SUPPLEMENTAL INSTALLATION INSTRUCTIONS
MODEL H4CE180A40 (380V-3-60 Hz Electrical Supply)
Scope
This installation Instruction Supplement provides information specific to Model H4CE180A40. For all other
information regarding the installation and operation of this unit, refer to Installation Instruction Form 035-17384-000.
Approvals
As unit is for Export, it is not certified by ETL or CGA.
TABLE 3: Electrical Data
Model
Voltage
Power
HCE
Code
Supply
180
40
380-3-60
NOTES:1. Condenser Fan Motors are supplied by one (1) autotransformer (p/n 025-32756-000) used to elevate
380 volt supply to 475 volt. Full load Amp rating at 460-3-60 supply is 2.4 amp rating at 380 volt supply
terminals of autotransformer is 2.6.
2. Dual Element time delay type fuses or HACR circuit breakers. Refer to NEC/NFPA No. 70,
Articles 440-11 & 12 for information on disconnect size.
Subject to change without notice. Printed in U.S.A.
Copyright © by Unitary Products Group 2000. All rights reserved.
Unitary
Product
Group
SPLIT-SYSTEM CONDENSING UNITS (EXPORT)
Compressor
Sys. #1
Sys. #2
RLA
LRA
RLA
LRA
16.7
123
16.7
123
®
Condensing Fan
HP
FLA (See Notes)
1.0 EA.
2.5 EA.
Supersedes: 035-17318-000 Rev. A (10/00)
5005
York
Drive
035-17392-000 REV. A (0401)
Minimum Cir-
Maximum Fuse Size.
cuit Ampacity
Amps (See Note 2)
42.6
50
035-17392-000 REV. A (0401)
Norman
OK
73069
