Yamaha DSP-AX2 Owner's Manual

Natural sound av amplifier.
Hide thumbs

Advertisement

DSP-AX2
Natural Sound AV Amplifier
Amplificateur Audio-Video
NATURAL SOUND AV AMPLIFIER DSP-AX2
STANDBY
/ON
SPEAKERS
A
B
SOURCE
DVD
MD/TAPE
D-TV/LD
CD-R
SILENT
CABLE
TUNER
SAT
CD
BASS
PROCESSOR
VCR 1
EXTENSION
DIRECT
PHONO
PHONES
VCR 2/DVR
VIDEO AUX
BASS
TREBLE
REC OUT
BEDIENUNGSANLEITUNG
MANUALE DI ISTRUZIONI
MANUAL DE INSTRUCCIONES
VOLUME
INPUT
INPUT MODE
EFFECT
S VIDEO
VIDEO
L
AUDIO
R
OPTICAL
6CH
INPUT
VIDEO AUX
DSP PROGRAM
OWNER'S MANUAL
MODE D'EMPLOI
BRUKSANVISNING
GEBRUIKSAANWIJZING
GB

Advertisement

Chapters

   Also See for Yamaha DSP-AX2

   Related Manuals for Yamaha DSP-AX2

   Summary of Contents for Yamaha DSP-AX2

  • Page 1

    DSP-AX2 Natural Sound AV Amplifier Amplificateur Audio-Video INPUT MODE NATURAL SOUND AV AMPLIFIER DSP-AX2 STANDBY SPEAKERS EFFECT SOURCE MD/TAPE D-TV/LD CD-R SILENT CABLE TUNER S VIDEO VIDEO BASS PROCESSOR VCR 1 EXTENSION DIRECT PHONO INPUT PHONES VCR 2/DVR VIDEO AUX...

  • Page 2

    YAMAHA will not be held responsible for any damage resulting from use of this unit with a voltage other than specified.

  • Page 3: Table Of Contents

    Contents Introduction Getting Started ... 3 Controls and Functions ... 4 Preparations Speaker System Configurations ... 9 Hookups ... 10 On-Screen Displays (OSD) ... 19 Speaker Placement ... 20 Speaker Settings ... 21 Speaker Output Levels ... 22 Basic Operation Basic Playback ...

  • Page 4: Introduction

    Introduction Welcome to the exciting world of digital home entertainment. This unit is the most complete and advanced AV amplifier available. Though some of the more advanced features of this unit may not be familiar to you, they are easy to use. Incorporated state-of-the-art technology such as Dolby Digital and DTS can bring the same audio experience to your home as they have brought to feature films in quality theaters around the world.

  • Page 5: Getting Started

    The sensor may not be able to receive signals properly when it is exposed to direct sunlight or a strong artificial light (such as a fluorescent or strobe light). In this case, change the direction of the light or reposition the main unit to avoid direct lighting. VOLUME INPUT INPUT MODE NATURAL SOUND AV AMPLIFIER DSP-AX2 STANDBY SPEAKERS EFFECT SOURCE...

  • Page 6: Controls And Functions

    Front Panel When you are not operating the controls behind the front panel door, close the door. To open the door, press gently on the lower part of the panel. NATURAL SOUND AV AMPLIFIER DSP-AX2 STANDBY SILENT BASS EXTENSION PHONES...

  • Page 7: Display Indicators

    q TREBLE Adjusts the high frequency response for the left and right Main channels. Turn the control to the right to increase the high frequency response. w REC OUT Selects the source you want to direct to the audio/video recorder. e EFFECT Switches the effect speakers (Center, Front Effect, Rear and Rear Center) on and off.

  • Page 8: Rear Panel

    Controls and Functions Rear panel MD/TAPE OPTICAL TUNER 1 Audio component jacks 2 Video component jacks 4 Speaker terminals 5 AC OUTLETS Use these outlets to supply power to your other audio/video component. 6 IMPEDANCE SELECTOR 7 DIGITAL OPTICAL/COAXIAL jacks CAUTION SEE INSTRUCTION MANUAL FOR CORRECT SETTING.

  • Page 9: Remote Control

    Remote Control 1 CLEAR Erases the content of learning. 2 RE-NAME Renames the input name. 3 TRANSMIT Flashes while the remote control is sending signals. 4 LEARN Starts the learning function. 5 MACRO Makes the MACRO setting. 6 MACRO ON/OFF Turns the macro function on and off.

  • Page 10: Preparations

    Preparations Speaker System Configurations Hookups Connecting Audio Components ... 10 Connecting Video Components ... 12 Connecting Speakers ... 14 Connecting Subwoofers ... 16 Connecting an External Decoder ... 17 Connecting External Amplifiers ... 17 Others ... 18 On-Screen Displays (OSD) OSD Modes ...

  • Page 11: Speaker System Configurations

    Speaker System Configurations The most complete speaker configuration consists of eight speakers: the left and right Main speakers, a Center speaker, the left and right Rear speakers, the left and right Front Effect speakers, and a Rear Center speaker. If you do not use eight speakers, you can direct the signals for speakers that are not in your system to other speakers in your configuration.

  • Page 12: Hookups

    When you connect other YAMAHA audio component (such as a CD player or changer, MD deck, or tape deck), connect to terminals with the same number labels. Yamaha applies this labelling system to all its products.

  • Page 13

    OUTPUT <Analog> CD recorder INPUT <Analog> OPTICAL OPTICAL INPUT OUTPUT <Digital> <Digital> <Digital> OPTICAL OUTPUT OUTPUT CD player <Analog> COAXIAL <Digital> OUTPUT OUTPUT <Analog> Turntable GROUND OPTICAL MD/TAPE INPUT recorder INPUT OUTPUT OPTICAL OUT (REC) OUT (REC) OPTICAL Hookups (General and China models) CENTER to/from External Amplifier...

  • Page 14: Connecting Video Components

    Hookups Connecting Video Components Before you connect any components, disconnect the power supply to all the components you plan to connect including this unit and determine which jacks are for the left and right channels and for input and output. After you finish all hookups, check them again to make sure they are correct.

  • Page 15

    COMPONENT <Video> OUTPUT VIDEO S VIDEO AUDIO OUTPUT OUTPUT OUTPUT DTV/LD player <Analog> OPTICAL <Digital> OUTPUT OUTPUT <Analog> AUDIO SAT OPTICAL OUTPUT <Digital> OUTPUT Cable TV/SAT <Digital> CABLE COAXIAL OUTPUT S VIDEO VIDEO OUTPUT OUTPUT <Video> <RF> RF-Signal Output* (General and China models only) * <U.K.

  • Page 16: Connecting Speakers

    Hookups Connecting Speakers This section explains how to connect speakers to this unit. After you finish connecting your speakers, use the SET MENU to change the signal output settings according to the number and size of the speakers in your configuration. Before connecting any speaker cords, identify which terminals are for the right and left channels and also the + and –...

  • Page 17

    Right Front Speaker Right Rear Speaker CAUTION SEE INSTRUCTION MANUAL FOR CORRECT SETTING. Subwoofer Right Main B Left Main B system Speaker Speaker Left Front Speaker Left Rear Speaker Rear Center Speaker VOLTAGE SELECTOR IMPEDANCE SELECTOR SET BEFORE POWER ON FRONT : 6 MIN./SPEAKER REAR...

  • Page 18: Connecting Subwoofers

    Hookups Connecting Subwoofers CENTER Subwoofer system Subwoofer system Right Rear Speaker Connecting a front subwoofer Connect the signal input jack on your subwoofer to one of the PRE OUT/ MAIN IN SUBWOOFER jacks. Notes: • The SUBWOOFER jacks (output) have a built-in high cut-off filter (90 Hz). When using a powered subwoofer, set the high cut-off frequency to “MAX”...

  • Page 19: Connecting An External Decoder

    Connecting an External Decoder This unit is equipped with six additional input jacks (left and right MAIN, CENTER, left and right SURROUND and SUBWOOFER) for discrete multi-channel input from an external decoder, sound processor, or pre-amplifier. Connect the output jacks on your external decoder to the 6CH INPUT jacks.

  • Page 20: Others

    Hookups Others WARNING Do not change the IMPEDANCE SELECTOR switch setting while the power to this unit is on, otherwise this unit may be damaged. IF THIS UNIT FAILS TO TURN ON WHEN THE STANDBY/ON SWITCH IS PRESSED: The IMPEDANCE SELECTOR switch may not be set to either end.

  • Page 21: On-screen Displays (osd)

    You can display the operation information for this unit on a video monitor. If you display the SET MENU and DSP sound field program parameter settings on a screen, it is much easier to see the available options and parameters than it is by reading this information on the front panel display.

  • Page 22: Speaker Placement

    Where you place your speakers has a tremendous effect on how well your system sounds. TV or Video Main monitor Main Speaker Speaker TV or Video monitor Center Speaker 0.5~1m 1.5~3m 0.5~1m (3ft) (1~3ft) (5~15ft) (1~3ft) Front Effect speakers Rear speakers Main speakers Center Speaker...

  • Page 23: Speaker Settings

    This unit has seven SPEAKER SET items in the SET MENU that you must set according to the number of speakers in your configuration and their size. The following table summarizes these SPEAKER SET items, and shows the initial settings as well as other possible settings. If the initial settings are not appropriate for your speaker configuration, change the settings in the SET MENU.

  • Page 24: Speaker Output Levels

    This section explains how to set the speaker levels using the test tone. There are two tests; Dolby Surround test and DSP test. Before You Begin BASS TREBLE Dolby Surround Test TEST DOLBY SUR. EFFECT LEVEL L SUR. EFFECT LEVEL L SUR.

  • Page 25: Dsp Test

    DSP Test TEST MAIN TEST DSP EFFECT LEVEL FRONT EFFECT LEVEL FRONT 1 After the dsp test is selected, “TEST DSP” appears on the video monitor and in the front display. 2 Adjust VOLUME +/– to hear the test tone. Make an adjustment so that the output level coming from the Front Effect speakers is the same as that of the Main speakers.

  • Page 26: Basic Operation

    Basic Operation Basic Playback Power Control ... 25 Selecting a Source ... 26 Input Modes and Indications ... 27 Selecting a Sound Field Program ... 28 Basic Recording Preparations ... 29...

  • Page 27: Basic Playback

    Playback operation is described with buttons on this unit and the remote control. These button names are noted in the order of “button name (remote control button name).” STANDBY SYSTEM POWER Input buttons Power Control STANDBY STANDBY Basic Playback STANDBY/ON NATURAL SOUND AV AMPLIFIER DSP-AX2 STANDBY SPEAKERS D-TV/LD SILENT CABLE BASS PROCESSOR VCR 1 EXTENSION DIRECT PHONES...

  • Page 28: Selecting A Source

    Basic Playback Selecting a Source INPUT The selected source D-TV/LD CABLE MD/TAPE CD-R VCR 1 TUNER VCR2/DVR V-AUX PHONO VOLUME 1 Select the source using the INPUT selector, or press one of the input buttons on the remote control. • The current source is indicated on the front panel display with an arrow. •...

  • Page 29: Input Modes And Indications

    Input Modes and Indications This unit comes with various input jacks. If your external component is connected to more than one type of input jack, you can set the priority of the input signal. Press INPUT MODE on the front panel or an input button (press it repeatedly) on the remote control to display or change the input mode.

  • Page 30: Selecting A Sound Field Program

    Basic Playback Selecting a Sound Field Program You can enhance your listening experience by selecting a DSP sound field program. The 25 DSP sound field programs are divided into 12 DSP program groups. 10KEY/DSP 6.1/ES If you want to utilize the Rear Center speaker with a 5.1 channel program source, press 6.1/ Hi-Fi DSP Programs Concert Hall 1...

  • Page 31: Basic Recording

    REC OUT allows you to record one source while viewing and/or listening to another source. Preparations STANDBY SOURCE MD/TAPE D-TV/LD CD-R CABLE TUNER VCR 1 PHONO VCR 2/DVR VIDEO AUX REC OUT Basic Recording 1 Turn on the power to this unit and all connected component. 2 Select the source component you want to record using REC OUT.

  • Page 32: Advanced Operation

    Advanced Operation SET MENU Items Operating the SET MENU ... 32 1. SPEAKER SET (1A. CENTER SP to 1G. MAIN LEVEL) ... 33 2. LOW FREQ. TEST ... 35 3. L/R BALANCE ... 36 4. HP TONE CTRL (Headphone Tone Control) ... 36 5.

  • Page 33: Set Menu Items

    The SET MENU consists of sixteen items including the Speaker Set, Center Graphic Equalizer and Parameter Initialization features. Choose the appropriate item and adjust or select the values as necessary. Notes: • You can adjust the items in the SET MENU while reproducing a source. •...

  • Page 34: Operating The Set Menu

    SET MENU Items Operating the SET MENU Adjustment should be performed with the remote control. Some items require extra steps to change to the desired setting. 1 Set PARAMETER/SET MENU to SET MENU. 2 Press h or g repeatedly to select an item from the table of SET MENU, then press + or – to enter the setting of that item. •...

  • Page 35: Speaker Set (1a. Center Sp To 1g. Main Level)

    1. SPEAKER SET (1A. CENTER SP to 1G. MAIN LEVEL) Use this feature to select suitable output modes for your speaker configuration. You must set the output mode when you use a subwoofer. 1A. CENTER SP (Center Speaker Mode) By adding a Center speaker to your speaker configuration, this unit can provide good dialogue localization for many listeners and superior synchronization of sound and images.

  • Page 36

    SET MENU Items 1D. REAR CT SP (Rear Center Speaker Mode) By adding a Rear Center speaker to your speaker configuration, this unit can provide more realistic front-to-back and back-to-front transitions. The initial setting is “LRG”. Select the “LRG” setting if you have a large Rear Center speaker. The entire range of Rear Center channel signals is sent to the Rear Center speakers.

  • Page 37: Low Freq. Test

    1G. MAIN LEVEL Change this setting if you cannot match the sound volume of the Front, Rear, and Center speakers with the Main speakers because of the unusually high efficiency performance of the Main speakers. The initial setting is “Normal”. Select the “Normal”...

  • Page 38: L/r Balance

    SET MENU Items 3. L/R BALANCE 3 L/R BALANCE 4. HP TONE CTRL (Headphone Tone Control) 4 HP TONE CTRL __________ 4 HP TONE BASS BASS TRBL - -------- + 4 HP TONE TRBL 5. CENTER GEQ (Center Graphic Equalizer) 5 CENTER GEQ _________ ≥...

  • Page 39: I/o Assign

    7. I/O ASSIGN Use this feature to designate the input for the COMPONENT jacks (A and B) and DIGITAL INPUT/OUTPUT jacks (1) to (10)* to any sources you want. Change the setting when there are not enough digital input jacks depending on the source components you are using. (*(10) can be selected for General and China models only.) Initial settings are shown on the display.

  • Page 40: Lfe Level

    SET MENU Items 10. DOLBY D. SET (Dolby Digital Set) 10A LFE LEVEL ≥ SPEAKER………………0dB HEADPHONE…………0dB 10A LFE LEVEL SP………………0dB 10B D-RANGE ≥ SP:>MAX STD MIN HP:>MAX STD MIN 10B D-RANGE SP:“MAX STD MIN 11. DTS SET 11 LFE LEVEL ≥...

  • Page 41: 13. Sp Delay Time

    13. SP DELAY TIME 13 SP DELAY TIME ≥ CENTER………………0ms REAR CNTR………3ms 13 SP DLY TIME CENTER………………0ms 14. DISPLAY SET 14 DISPLAY SET ≥ BLUE BACK………AUTO OSD SHIFT………………0 14 DISPLAY SET DIMMER………………………0 BLUE BACK……AUTO 15. MEMORY GUARD 15 MEMORY GUARD >OFF 15 MEMORY GUARD “OFF...

  • Page 42: Remote Control Features

    The remote control can operate not only the main unit but also other Yamaha and other manufactures’ audio and video components by using the Learning function and other manufactures’ code settings. The Macro feature also improves the operability of this unit allowing you to program a series of operations in sequence onto a single button.

  • Page 43: Source Select

    SOURCE SELECT You can control another component independently from the input you selected by pressing an input button. 1 Press SOURCE SELECT h or g to choose a component and set the remote control to be used for it. 2 The display window will show one of the following: V-AUX, TAPE, PHONO, TUNER, MD, CD, VCR 1, VCR 2, DVD, CD-R, CABLE (Cable TV), SAT (Satellite TV), A, TV/LD (digital and regular TV/LD player), OPTN (Option).

  • Page 44: Each Component Control Area

    Remote Control Features Each Component Control Area The general operational buttons are shown for each area. Some of them may not function depending on the component you have. TUNER button (Tuner area) (Set 10KEY) POWER Preset number 1 to 8 Preset group A through E from left.

  • Page 45

    PHONO and V-AUX buttons, and OPTN area* (Set 10KEY) TV VOL +/–, TV INPUT, and TV MUTE function if you have set up the manufacturer code for the TV Area. *2 Operational buttons do not work without setting the manufacturer code for the source component.

  • Page 46

    Remote Control Features CABLE and SAT buttons (CABLE and SAT areas* DISPLAY MENU Menu cursor/ENTER You can control your VCR, if you have set up the code for VCR1. POWER Numeric buttons 1 to 9 Recall Numeric button 0 CH +/– TV VOL +/–, TV INPUT, and TV Enter MUTE function if you have set up...

  • Page 47: Setting The Manufacturer Code In The Remote Control

    You can control other components by setting a manufacturer code. A code can be set up in each component control area except for the OPTN area. The Yamaha code is factory preset for DVD, CD-R, CD, MD, TUNER, and Å (LD code). There is no factory preset code on VCR1, VCR2/DVR, V-AUX, PHONO, TAPE, CABLE, SAT.

  • Page 48: Programming A New Remote Control Function

    Remote Control Features Programming a New Remote Control Function If you desire to program functions not included in the basic operations covered by the manufacturer code, or a manufacturer code is not available, the following procedure needs to be performed. The possible programming area is the same as a component control area, so buttons are programmable independently for each source component area.

  • Page 49: Using The Macro Feature

    *3 The components for which playback can be started are any YAMAHA remote control-compatible MD recorders, CD players, CD recorders, and DVD players. When using macros to operate components other than these or non-YAMAHA components, it is either necessary to learn the PLAY button on the control area of that component or to setup a manufacturer code.

  • Page 50

    Remote Control Features Operating the Macro feature MACRO ON/OFF Programming a Macro You can use the Macro feature to transmit many remote control commands by pressing a single button. MACRO MACRO Notes: • “NG” appears in the display window when programming is not done correctly. •...

  • Page 51: Changing The Source Name In The Display Window

    Changing the Source Name in the Display Window RE-NAME RE-NAME Clearing a Learned Function or Macro MACRO LEARN CLEAR While pressing Flashes alternately MACRO LEARN 1 Select the source component you want to rename by using the input buttons. 2 Press RE-NAME using a ballpoint pen or similar object. 3 Use the cursor buttons h/g to select a character.

  • Page 52: Clearing Learned Functions And Setups

    Remote Control Features Clearing Learned Functions and Setups CLEAR For example, when DVD is selected as the source component. CLEAR CLEAR Notes: • If the remote control is without batteries for more than twenty minutes, or if worn out batteries remain in the unit, the contents of the memory may be cleared.

  • Page 53: Adjusting The Levels Of The Effect Speakers

    Adjusting the Levels of the Effect Speakers You can adjust the volume level of each effect speaker (Center, Right Rear, Rear Center, Left Rear, Front Effect, and Subwoofer) while listening to a music source. Center EFFECT LEVEL CENTER Right Rear EFFECT LEVEL R SUR.

  • Page 54: Additional Information

    Additional Information Digital Sound Field Processing (DSP) Understanding Sound Fields ... 53 Hi-Fi DSP Programs ... 54 CINEMA-DSP Sound Design of CINEMA-DSP ... 55 CINEMA-DSP Programs ... 56 DSP Parameter Changing Parameter Settings ... 58 Parameter Descriptions ... 58 Resetting to the Factory Preset Value ... 61...

  • Page 55: Digital Sound Field Processing (dsp)

    This type of program consists of early reflections and high quality digital reverberation processing. Reverberation is the most important element for recreating the sound field of a church, for example. To recreate a realistic spatial sound image from reverberation data, Yamaha has adapted the four-channel-output reverberation technology.

  • Page 56: Hi-fi Dsp Programs

    Digital Sound Field Processing (DSP) Hi-Fi DSP Programs Concert Hall 1 Europe Hall A This is a large fan-shaped concert hall with approximately 2500 seats. There is relatively little reflection from the walls, and sound spreads finely and beautifully. Concert Hall 2 U.S.A.

  • Page 57: Cinema-dsp

    CINEMA-DSP is an upgraded version of YAMAHA DSP specially designed for movie soundtracks. CINEMA-DSP integrates the DTS, Dolby Digital, and Dolby Pro Logic surround sound technologies with YAMAHA DSP sound field programs to provide the surround sound field. It recreates the most complete movie sound design in your audio room. In CINEMA-DSP sound field programs, Yamaha’s exclusive DSP processing is added to the right and left Main and Center channels, so the listener can enjoy realistic dialogue, depth of sound, smooth transition between sound sources, and a surround sound field that goes beyond the screen.

  • Page 58: Cinema-dsp Programs

    CINEMA-DSP CINEMA-DSP Programs According to the input signal format, this unit automatically chooses the appropriate decoder and DSP sound field pattern. Table of Program Names for Each Input Format Input Stereo Program (2ch) Group ENTERTAINMENT Game Classical/Opera CONCERT VIDEO Pop/Rock Mono Movie TV THEATER Variety/Sports...

  • Page 59: Concert Video

    Entertainment Game This program adds a deep and spatial feeling to video game sounds. Concert Video Classical/Opera This program provides excellent vocal depth and overall clarity by restraining excessive reverberation. The surround sound field is relatively moderate but it reproduces beautiful sound using data collected from a concert hall.

  • Page 60: Dsp Parameter

    You can enjoy good quality sound with the preset parameters. Although you do not have to change the initial settings, you can change some of the parameters to better suit the input source or your listening room. Changing Parameter Settings Program Type (subprogram) Program No.

  • Page 61: Room Size

    ROOM SIZE [P. ROOM SIZE for the presence sound field Function ... This parameter adjusts the apparent size of the surround sound field. The larger the value, the larger the surround sound field becomes. Description ... As the sound is repeatedly reflected around a room, the larger the hall is, the longer the time between the original reflected sound and the subsequent reflections.

  • Page 62

    DSP Parameter S. LIVENESS (Surround Liveness) Function ... This parameter adjusts the apparent reflectivity of the virtual walls in the surround sound field. RC. INIT. DLY (Rear Center Initial Delay) Function ... This parameter adjusts the delay between the direct sound and the first reflection in the rear center sound field. RC.

  • Page 63: Resetting To The Factory Preset Value

    REV. LEVEL (Reverberation Level) Function ... This parameter adjusts the volume of the reverberation sound. Description ... The larger the value, the stronger the reverberation becomes. CT. DELAY (Center Delay) Function ... These parameters adjust the sound delay for each channel in 8 channel stereo mode. LS.

  • Page 64: Appendix

    Appendix Troubleshooting Specifications...

  • Page 65: Troubleshooting

    Refer to the chart below when this unit does not function properly. If the problem you are experiencing is not listed below or if the instruction below does not help, turn the power off, disconnect the power cord, and contact your dealer or the nearest Yamaha Audio Products Service Department.

  • Page 66

    Troubleshooting Problem No sound is coming from the PRO LOGIC/Normal, DOLBY DIGITAL/ Front Effect speakers. Normal or DTS DIGITAL SUR./Normal of DSP program 12 is selected. The front level is set to minimum. The 1F. FRNT EFCT item in the SET MENU is set to “NONE”.

  • Page 67

    Remote Control Problem The remote control does not The batteries are dead. work. The internal microcomputer has “frozen”. The remote control does not Wrong distance or angle. function properly. Direct sunlight or lighting (such as an inverter type of fluorescent lamp) is striking the remote control sensor of this unit.

  • Page 68: Specifications

    Audio Section Minimum RMS Output Power 20 Hz to 20 kHz, 0.02% THD, 8 ohms Main L/R, Center, Rear L/R, Rear Center ... 100 W 1 kHz, 0.05% THD Front L/R ... 25 W <General and China models> Maximum Output Power (EIAJ) 1 kHz, 10% THD, 8 ohms Main L/R, Center, Rear L/R, Rear Center ...

  • Page 69

    YAMAHA ELECTRONICS (UK) LTD. YAMAHA HOUSE, 200 RICKMANSWORTH ROAD WATFORD, HERTS WD1 7JS, ENGLAND YAMAHA SCANDINAVIA A.B. J A WETTERGRENS GATA 1, BOX 30053, 400 43 VÄSTRA FRÖLUNDA, SWEDEN YAMAHA MUSIC AUSTRALIA PTY, LTD. 17-33 MARKET ST., SOUTH MELBOURNE, 3205 VIC., AUSTRALIA...

  • Page 70

    Quick Reference Card Remote Control Infrared window CLEAR LEARN MACRO RE-NAME TRANSMIT MACRO ON/OFF STANDBY SYSTEM POWER button Input buttons 6CH INPUT Display Source selector LIGHT Operational buttons 10 KEY/DSP Sound program selector/ Numeric buttons MUTE VOLUME +/– Operational buttons EFFECT LEVEL PARAMETER/SET MENU...

  • Page 71

    Quick Reference Card PHONO and V-AUX buttons, and OPTN area (Set 10KEY) TV VOL +/–, TV INPUT, and TV MUTE function if you have set up the manufacturer code for the TV Area. DVD button (DVD area) DISPLAY MENU TITLE Menu cursor/ENTER SOUND Skip Search...
