- Page 1 H3C S7500E-X Switch Series Command Reference Hangzhou H3C Technologies Co., Ltd. http://www.h3c.com Software version: S7500EX-CMW710-R7523P01 Document version: 6W100-20160830...
- Page 2 , H3CS, H3CIE, H3CNE, Aolynk, Care, , IRF, NetPilot, Netflow, SecEngine, SecPath, SecCenter, SecBlade, Comware, ITCMM and HUASAN are trademarks of Hangzhou H3C Technologies Co., Ltd. All other trademarks that may be mentioned in this manual are the property of their respective owners Notice The information in this document is subject to change without notice.
- Page 3 Preface This command reference describes OAA configuration commands. This preface includes the following topics about the documentation: • Audience. • Conventions. • About the H3C S7500E-X documentation set. • Obtaining documentation. • Technical support. • Documentation feedback. Audience This documentation is intended for: •...
- Page 4 Convention Description Asterisk marked braces enclose a set of required syntax choices separated by vertical { x | y | ... } * bars, from which you select at least one. Asterisk marked square brackets enclose optional syntax choices separated by vertical [ x | y | ...
- Page 5 Represents a security card, such as a firewall, load balancing, NetStream, SSL VPN, IPS, or ACG card. About the H3C S7500E-X documentation set The H3C S7500E-X documentation set includes the following categories of documents: Category Documents Purposes...
- Page 6 System log messages Explains the system log messages. Obtaining documentation Access the most up-to-date H3C product documentation on the World Wide Web at http://www.h3c.com. Click the following links to obtain different categories of product documentation: [Technical Documents]—Provides hardware installation, software upgrading, and software feature configuration and maintenance documentation.
-
Page 7: Table Of Contents
Contents OAP module commands ················································································· 1 oap connect ······················································································································································· 1 oap reboot ·························································································································································· 1 OAP commands ······························································································ 3 display oap client info ································································································································· 3 display oap client summary ························································································································ 4 oap client close ·········································································································································· 5 oap client reboot ········································································································································· 6 oap enable ·················································································································································... -
Page 8: Oap Module Commands
OAP module commands oap connect Use oap connect to log in to the CLI of an OAP module from the device. You can also use this command to log in to another operating system that is running on a card in the device. Syntax In standalone mode: oap connect slot slot-number... - Page 9 Predefined user roles network-admin mdc-admin Parameters slot slot-number: Specifies an OAP module by its slot number. (In standalone mode.) chassis chassis-number slot slot-number: Specifies an OAP module in an IRF member device by the member ID and slot number. (In IRF mode.) Examples # (In standalone mode.) Reboot the OAP module in the specified slot.
-
Page 10: Oap Commands
OAP commands display oap client info Use display oap client info to display OAP client information. Syntax display oap client info [ client-id ] Views Any view Predefined user roles network-admin network-operator mdc-admin mdc-operator Parameters client-id: Specifies an OAP client by its ID in the range of 1 to 255. If you do not specify this argument, the command displays information about all OAP clients in ascending order of client IDs. -
Page 11: Display Oap Client Summary
Client ID: 2 CPU: Intel(R) Pentium(R) M processor 1.40GHz PCB Version: 3.00 CPLD Version: 1.00 Bootrom Version: 1.12 Storage Card: 256 MB Memory: 512 MB Harddisk: 40.0 GB Related commands display oap client summary display oap client summary Use display oap client summary to display the summary registration information of OAP clients. Syntax display oap client summary [ client-id ] Views... -
Page 12: Oap Client Close
Status: Registered MAC Address: 00e0-fa1e-03da Interface: Ten-GigabitEthernet1/0/2 Last registered: 02/08/2011 13:00:00 Table 1 Command output Field Description Status Status of the OAP client, which is always Registered. MAC Address MAC address of the OAP client. Interface Interface used to communicate with the OAP client. Last registered Registration time of the client. -
Page 13: Oap Client Reboot
oap client reboot Use oap client reboot to restart an OAP client. Syntax oap client reboot client-id Views System view Predefined user roles network-admin mdc-admin Parameters client-id: Specifies an OAP client by its ID in the range of 1 to 255. Client IDs are assigned by the OAP manager to OAP clients to uniquely identify the clients. -
Page 14: Oap Timer Clock-Sync
mdc-admin Examples # Enable OAP on interface Ten-GigabitEthernet 1/0/1. <Sysname> system-view [Sysname] interface ten-gigabitethernet 1/0/1 [Sysname-Ten-GigabitEthernet1/0/1] oap enable oap timer clock-sync Use oap timer clock-sync to set the clock synchronization timer. Use undo oap timer clock-sync to restore the default. Syntax oap timer clock-sync minutes undo oap timer clock-sync... - Page 15 Views System view Predefined user roles network-admin mdc-admin Parameters seconds: Specifies the client monitoring timer in seconds, in the range of 0 to 10. Setting this argument to 0 disables client monitoring. Usage guidelines The client monitoring timer regularly triggers the OAP manager to send client monitoring packets to OAP clients.
-
Page 16: Index
Index oap client close,5 oap client reboot,6 display oap client info,3 enable,6 display oap client summary,4 oap timer clock-sync,7 oap timer monitor,7...
