Yard Machines 41AFA16K900 Service Spare Parts List

SPECIFY MODEL NO. WHEN ORDERING PARTS
16" Hedge Trimmer
MODEL NO.
No. Parts No.
STK CODE
1 6059-203A01
2 6010-203A02
3 6028-203A06
4 6022-203A01
5 6010-203A01
6 6024-203A01
7 6038-203A05
8 6028-203A05
9 6261-203A01
10 6MB-608-01
11 6073-203A01
12 6250-203A02
13 6115-203A01
14 6112-203A01
15 6111-203A01
16 6216-203A01
SERVICE SPARE PARTS LIST
41AFA16K900/MTD16K
Description
TUBE
WIRE
TRIGGER
SWITCH
WIRE
SPRING
HOUSING (L)
TRIGGER
FIELD ASS'Y
BEARING
GEAR
16" BLADE
PIN
ECCENTRIC SHAFT
OUTPUT SHAFT
BRUSH
No. Parts No.
Q STK CODE
1 17 6159-203A01
1 18 6038-203A06
1 19 6041-840001
2 20 6SDABB04-14
1 21 6043-982002
1 22 6199-203A01
1 23 6011-203A01
1 24 6SDABB04-20
1 25 6017-203A02
4 26 6260-203A01
6262-203A01
1 27
1 28 6SVABB04-10
2 29 6252-203A02
1 30 6252-203A01
1 31 6097-203A20
2 32 6097-203A19
DATE
1/13/2006
Description
BRUSH HOLDER
HOUSING (R)
TERMINAL BLOCK
SCREW
STRAIN RELIEF
CORD GUARD
POWER CORD
SCREW
BLADE COVER
ARMATURE
COVER
SCREW
GASKET
GASKET
LABEL (R)
LABEL (L)
REVISED
DATE
N/A
Q
2
1
2
2
1
1
1
12
1
1
1
2
2
1
1
1
