2 Programs Dolby Surround (DOLBY PRO LOGIC and DOLBY PRO LOGIC ENHANCED)
Test Tone Generator for Easier Speaker Output Balance Adjustment
Thank you for selecting this YAMAHA stereo receiver.
OWNER'S MANUAL
CONTENTS
Safety Instructions ........................2
Supplied Accessories ...................4
Profile of This Unit .......................5
Connections .................................7
Operations .................................13
Tuning Operations ......................16
Preset Tuning ...................................17
(DSP) ...............................................20
Transmitter .......................................26
Troubleshooting .........................27
Specifications .............................28
80W + 80W (8Ω) RMS Output Power, 0.09% THD, 1 kHz (Front)
80W (8Ω) RMS Output Power, 0.1% THD, 1 kHz (Center)
15W + 15W (8Ω) RMS Output Power, 0.7% THD, 1 kHz (Rear)
4 Programs for Digital Sound Field Processing and
Automatic Input Balance Control for Dolby Surround
3 Center Channel Modes (NORMAL/WIDE/PHANTOM)
IF Count Direct PLL Synthesizer Tuning System
IMPORTANT!
Please record the serial number of this
unit in the space below.
Model:
Serial No.:
The serial number is located on the rear
of the unit.
Retain this Owner's Manual in a safe
place for future reference.
WARNING
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE
THIS UNIT TO RAIN OR MOISTURE.
R-V98

Natural Sound Stereo Receiver

5 Speaker Configuration
Digital Sound Field Processor
40-Station Random Preset Tuning
Automatic Preset Tuning
Preset Station Shifting Capability
Video Signal Input/Output Capability
Remote Control Capability
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK), NO USER-SERVICEABLE
PARTS INSIDE, REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
• Explanation of Graphical Symbols

SLEEP Timer

CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead
symbol, within an equilateral triangle,
is intended to alert you to the
presence of uninsulated "dangerous
voltage" within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended to alert
you to the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the
appliance.
