recommended that the manufacture or your doctor is consulted to verify any incompatibility. Important This appliance generates short range magnetic field therefore people with other types of electrical medical equipment, such as hearing aids for the deaf,... - Page 4 • If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. • WARNING: If the surface is cracked, switch off the appliance to avoid the possibility of electric shock.
-
Page 5: Installing The Hob
Installing the hob WARNING Risk of cutting. Be careful of cutting edges. End parts in foamed plastic - be careful. During transportation these could cause slight injury or cuts. Remove the material and envelope of documents from the packaging. Before proceeding with installation read the work instructions carefully. Step.1 Put a towel or cloth on the work surface. -
Page 6: Kandel - Installation
Power Cable Connection Kandel - Installation Preparing the unit for a built-in appliance 1. Drill a hole on the table surface according to the size shown in the drawing. For the purpose of the installation and use, a minimum of 50mm space shall be preserved around the hole. - Page 7 WARNING • The kitchen units that are in direct contact with the appliances must be heat-proof (min. 95°). • The appliance can be installed on a work surface with a thickness of between 30 and 40 mm and near to walls which are higher than the work surface,maintaining a minimum distance of 100 mm.
-
Page 8: Syke- Installation
Syke- Installation Preparing the unit for a built-in appliance 1. Drill a hole on the table surface according to the size shown in the drawing. For the purpose of the installation and use, a minimum of 50mm space shall be preserved around the hole. - Page 9 2. Owing to the high temperature inside the induction cooker, make sure good ventilation is provided to assure its normal operation, as shown: 3. ATTENTION: important assembly instructions for keeping the induction module cold. 4. Do not install the hob on top of a refrigerator or dishwasher.If the hob is installed on top of a drawer put a shelf in between as shown(50mm).If shelves are put in between ensure that they allow air to flow(30mm).
- Page 10 • Carry out all cutting of the unit and work surface then carefully remove shavings or sawdust before inserting the appliances. • To ensure a correct ventilation of the hob please comply with the dimensions shows in figures . • Always refer to the manufacturer for specific instructions. •...
-
Page 11: Kandel- Description Of The Appliance
Kandel- Description of the appliance Control Panel Schematic diagram of the control panel Instruction ON/OFF: Turn on or turn off the machine. CHILD LOCK: Press the button one time,it is lock.Other button can't operation when it is lock. Long press the button, it is unlock. - Page 12 Display: It shows power level and error code. Display: It shows time. The left above burner choose. The right above burner choose. The left bottomburner choose. The right bottom burner choose. Timer: Setting the time as you need. Booster function Keep warm function Display instructions of the LED light and digital tube 1) Display rule of the LED light.
- Page 13 (2) Power on status: "on / off" buttonused for switching on and off the induction cooker. A. Under standby state, press child lock, first unlock, then press "on/off" button, power indicator light always on, child lock indicator light does not show, one digit digital tube display "-", 20s without any operation, return to standby state.
- Page 14 (5) The keep warm function: To start up keep warm function, directly press L key, keep warm function indicator light will keep bright. A. The keep warm function can not timing, the keep warm function is available at each cooking zone at any power level while directly pressing L key, but you must select a cooking zone first.
-
Page 15: Syke- Description Of The Appliance
Syke- Description of the appliance Control Panel Schematic diagram of the control panel Instruction ON/OFF: Turn on or turn off the machine. CHILD LOCK : Press the button one time,it is lock. Other button can't operation when it is lock. Long press the button, it is unlock. UP: Increase the power level or add the time. - Page 16 Operation When the hob is plugged, the hob is ready for cooking but it is locked as “child-lock” status. (1) To unlock the hob, press the child lock icon. (2) Press on/off button to operate the hob. (3) Press the +/- button to select the power level. (4) To turn off the hob, Press on/off button.
-
Page 17: Fault Code
Fault code Fault Possible Cause Description Code No pan or pot,or their If no suitable pan or pot is placed on after size,material,etc. is not 60s, the hob will turn off automatically; if suitable, or not placed suitable pan or pot is placed within 60s, the precisely in the middle of hob will start to work. -
Page 18: Pots And Pans And How To Use Them
Pots and pans and how to use them Attention • The pots and pans that can be used on this hob must be made of ferromagnetic material. They can be made of enameied steel, cast iron or special pans of stainless steel for induction. - Page 19 Never have the hob to work For sealed foods such as The appliance is not without food in pot, otherwise canned goods, please do not intended to be used by its operational performance heat them before opening children or handicapped may be affected and danger their covers so as to avoid persons, unless they have...
-
Page 20: Maintenance And Cleaning
Maintenance and cleaning 1.Please shut off the power and pull out the plug before cleaning of the appliance. 2.Clean the appliance until it cools down completely. 3.To remove dirt, please select illustrious detergent. 4.After removing dirt, please use neat wet cloth to clean the unit. 5.Do not clean by water directly, water gets inside may cause malfunction. -
Page 21: Troubleshooting
Do not use these products: Abrasive powders or detergents, spray products for ovens, whitening products, sponges with abrasive surfaces, steel wool balls or synthetic ones. These products could seriously damage your hob. Troubleshooting Problem Possible causes What to do Check that the appliance is The appliance does appliance connected,... -
Page 22: Environmental Note
Environmental note This appliance is marked according to the European directive 2002/96/EC on Waste electrical and Electronic Equipment (WEEE). By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. -
Page 23: Warranty Certificate
Warranty Certificate This "Warranty Certificate" is extended for a twelve month coverage on the equipment detailed below, from the date of purchase and under the conditions stipulated: • Our obligation within the terms of this guarantee is to replace, without charge to the Client, any part that, in our opinion, has manufacturing defects.
