Yamaha MCX-CA15 Owner's Manual

Distributed audio amplifier.
Hide thumbs

Advertisement

MCX-CA15
Distributed Audio Amplifier
MCX-CA15
MCX-CA15
AUDIO OUT
AUDIO IN
IR/CTRL
STATUS
SW OUT
VIDEO OUT
DC IN 12V
OWNER'S MANUAL
UB

Advertisement

   Related Manuals for Yamaha MCX-CA15

   Summary of Contents for Yamaha MCX-CA15

  • Page 1

    MCX-CA15 Distributed Audio Amplifier MCX-CA15 MCX-CA15 AUDIO OUT SW OUT AUDIO IN IR/CTRL VIDEO OUT DC IN 12V STATUS OWNER'S MANUAL...

  • Page 2

    This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements. Modifications not expressly approved by Yamaha may void your authority, granted by the FCC, to use the product. 2 IMPORTANT: When connecting this product to accessories and/or another product use only high quality shielded cables.

  • Page 3

    YAMAHA will not be held responsible for any damage resulting from use of these units with a voltage other than that specified.

  • Page 4

    These units are not disconnected from the AC power source as long as they are connected to the wall outlet, even if the unit itself is turned off. This state is called the sleep mode. In this state, these units are designed to consume a very small quantity of power.

  • Page 5: Table Of Contents

    SUPPLIED ACCESSORIES...3 CONTROLS AND FUNCTIONS ...4 Front panel... 4 Inside front panel ... 5 Rear panel ... 6 Bottom panel ... 7 USING THE MCX-CA15 OPERATION...8 Operation modes... 8 Input level sensing function... 11 RESET button... 11 ADDITIONAL INFORMATION TROUBLESHOOTING ...12 SPECIFICATIONS...13...

  • Page 6: Features

    Audio Controller (hereafter, the “client”) to complete the MusicCAST system, or as an amplifier integrated with an existing audio system. As a companion to your client, the MCX-CA15 is fully controllable from the client, and functions as a power amplifier and DC power distributor. It provides high-quality power to all connected speakers, and can display the client’s on-screen display (OSD) on a TV or monitor connected to...

  • Page 7: Supplied Accessories

    SUPPLIED ACCESSORIES After unpacking, check that you received all of the following parts. Owner’s Manual (this manual) MCX-CA15 Distributed Audio Amplifier MCX-CA15 MCX-CA15 AUDIO OUT SW OUT AUDIO IN IR/CTRL VIDEO OUT DC IN 12V STATUS OWNER'S MANUAL Pin/mini plug cable...

  • Page 8: Controls And Functions

    IR/CTRL jack Connect an IR flasher (infrared emitter) to this jack if you want to control a YAMAHA AV receiver registered on a client. When this unit is connected to a client, this jack functions as an IR output jack.

  • Page 9: Inside Front Panel

    Inside front panel A B C MODE MODE switch Switches between operation modes “A”, “B” and “C” (see page 10). RESET button Resets this unit after the protection circuitry has been activated or the operation mode has been changed (see page 11). INPUT SENSE Detects the presence of signals input through the AUDIO IN jack (see page 11).

  • Page 10: Rear Panel

    CONTROLS AND FUNCTIONS Rear panel SPEAKER OUT SPEAKER OUT terminals Connect speakers to these jacks using commercially available speaker cables. DC IN/OUT terminals When this unit is connected to a client only, connect the DC power cable to these terminals to supply power to the client.

  • Page 11: Bottom Panel

    Connect a client to this jack using the CAT-5 cable (straight) supplied with the client to input signals from the client. CONTROL OUT/IN jack Connect another MCX-CA15 or an external component to this jack to control the power of this unit. AV IN...

  • Page 12: Using The Mcx-ca15

    Mode A mode Use this mode if you want to use the MCX-CA15 as a companion to a client. In this mode you can also control a YAMAHA AV receiver connected to the MCX-CA15 or I/O box from the client’s A B C remote control using YAMAHA AV link technology.

  • Page 13

    “C” mode. In this case, this unit is capable of detecting signals within the range 3 to 30 V from these jacks. You can connect another MCX-CA15 or an external component to these jacks to control the power of this unit.

  • Page 14

    OPERATION To switch the operation mode You can switch between the operation modes on the MCX-CA15 by sliding the MODE switch located on the inside front panel to the left and right. CAUTION • Always check that the operation mode is set correctly before performing automatic or manual configuration on the client.

  • Page 15: Input Level Sensing Function

    • You have changed the operation mode using the MODE switch. Note When the MCX-CA15 is connected to a client and you want to reset the system, press and hold the client for ten seconds. OPERATION INPUT SENSE...

  • Page 16: Troubleshooting

    TROUBLESHOOTING Refer to the chart below if the MCX-CA15 does not function properly. If the problem you are experiencing is not listed below or if the instruction below does not help, disconnect the power cord, and contact the nearest authorized YAMAHA dealer or service center.

  • Page 17: Specifications

    AUDIO PERFORMANCE • Minimum RMS output power 1 kHz, 1% THD... 13 W + 13 W • Maximum power (EIAJ) 1 kHz, 10% THD...17 W + 17 W or 18 W (1 ch) • Frequency response (EIAJ) ...20 Hz to 20 kHz, ±1.0 dB •...

  • Page 20

    YAMAHA ELECTRONIQUE FRANCE S.A. RUE AMBROISE CROIZAT BP70 CROISSY-BEAUBOURG 77312 MARNE-LA-VALLEE CEDEX02, FRANCE YAMAHA ELECTRONICS (UK) LTD. YAMAHA HOUSE, 200 RICKMANSWORTH ROAD WATFORD, HERTS WD18 7GQ, ENGLAND YAMAHA SCANDINAVIA A.B. J A WETTERGRENS GATA 1, BOX 30053, 400 43 VÄSTRA FRÖLUNDA, SWEDEN Printed in Malaysia WD28630 YAMAHA MUSIC AUSTRALIA PTY, LTD.
