molex PicoBlade 1.25 DIP Application Specification

【1.APPLICATION】
HARNESS SIDE
ONBOARD SIDE
※ Please refer to crimp specification for further details.
― Before using ―
・
Be sure to read the following precautions before using connector.
・
Keep this manual for reference at any time.
・
The displays and illustrations shown in this manual are for illustrative purposes only and may differ
from the actual product.
・
The contents of this manual are subject to change without notice.
・If you find any mistake or there is anything that is not clear, please contact your sales representative.
REV. A
SHEET 1-58
REVISE ON PC ONLY
A
2018/11/02 S.OBARA
REV. DESCRIPTION
DESIGN CONTROL
J
DOCUMENT NUMBER
510210000-AS
APPLICATION SPECIFICATION
APPLICATION SPECIFICATION
PicoBlade 1.25 DIP TYPE & SMT TYPE
This application specification is written in English and Japanese.
本取扱説明書は、英文および和文で記載されております。
English 英文: Page 1~28
Japanese 和文: Page 29~57
RECEPTACLE HOUSING
RECEPTACLE CRIMP
TERMINAL
APPLICABLE WIRE（※）
APPLICABLE CRIMP DIE MODEL No. （※）
HEADER ASS'Y
DIP TYPE
HEADER ASS'Y
SMT TYPE
TITLE:
RELEASED
新規作成
602794
STATUS
Product Name
AWG#28-32
AWG#26-28
ST TYPE
R/A TYPE
ST TYPE
R/A TYPE
PicoBlade 1.25 DIP TYPE & SMT TYPE
APPLICATION SPECIFICATION
THIS DOCUMENT CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC
TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION
WRITTEN BY: CHECKED BY:
SOBARA01 A.IDA
DOC. TYPE DOC. PART
PS 000
Part Number
51021 series
50058 series
50079 series
AWG#26～32
Tin plated stranded wire
57067-3**0
53047 series
53048 series
53398 series
53261 series
DATE:
APPROVED BY:
2018/08/13
T.KANEKO
CUSTOMER
GENERAL
EN-127(2015-12 )
LANGUAGE
ENGLISH
JAPANESE
SHEET
1 OF 58
