Summary of Contents for Cartoni Focus 8
- Page 1 PROFESSIONAL CAMERA SUPPORT USER’S MANUAL & Maintenance...
- Page 3 & S afety ntrodUctIon peratIng elementS rocedUreS pecIfIcatIonS aIntenance arranty & cceSSorIeS prodUct lIne CARTONI ® All rights reserved © Manual Version: 2.2 Issue date: March 2020...
- Page 5 & S afety ntrodUctIon The FOCUS 8 Fluid Head is the ideal support for the latest smaller, light- er high-performance Cameras weighing from 0 to 8 kg (0 to 17.7 lbs). Extremely compact and lightweight, the innovative FOCUS 8 features...
-
Page 6: Operating Elements
2. o peratIng lementS ❺ ❸ ❹ ❻ ❶ ❷ Tie down knob Pan brake lever Pan bar Pan bar attachment Pan bar extension Tilt brake lever... - Page 7 ❾ ❿ ⓫ ⓬ ❽ ⓭ Level bubble ❼ Pan drag selector Camera Plate lock Safety lock Camera Plate Balance knob Tilt drag selector...
- Page 8 3. p rocedUreS Place the FOCUS 8 on your Tripod by loosening the tie-down knob (1) under the Fluid Head and level using the level bubble (7). Connect the Pan bar (3) to the Fluid Head tightening the lever (4) on the Pan bar attachment and select your desired operating angle.
-
Page 9: Specifications
Unlock the Pan brake lever (2) and set Fluid drag control by adjusting selectors (8) and (13). For easy mounting on a slider, the threaded shaft on the head bowl can be removed with a 10 mm allen key and a 3/8 inch threaded hole will allow the connection. -
Page 10: Maintenance
5. m aIntenance With indoor use - when needed - just clean the FOCUS 8 and Tripod with a soft cloth. Dirt accumulated during storage may be removed using a brush or Air spray. CARTONI products main mechanisms are sealed as they are also built for professional outdoor use. - Page 11 It is the end user’s responsibility when ordering to ensure that the prod- ucts ordered conform to his requirements. All freight of product to CARTONI must be prepaid. All implied war- ranties are limited to the time period set forth herein & subject to change without notice.
- Page 12 PROFESSIONAL CAMERA SUPPORT CARTONI S.p.A Via di Portonaccio, 33/B - 00159 Rome (Italy) Phone +39 06 4382002 Fax +39 06 43588293 Email: cartoni@cartoni.com www.cartoni.com...
