Parts Manual for
MODELS:
KHKW36151
KHKW48171
MANUAL 106540 REV. IR (10/10/01)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KHKW36151 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Yazoo/Kees KHKW36151

Summary of Contents for Yazoo/Kees KHKW36151

  • Page 1 In an effort to keep pace with changes in technology, Yazoo/Kees reserves the right to make changes or improvements at any time without incurring any obligation to make such changes on products previously manufactured.
  • Page 2 MODEL NUMBER SERIAL NUMBER DATE PURCHASED DEALER ADDRESS NOTES...

  • Page 3: Table Of Contents

    CONTENTS SECTION PAGE HYDRAULIC ASSEMBLY ... 4 REAR DECK ASSEMBLY ... 6 ENGINE ASSEMBLY ... 8 48" FRONT DECK ASSEMBLY ... 10 36" FRONT DECK ASSEMBLY ... 12 CUTTER HOUSING ASSEMBLY... 14 HANDLE ASSEMBLY ... 16 MOTION CONTROL ASSEMBLY ... 18 FRONT CASTER ASSEMBLY ...

  • Page 4: Hydraulic Assembly

    HYDRAULIC ASSEMBLY...
  • Page 5 HYDRAULIC ASSEMBLY ITEM PART NO. QTY. 1 ... 101245 ... 4 ... 1/2" HYDRAULIC HOSE 2 ... 101243 ... 2 ... 45 DEG. ELBOW 3 ... 101239 ... 2 ... STRAIGHT CONNECTOR 4 ... 101237 ... 2 ... STRAIGHT CONNECTOR 5 ...

  • Page 6: Rear Deck Assembly

    REAR DECK ASSEMBLY...
  • Page 7 ITEM PART NO. QTY DESCRIPTION 1 ... 102265 ... 1 ... REAR DECK W/DECALS 2 ... 106535 ... 1 ... TANK SUPPORT 3 ... 101324 ... 1 ... BUMPER 4 ... 100352 ... 1 ... LOWER BELTSHIELD 5 ... 104553 ... 2 ... WHEEL, COMPLETE 6 ...

  • Page 8: Engine Assembly

    ENGINE ASSEMBLY...
  • Page 9 ENGINE ASSEMBLY ITEM PART NO. QTY. 1 ... 102036 ... 1 ... BELT GUIDE 36" MODEL ... 1 ... BELT GUIDE 48" MODEL 2 ... 106504 ... 1 ... HEAVY WASHER 3 ... 990669 ... 4 ... HCS 5/16 X 1.750 4 ...

  • Page 10: 48" Front Deck Assembly

    48" FRONT DECK...
  • Page 11 59 ... 105746 ... 1 ... DECAL, SEVERING 60 ... 913010 ... 1 ... DECAL, CPSC 61 ... 103420 ... 1 ... DECAL, YAZOO/KEES 62 ... 101369 ... 1 ... DECAL, 48 63 ... 102335 ... 3 ... HCS 5/16C X 4 64 ...

  • Page 12: 36" Front Deck Assembly

    36" FRONT DECK ASSEMBLY...
  • Page 13 23 ... 990184 ... 16 ... HLN 5/16C 24 ... 990209 ... 10 ... HCS 5/16C X 1 25 ... 103420 ... 1 ... DECAL, YAZOO/KEES 26 ... 990585 ... 6 ... HFLN 5/16C 27 ... 990553 ... 6 ... HCS 5/16C X 3 28 ...

  • Page 14: Cutter Housing Assembly

    CUTTER HOUSING ASSEMBLY...
  • Page 15 CUTTER HOUSING ASSEMBLY ITEM PART NO. QTY. 1 ... 102440 ... 1 ... CUTTER HOUSING ASM. 2 ... 102675 ... 3 ... MACH. BUSING 10GA. 3 ... 102244 ... 2 ... MACH. BUSING 18GA. 4 ... 102677 ... 2 ... BEARING 5 ...

  • Page 16: Handle Assembly

    HANDLE ASSEMBLY...
  • Page 17 HANDLE ASSEMBLY ITEM PART NO. QTY. 1 ... 102984 ... 1 ... THUMB LATCH RT..102983 ... 1 ... THUMB LATCH LT.(NOT SHOWN) 2 ... 103005 ... 1 ... HANDLE W/DECAL 3 ... 102990 ... 1 ... CONTROL LEVER LT..

  • Page 18: Motion Control Assembly

    MOTION CONTROL ASSEMBLY...

  • Page 19: Motion Control Assembly

    MOTION CONTROL ASSEMBLY ITEM PART NO. QTY. DESCRIPTION 1 ... 100032 ... 12 ... FLANGED NYLON BUSHING 2 ... 102963 ... 1 ... TRACK WELDMENT, LT. 3 ... 100147 ... 1 ... KNOB 4 ... 102958 ... 1 ... TRAVEL LEVER 5 ...

  • Page 20: Front Caster Assembly

    FRONT CASTER...
  • Page 21 FRONT CASTER ITEM PART NO. QTY. DESCRIPTION 1 ... 101874 ... 1 ... 7/16 LYNCH PIN 2 ... 916561 ... 1 ... MACH. BUSHING 3 ... 101873 ... 5 ... "C"-SPACER 4 ... 101232 ... 2 ... FLANGE BUSHING 5 ... 101875 ... 1 ... CASTER ARM W/BUSHING 6 ...

  • Page 22: Wiring Harness

    HANDLE WIRING HARNESS HARNESS...

  • Page 23: Harness Diagram

    HANDLE WIRING DIAGRAM HARNESS DIAGRAM...

This manual is also suitable for:

Khkw48171

Table of Contents

Save PDF
