- Page 1 Parts Manual ZMMKW34170 / 968999757 Please read the operator’s manual carefully and make sure you understand the instructions before using the machine.
- Page 2 ©2007 HTC. All Rights Reserved. Beatrice, NE. Printed in U.S.A.
-
Page 3: Table Of Contents
CHASSIS / FRAME ... 4 ENGINE ... 6 STEERING ... 8 PARKING BRAKE ... 10 HYDRAULIC PUMP-MOTOR ... 12 MOWER LIFT / DECK LIFT ... 14 34" DECK ... 16 NOTE: ALL FASTENERS ARE GRADE 5 UNLESS OTHERWISE SPECIFIED. CONTENTS CONTROLS ... -
Page 4: Chassis / Frame
CHASSIS / FRAME... - Page 5 ITEM PART NO. QTY. DESCRIPTION 539 121506 ...2 ... BRACKET, BLOCKOUT 539 132805 ...1 ... CHANNEL SEAT MOUNT 539 132801 ...1 ... FRAME 539 110813 ...1 ... “U” TYPE RETAINER ¼ 539 114832 ...1 ... DECAL, OIL TANK 539 977778 ...2 ...
-
Page 6: Engine
ENGINE... - Page 7 ITEM PART NO. QTY. DESCRIPTION 539 110065 ...1 ... BOLT, 539 115387 ...1 ... KEY, ¼ x .88 539 115546 ...1 ... WASHER, 539 118893 ...1 ... OIL DRAIN 539 119489 ...1 ... HUB, BEARING-SPACER 539 119680 ...1 ... ADAPTOR, OIL DRAIN 539 120786 ...1 ...
-
Page 8: Steering
STEERING... - Page 9 ITEM PART NO. QTY. DESCRIPTION 539 101332 ...2 ... HHB ½-13 x 2¾ 539 108396 ...2 ... HHB -18 x 2½ 539 110340 ...2 ... NUT -11 HEX NYLOC 539 115502 ...4 ... NUT -24 HEX JAM 539 115533 ...2 ... WASHER 539 991073 ...2 ...
-
Page 10: Parking Brake
PARKING BRAKE... - Page 11 ITEM PART NO. QTY. DESCRIPTION 539 107271 ...2 ... RHSSNB 539 109332 ...2 ... NUT -16 HEX JAM 539 115617 ...2 ... NUT -18 HEX NUT NYLOC 539 115668 ...2 ... ROLL PIN, 539 121861 ...1 ... BRAKE SWITCH 539 115680 ...4 ...
-
Page 12: Hydraulic Pump-Motor
HYDRAULIC PUMP-MOTOR... - Page 13 HYDRAULIC PUMP-MOTOR ITEM PART NO. QTY. DESCRIPTION 539 115278 ...1 ... IDLER PULLEY 539 115546 ...1 ... WASHER.445 x 1.387 x .255 539 108010 ...1 ... NUT ½-13 HEX NYLOC 539 116008 ...1 ... BUSHING 1.90 539 117855 ...1 ... TUBE HYD LH-A 539 117856 ...1 ...
-
Page 14: Mower Lift / Deck Lift
MOWER LIFT / DECK LIFT... - Page 15 MOWER LIFT / DECK LIFT ITEM PART NO. QTY. DESCRIPTION 539 100476 ...4 ... NUT -11 HEX JAM 539 108369 ...2 ... HHB ½-13 x 1¼ 539 115359 ...1 ... BLADE ADAPTOR 539 115501 ...4 ... HAIR PIN COTTER 539 115518 ...2 ...
-
Page 16: 34" Deck
34" DECK... - Page 17 ITEM PART NO. QTY. DESCRIPTION 539 108346 ...2 ... HHB ½-13 x 2½ 539 109554 ...1 ... WASHER ½ FLAT 539 132829 ...1 ... HINGE, DEFLECTOR 539 132830 ...1 ... DEFLECTOR 539 115220 ...3 ... BUSHING ½ ID x ¾OD 539 115278 ...2 ...
-
Page 18: Controls
CONTROLS... - Page 19 ITEM PART NO. QTY. DESCRIPTION 539 110074 ...1 ... HOUR METER 539 115208 ...1 ... BACKING PLATE 539 115640 ...4 ... ¼-20x½ SCREW 539 115850 ...1 ... CIRCUIT BREAKER 539 132440 ...1 ... FENDER 539 131931 ...1 ... CONTROL PANEL 539 132443 ...1 ...
-
Page 20: Fuel System
FUEL SYSTEM... - Page 21 ITEM PART NO. QTY. DESCRIPTION 539 106188 ...1 ... CAP, FUEL 539 912222 ...4 ... FUEL LINE CLAMP 539 115736 ...1 ... HOSE ¼ x 8 539 117050 ...1 ... HOSE ¼ x 28 FUEL SYSTEM ITEM PART NO. 539 132439 ...1 ...
-
Page 22: Seat
SEAT... - Page 23 ITEM PART NO. QTY. DESCRIPTION 539 115674 ...2 ... NUT -18 HEX FLANGE 539 116091 ...2 ... SPACER 539 132816 ...1 ... SEAT PLATE 539 118102 ...2 ... CLIP 539 119102 ...2 ... ISO MOUNT 1½ x ¾ SEAT ITEM PART NO. QTY.
-
Page 24: Casters
CASTERS... - Page 25 ITEM PART NO. QTY. DESCRIPTION 539 115566 ...2 ... HHB -18 x 1 NYLOC 539 115675 ...2 ... WASHER, 1.025 ID x 1.64 OD 539 115747 ...2 ... CASTER SPRING 539 115749 ...2 ... CASTER PLUG 539 115750 ...2 ... BEARING 539 132826 ...2 ...
-
Page 26: Electrical
ELECTRICAL... - Page 27 ITEM PART NO. QTY. DESCRIPTION 539 115292 ...1 ... TIE DOWN W/INSULATOR 539 115364 ...2 ... SOLENOID/STARTER CBL 539 115774 ...1 ... SOLENOID 539 116400 ...1 ... TERMINAL COVER-SM 539 102436 ...1 ... BATTERY 12V 539 121331 ...1 ... TERMINAL COVER 539 122754 ...1 ...
-
Page 28: Drive
DRIVE... - Page 29 ITEM PART NO. QTY. DESCRIPTION 539 100413 ...4 ... RHSB 539 101173 ...8 ... NUT ½-20 UNF HEX LUG 539 101331 ..16 ... NUT½-13 HEX NYLOC 539 108346 ...8 ... HHB ½-13 x 2½ 539 108369 ...8 ... HHB ½-13 x 1¼ 539 115370 ...2 ...
-
Page 30: Decals
DECALS... - Page 31 ...1 ... DECAL, CUT HEIGHT 539 119978 ...1 ... DECAL, LEVER 539 102063 ...2 ... DECAL, COMMERCIAL DECALS 539 103433 ...1 ... DECAL, YAZOO/KEES 539 103424 ...1 ... DECAL, Y/K 10.. 539 117707 ...1 ... DECAL, FUSION 11.. 539 118057 ...1 ...
- Page 34 Part No. 539 132448 R02 02/01/08...
