3 ELIOS System specifications
AIRCRAFT
CONFIGURATION
DIMENSIONS
MOTORS
MOTOR POWER RATING
PROPELLERS
TAKE-OFF WEIGHT
MAX FLIGHT TIME
MAX ASCENT SPEED
MAX DESCENT SPEED
MAX SPEED
MAX PITCH/ROLL ANGLES
MAX WIND RESISTANCE
FLIGHT CONTROL SENSORS
MATERIALS
OPERATING TEMP.
FLIGHT MODES
FAIL-SAFE
OPERATING FREQUENCY
EIRP
INGRESS PROTECTION
NOISE LEVEL
SMART BATTERY
RATED CAPACITY
NOMINAL VOLTAGE
BATTERY TYPE
Additional precautions must be taken between 0-10ºC and 40-50ºC. Stability, flight performance
2
and flight time might be reduced.
ORIGINAL INSTRUCTIONS
Strictly confidential
Quadcopter
Fits in a < 400 mm sphere; 15.75 in
4 fast reversing electric brushless motors
120W average power, 750W nominal peak power
4 propellers, 5 inches
< 1450 g; < 3,2 lbs.
Includes battery, payload & protection
Up to 10 min
1.3 m/s; 4.3 ft/s
1.3 m/s; 4,3 ft/s
1.3 m/s (Assist mode); 4,3 ft/s
4 m/s (Atti mode); 13 ft/s
6.5 m/s (Sport mode); 21 ft/s
0.15 rad (Attitude mode)
0.2 rad (Assist mode)
0.3 rad (Sport mode)
3 m/s (Assist mode); 10 ft/s
5 m/s (Sport mode); 16,4 ft/s
IMU, magnetometer, barometer, 7 vision and distance sensors
Carbon fiber composites, magnesium alloy, aeronautical grade
aluminum, high-quality thermoplastics
2
0 ºC to 50 ºC * (32 °F to 122 °F)
ASSIST - Assist mode
ATTI - Attitude mode
SPORT - Sport mode
Auto-landing on signal lost
Forced-descent when battery critically low
2404 – 2483 MHz (UAV to RC)
2.4 GHz: ≤ 32 dBm (FCC); ≤20 dBm (CE); ≤10 dBm/MHz (MIC)
Splash and dust resistant
99 dB(A) hover
120 dB(A) max @ 1m
5200 mAh
19 V
LiPo 5S HV Smart Battery:
- Improved safety (protection for: overcharge, overcurrent, over/under-
temperature)
- Plug-and-play charging
- Self-balancing
- Storage self-discharge
3 – ELIOS System specifications
