  • Page 1 HeiTel™ by Xtralis Integration of Dahua HDCVI Encoders July, 2017 Doc. 33001_00...
  • Page 2 This document includes registered and unregistered trademarks. All trademarks displayed are the trademarks of their respective owners. Your use of this document does not constitute or create a licence or any other right to use the name and/or trademark and/or label. This document is subject to copyright owned by Xtralis. You agree not to copy, communicate to the public, adapt, distribute, transfer, sell, modify or publish any contents of this document without the express prior written consent of Xtralis.
  • Page 3 Integration of Dahua HDCVI Encoders HeiTel by Xtralis Technical Product Information HNVR, CamDisc(+) E, ipVG Product/Version Date August 2017 Subject Integration of Dahua HDCVI Encoders Summary Integration of Dahua HDCVI Encoders Connecting HDCVI analogue cameras using a Dahua HDCVI Encoder...

  • Page 4: Table Of Contents

    HeiTel by Xtralis Integration of Dahua HDCVI Encoders Contents Introduction..........................2 Background ........................2 Prerequisites ........................2 Overview ..........................2 Install Dahua HDCVI Encoder ....................3 Camera configuration in CamControl LITE ................4 Basic configuration ......................4 Advanced settings ......................5 Check settings ..........................

  • Page 5: Introduction

    The following hardware and software are required for operation of a Dahua HDCVI Encoder:  One of the HeiTel devices listed above, with up-to-date firmware  For video systems with older firmware versions a firmware update must be carried out first.

  • Page 6: Install Dahua Hdcvi Encoder

    The Dahua device is connected to the HeiTel device via IP connection.  The HeiTel device sends the data via per IP connection (and switch) to the CamControl LITE software, CamControl PRO software respectively. The CamControl LITE software is used for configuration and video evaluation and analysis.

  • Page 7: Camera Configuration In Camcontrol Lite

    This chapter describes the configuration of the cameras connected to the Dahua device using the CamControl LITE software. Note: To each of the 10 camera channels available on the HeiTel device one camera connected to the Dahua device can be assigned to. Basic configuration Proceed as follows: Connect to the HeiTel device to which the Dahua device is connected.

  • Page 8: Advanced Settings

    Moreover, such settings will result in problems with PTZ presets. The Dahua device stores its own Preset list for each of the cameras but the HeiTel device can only manage one Preset list per camera channel. The HeiTel transmitter will always use the Preset list of the Live stream (CamControl LITE) as reference. But this reference then always applies when calling up presets via: ...

  • Page 9: Check Settings

    Integration of Dahua HDCVI Encoders HeiTel by Xtralis Check settings When having completed the setup of the individual cameras check the functioning. The main focus in this respect is to make sure that one camera channel always shows (or records) video of one and the same camera.

  • Page 10: Troubleshooting

    HeiTel by Xtralis Integration of Dahua HDCVI Encoders Troubleshooting This section describes remedial action for common error patterns which may result from improper configuration or setup. Alarm tone at the Dahua device (no HDD) Depending on the configuration, operating the Dahua Encoder without hard disk might result in a continuous alarm (alarm tone).
  • Page 11 Integration of Dahua HDCVI Encoders HeiTel by Xtralis www.xtralis.com UK and Europe +44 1442 242 330 D-A-CH +49 431 23284 1 The Americas +1 781 740 2223 Middle East +962 6 588 5622 Asia +86 21 5240 0077 Australia and New Zealand +61 3 9936 7000 A Disclaimer about this document, statements about Intellectual Property, Copyrights, and Liability, as well as a General Warning are available in an earlier section of this document.
