Capricorn RC TE02 Instruction Manual
  1. Manuals
  2. Brands
  3. Capricorn RC Manuals
  4. Motorized Toy Car
  5. TE02
  6. Instruction manual

Capricorn RC TE02 Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Instruction Manual rel. 1.4
(10-2012)

Advertisement

loading
Need help?

Need help?

Do you have a question about the TE02 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Capricorn RC TE02

Summary of Contents for Capricorn RC TE02

  • Page 1 Instruction Manual rel. 1.4 (10-2012)
  • Page 2 CAPRICORN RC is not responsible for any damage or harm caused by improper use or assembly. CAPRICORN RC and its distribution network are not responsible for any damage caused by shipping or handling. Eventual parts missing from the kit or flawed must be reported within two weeks of purchase to your local hobby shop or distributor.
  • Page 3 Capricorn RC Step 0.2 - Tools & Equipment - Tools needed for assembly (NOT INCLUDED) Box Wrench Glass or Vinyl Hex Wrench Wrench Glowplug Reamer Adjustable Pliers Tape 1,5/2/2,5/3mm & Cluthnut Cutter Pliers Parts for model completion and Start (NOT INCLUDED) Steering &...
  • Page 4 Step 0.3 Capricorn RC - Screws Chart - M2,5x8 M2x6 E-Ring M2,5x6 M2,5x10 E-Ring M3x8 Flanged M2,5x8 M3x12 Flanged M3x5 M3x6 M3x3 M3x5 M3x8 Washer 3,5x10x0,2 M3x10 M3x8 Washer 5x10x0,2 M3x12 M3x12 Washer 5x15x0,3 M4x3 M3x16 M4x4 Washer 6x10x0,5 M3x6...
  • Page 5 Capricorn RC Step 1.0 - Shock absorbers - Front 55 / Rear 56 3x1,78 Parts List M2,5 Nut Rif. n° Code Cap16066T 2,6x6,2x0,5 Cap16057 Cap14044 Cap17039 Cap16016 Capshockori Capshockori Cap16003 Cap14033 Cap14036 Cap16085 Cap14042 Made in Italy...
  • Page 6 Capricorn RC Step 1.1 - Shock absorbers - Front 2x Initial Setting Front Rear 2x Rear Code Cap16032 Initial Setting 12x1,5 Parts List Rif. n° Code Cap171215 Cap16027 Cap16030 Cap14030 Made in Italy...
  • Page 7 Step 2.0 Capricorn RC - Front gear differential - 5x10x0,2 5x15x0,3 2x10 Pin Parts List Rif. n° Code Cap14014 Cap17042 Cap16075 Cap170520 Cap17042 Cap17015 Cap14045 Made in Italy...
  • Page 8 Capricorn RC Step 2.1 - Front gear differential - 5x10x0,2 5x15x0,3 2x10 Pin Parts List Rif. n° Code Cap14014 Cap17042 Cap16075 Cap170520 Cap17042 Cap17015 Cap14045 Made in Italy...
  • Page 9 Capricorn RC Step 2.2 - Front gear differential - 3,5x10x0,2 Note: Satellite gears (n° 4) must move freely on the diff Pin (n° 2) Parts List Rif. n° Code Cap16056 Cap14045 Cap17042 Made in Italy...
  • Page 10 Capricorn RC Step 2.3 - Front gear differential - 24x0,7 15x1 M2,5x8 Fill differential up to the top of the pins with silicon oil. Initial Setting 300.000 Parts List Rif. n° Code Cap172407 Cap17022 Made in Italy...
  • Page 11 Step 2.4 Capricorn RC - Front gear differential - 10x15x4 10x15x4 Parts List Rif. n° Code M2x6 Cap14028K Cap17020 Cap18018 Made in Italy...
  • Page 12 Step 3.0 Capricorn RC - Rear gear differential - 5x10x0,2 5x15x0,3 2x10 Parts List Rif. n° Code Cap14021 Cap17042 Cap16076 Cap170520 Cap17042 Cap17015 Cap14045 Made in Italy...
  • Page 13 Capricorn RC Step 3.1 - Rear gear differential - 5x10x0,2 5x15x0,3 2x10 Pin Parts List Rif. n° Code Cap14021 Cap17042 Cap16076 Cap170520 Cap17042 Cap17015 Cap14045 Made in Italy...
  • Page 14 Step 3.2 Capricorn RC - Rear gear differential - 3,5x10x0,2 Note: Satellite gears (n° 4) must move freely Parts List on the diff Pin (n° 2) Rif. n° Code Cap16056 Cap14045 Cap17042 Made in Italy...
  • Page 15 Capricorn RC Step 3.3 - Rear gear differential - 10x16x4 Fill differential up to the top of the pins with silicon oil. Initial Setting 100.000 24x0,7 15x1 10x16x4 M2,5x8 Parts List Rif. n° Code Cap172407 Cap17022 Cap16017 Made in Italy...
  • Page 16 Capricorn RC Step 4.0 - 2 Speed gear - M2,5x10 22 - 0 M4x3 Thread Lock Parts List Rif. n° Code Cap16024 Cap14017 Cap17038 6x10x3 Cap14020 Cap16025 Cap16001 Cap16074 Cap17009 M3x5 Cap16062 6x10x3 Cap14032 Cap16011 M3x5 Cap16031 Cap17021 Cap16079 Cap17002...
  • Page 17 Step 5.0 Capricorn RC - Servo Saver - 6x10x3 6x10x3 M3x6 Thread Lock Option Ackermann Inserts Parts List Rif. n° Code Cap16014 Cap16065-B Cap16065 M3x6 Cap16033 10x1,5 Cap171015 Cap16028 Thread Lock Cap16019 Cap16055 Cap15005 Cap17030 Cap17029 Initial Setting Cap16086 Made in Italy...
  • Page 18 Capricorn RC Step 6.0 Move freely - Belt Tensioner Set - To loosen side belt To tighten side belt 5x10x4 5x10x4 Flanged M3x12 Parts List M3x3 Rif. n° Code Thread Loock Cap16080-B 3x6x2,5 Cap18000 Cap17006 Cap 2029 Cap15010 Cap16012 Cap 415...
  • Page 19 Capricorn RC Step 7.0 - Middle Shaft Holder - 6x10x0,9 Black Plastic 6x13x5 M3x6 Thread Lock Initial setting Code Cap14027 2x12 Pin Parts List Rif. n° Code Cap16083 6x13x5 Cap16020 Cap16002 Cap14022 Cap17046 Cap17016 Cap18019 2x12 Pin Cap17030 To loosen front belt...
  • Page 20 Capricorn RC Step 8.0 - Rear Suspension - M3x3 2x10 Pin 2x L/R 10x16x4 Parts List 10x16x4 Rif. n° Code Cap14004 Cap16017 Cap16004 Cap16026 Cap16097 Cap17015 Pivot Balls must move freely Cap 255+ Cap17006 Made in Italy...
  • Page 21 Step 8.1 Capricorn RC - Rear Suspension - M3x8 Hard Thread lock on the 9 pin only 2 and 3 side parts Parts List Rif. n° Code Cap16071-B Inital position Cap16038-B for Long wheel Cap16039-B Cap17031 3x10 Pin Cap14038 3x50...
  • Page 22 Step 8.2 Capricorn RC - Rear Suspension - M3x12 Thread Lock M3x8 Thread Lock 3x177 belt !! Insert before 3 4 parts !! Grease Parts List 5,8 ball Rif. n° Code M3x8 Cap16059-B Grease Cap14013 Cap16046-Q Front Cap16047-Q Cap17024 Initial setting...
  • Page 23 Capricorn RC Step 8.3 - Rear Suspension - Parts List 5,8 FL ball M3x16 !! Flare on top side !! Rif. n° Code Cap18002-XL 3x6x2,5 Initial Setting Cap18001 Cap18003 Cap16086F Cap17043 Drill 1,5mm Cap17024 Cap14038-Q Drill Cap16054 Cap14031 3x32 Rear camber setting +..-...
  • Page 24 Step 8.4 Capricorn RC - Rear Transmission - Parts List Rif. n° Code M3x12 Thread Lock Cap16040-B 6x12x4 Cap17031 Cap16021 M3x8 Cap17026 Thread Lock Made in Italy...
  • Page 25 Capricorn RC Step 8.5 - Brake set - M4x4 Z 20 Thread Lock M3x20 6x12x4 Parts list Rif. n° Code M3 Nut Cap16077 Fibre pad Steel pad Cap17010 Cap14025K Cap14025K Parts List Rif. n° Code Note: Cap16037-B Roughen steel plates...
  • Page 26 Capricorn RC Step 8.6 - Rear Transmission - Parts List M3x12 Thread Lock Rif. n° Code Cap16019 M3x8 5x8x2,5 Thread Lock Cap17031 Cap17026 Made in Italy...
  • Page 27 Capricorn RC Step 8.7 - Rear Transmission - Z 18 2x12 Pin Parts List Rif. n° Code Cap16022 Cap17002 Cap14022 Cap17016 Cap14023K Cap14023K Made in Italy...
  • Page 28 Capricorn RC Step 9.0 - Rear Anti-Roll bar - M3x3 5x8x2,5 right move Note: Insert ball berings left move before pivot ball 30° left move side Note: Wire should be flush with end of pivot ball Parts List Rif. n°...
  • Page 29 Capricorn RC Step 9.1 - Rear Anti-Roll bar - Note: Left move side Up position M3x3 Note: adjust position for minimum offset and freely rear bar movement Zoom view Parts List Rif. n° Code Cap16010 Cap17006 Made in Italy...
  • Page 30 Capricorn RC Step 10.0 - Brake Link - M3x8 M3x6 Thread Lock Thread Lock Carbon plate Parts List Rif. n° Code Cap15008 Cap16068-P Cap17032 Cap16029 Cap17030 Made in Italy...
  • Page 31 Capricorn RC Step 11.0 - Battery Holders - Bottom view Note: Use tape to mount RX battery to the carbon plate holder RX Battery (NOT INCLUDED) Default Plastic Plate --- --- --- Option Carbon Plate M3x6 code Cap15014 Option Brass Plate...
  • Page 32 Capricorn RC Step 12.0 - Central Transmission - M3x8 Thread Lock Parts List Rif. n° Code Cap16036 Cap15009P Cap17032 Cap14011 Cap17031 Cap14012 3x186 belt M3x8 Thread Lock 3x390 belt Made in Italy...
  • Page 33 Capricorn RC Step 13.0 Right Block - Front Suspension - M4x6 Thread Lock 3x65 M3x5 Parts List Rif. n° Code M3x12 Cap18006 Flanged M3x12 Cap14005 Cap16051 To adjust Anti-roll bar position Cap16082 To adjust front down stop position Cap16084 Cap17025...
  • Page 34 Capricorn RC Step 13.1 - Front Suspension - Parts List Rif. n° Code M3x8 Thread Lock Cap18007 Cap14006 Cap16007 Cap17031 Made in Italy...
  • Page 35 Capricorn RC Step 13.2 - Front Transmission - M3X20 Thread Lock M3X6 Thread Lock Parts List Rif. n° Code Cap18015 Cap18008 Cap17028 Cap15002 M3X10 Thread Lock Cap17023 Note: Cap18009 insert front belt on the pulley before placing the differential Cap17030...
  • Page 36 Step 13.3 Capricorn RC - Front Suspension - M3x8 Thread Lock Parts List Rif. n° Code Cap18010-Q Front up roll center insert Cap14038-Q M2,5x4 3x40 Default 45° eccentric holder for Cap14007 four different setting Cap16052 Drill Option 1,5 eccentric holder for...
  • Page 37 Capricorn RC Step 13.4 Right Steering Block - Front Suspension - M3x3 2x10 Pin 10x16x4 2x10 Pin 2x L/R Parts List 10x16x4 Rif. n° Code Cap14002 5,8 ball Cap16017 Cap16004 M3x8 Cap16026 Cap16063 Pivot Balls must move freely Cap16049 Grease...
  • Page 38 Capricorn RC Step 13.5 - Front Suspension - Note: Ensure that the front suspension moves freely Grease Made in Italy...
  • Page 39 Capricorn RC Step 14.0 - Steering - M3x8 Parts List Thread lock Rif. n° Code Cap17031 Cap16073 Cap14041 Made in Italy...
  • Page 40 Capricorn RC Step 15.0 Bodymounts Parts List Rif. n° Code Cap14034 M3x10 Cap17027 M3x8 Cap17040 Cap15011 Cap17031 Made in Italy...
  • Page 41 Step 15.1 Capricorn RC Initial position - Front Bodymounts M3x6 2x12 Pin M3x8 Parts List Rif. n° Code Cap14010 Cap15007P Cap17032 Cap17030 Cap17016 Cap15013 Made in Italy...
  • Page 42 Step 15.2 Capricorn RC Rear Bodymounts Initial position 2x12 Pin M3x8 Parts List Rif. n° Code Cap15012 Cap17032 Cap17016 Cap15013 Made in Italy...
  • Page 43 Capricorn RC Step 16.0 Fuel Tank & Electronics M3x10 M3x8 Note: 3mm shims when using Parts List micro-size RX battery Rif. n° Code Cap18011 Cap16061 Cap17031 Note: insert into the holes Cap14029 of the radio plate Cap14029 Cap17023 Cap14039 Made in Italy...
  • Page 44 Step 16.1 Capricorn RC Note: Fuel Tank & Electronics 90° between the ball joints 90° : 95° Parts List Rif. n° Code Cap17005 Cap14043 M3x6 NOT INCLUDED Parts List Servo grommet Rif. n° Code Cap16070 Cap17041 Servo Cap17028 M3x6 Cap16048...
  • Page 45 Capricorn RC Step 16.2 Fuel Tank & Electronics M3x12 Servo grommet Parts List Rif. n° Code Servo Cap17026 NOT INCLUDED Cap16048 Made in Italy...
  • Page 46 Capricorn RC Step 16.3 Fuel Tank & Electronics M3x12 Double-sided tape size 25x17 Parts List Rif. n° Code Cap14040 Receiver Cap14001 Silicone Tubing NOT INCLUDED Cap17026 Made in Italy...
  • Page 47 Step 17.0 Capricorn RC - Radio plate assembly - M3x6 Thread lock Note: Attach steering linkage to servo arm up 5,8 ball Parts List Rif. n° Code Cap17030 Made in Italy...
  • Page 48 Capricorn RC Step 18.0 5° Adjust angle - Gas/Brake Linkage - with pliers M3x3 Note: Insert link in the Note: brake arm before. Do not overtighten screws. Pivots must rotate freely Parts List Rif. n° Code Servo arm Cap17041 M2,5x8...
  • Page 49 Step 18.1 Capricorn RC - Gas/Brake Linkage - Servo screw Made in Italy...
  • Page 50 Capricorn RC Step 19.0 - Rear Shock Assembly - Initial setting 5,8 ball M3x6 Parts. List Rif. n° Code Cap17030 5,8 ball Cap16086 Made in Italy...
  • Page 51 Capricorn RC Step 19.1 - Front Shock Assembly - Initial setting M3x6 5,8 ball Parts. List Rif. n° Code Cap17030 5,8 ball Cap16086 Made in Italy...
  • Page 52 Capricorn RC Step 20.0 - Clutch - 5x7x0.2 5x7x0,1 Parts List 5x10x4 Rif. n° Code Cap 405WC 5x8x2,5 Cap 408 5x10x4 Axial Cap 414 Cap 411M08 Cap 403-08 Cap 410WC M3x12 Cap 417 Cap 409 Cap 434 Cap 434 Cap 413...
  • Page 53 Capricorn RC Step 20.1 - Engine & Clutch - 9,2: Use the cone that comes whit your engine Note: Hard Tighten the clutch nut with 10mm Hex Tool Shim for adjusting flywheel distance Made in Italy...
  • Page 54 Capricorn RC Step 20.2 - Engine & Clutch - 0,4:0,6 Spring preload Made in Italy...
  • Page 55 Capricorn RC Step 20.3 - Engine & Clutch - Adjusting the clutch bell gap Push the clutch bell on to the clutch shoe and misure A distance Gap =0 Note: Do not install internal shims Gap =0,5 Note: install internal...
  • Page 56 Capricorn RC Step 20.4 - Engine & Clutch - Grease Endplay gap = Endplay shims Z20 (Option Z19) Z15 (Option Z14) NOTE ORIENTATION Large chanfer Made in Italy...
  • Page 57 Capricorn RC Step 21.0 - Final Assembly - M3x8 Flanged Parts List Rif. n° Code Note: Cap 506 Orient appropriately for your Exhaust system M4x4 Cap17010 Cap16005 Cap17034 Cap 854 Made in Italy...
  • Page 58 Capricorn RC Step 21.1 - Final Assembly View - Made in Italy...
  • Page 59 Capricorn RC Step 21.2 - Final Assembly View - Made in Italy...
  • Page 60 Capricorn RC - DEFAULT SET-UP SHEET - Type 1 Type 2 Type 3 Rear ~ ~ ~ ~ FRONT REAR Front ~ ~ ~ ~ TYRES LEFT RIGHT LEFT RIGHT Type 1 Type 2 Type 3 TYPE Shock Position SHORE...
  • Page 61 Capricorn RC - BLANK SET-UP SHEET - Type 1 Type 2 Type 3 Rear FRONT REAR Front TYRES LEFT RIGHT LEFT RIGHT Type 1 Type 2 Type 3 TYPE Shock Position SHORE DIAMETER SHOCK ABSORBERS Upper Arm Position Upper Arm Position...
  • Page 62 Capricorn RC Step A - Front wire anti-roll bar - OPTION KIT M3x3 Note: adjust position for minimum offset and freely front bar movement Parts List Rif. n° Code 5x8x2,5 Cap17051 Cap17052 Cap17041 16,5 Cap18012Kit Cap16019 Cap18014-xy Before After Cap17006...
  • Page 63 Capricorn RC Notes Made in Italy...
  • Page 64 Capricorn RC - Titanium screws Kit - Made in Italy...
  • Page 65 Capricorn RC - Titanium screws Kit - M3x6 Titanium button n° 23 M3x18 Titanium button n° 2 M3x8 Titanium button n° 18 M3x20 Titanium button n° 2 M3x10 Titanium button n° 5 M3x12 Titanium flat n° 4 M3x12 Titanium button n° 10 M3x16 Titanium flat n°...
