- Page 1 NX-SW10 Subwoofer/Center Speaker/Rear Speakers Caisson de grave/Enceinte centrale/ Enceintes arriere OWNER’S MANUAL MODE D’EMPLOI MANUAL DE INSTRUCCIONES...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. • Explanation of Graphical Symbols The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert you to the presence of uninsulated... - Page 3 This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements. Modifications not expressly approved by Yamaha may void your authority, granted by the FCC, to use the product. 2. IMPORTANT : When connecting this product to accessories and/or another product use only high quality shielded cables.
- Page 4 11 Secure placement or installation is the owner’s responsibility. YAMAHA shall not be liable for any accident caused by improper placement or installation of speakers. For SW-VS10 12 Never open the cabinet. If something drops into the set, contact your dealer.
-
Page 5: Table Of Contents
Refer to the VS-10 (sold separately) owner’s manual. Advanced YST v This subwoofer incorporates advanced YAMAHA Active Servo Technology to achieve superior bass reproduction. Checking the Package Contents Check that the following accessories are included in the package. -
Page 6: Speaker Placement
Rear speakers (NX-VS10E) Depending on room conditions, it is possible to place YAMAHA rear speakers NX-VS10E on shelves or hang them on the wall. For the installation of the rear speakers, refer to page 7. -
Page 7: Connections
CAUTION Always be sure to turn off the power of any component to be connected when making connections. To ensure proper connections • Be sure all connections are made correctly, that is to say L (left) to L, R (right) to R, “+” to “+” and “–” to “–”. Some components require different connection methods and have different terminal names. - Page 8 CONNECTIONS Connecting the speaker cords to the speaker terminals on the subwoofer Bare wire Connecting the speaker cords to the speaker terminals on the center speaker and the rear speakers Open the tab for the + terminal (red) or the – terminal (black).
- Page 9 Connecting the Subwoofer to the VS-10 Connect the SYSTEM CONNECTOR terminal on the VS-10 (sold separately) to the SYSTEM CONNECTOR terminal on the subwoofer using the system connector cable. Match the mark on the plugs with those on the terminals and insert the plugs. VS-10 (sold separately) VIDEO SIGNAL MONITOR...
-
Page 10: Installation Of The Center Speaker
INSTALLATION OF THE CENTER SPEAKER To prevent the center speaker from falling, secure it with the supplied velcro strips when placing it on a television or other device. Using the Velcro Strips Precautions before installation • Do not touch the adhesive surface after peeling off the strip as this will weaken its adhesive strength. •... -
Page 11: Installation Of The Rear Speakers
INSTALLATION OF THE REAR SPEAKERS Use the supplied type A wall brackets when hanging the rear speakers on a wall. Attach two commercially available wood screws (diameter about 4 mm) in the location on the wall where the rear speaker is to be hung, and then mount the type A bracket on the wood screws. - Page 12 • Secure the speaker cords so that they will not catch on hands or feet, causing speakers to drop. • Be absolutely sure to check for safety after speakers are mounted. YAMAHA bears no responsibility for damage caused due to improper installation or installation in an improper location.
-
Page 13: Troubleshooting
Be sure to investigate thoroughly before requesting repairs or after service. If it cannot be corrected, or if the problem is not listed in the SYMPTOM column, disconnect the power cord and contact your authorized YAMAHA dealer or service center. -
Page 14: Specifications
Center speaker ... 40 W (1 kHz, 10% THD, 6 ohms) Rear speakers ... 25 W x 2 (1 kHz, 10% THD, 6 ohms) Subwoofer (SW-VS10) Type ... Advanced YAMAHA Active Servo Technology System Speaker ... 16-cm cone, magnetically shielded Maximum Input Power ... 50 W Impedance ... - Page 15 YAMAHA ELECTRONICS (UK) LTD. YAMAHA HOUSE, 200 RICKMANSWORTH ROAD WATFORD, HERTS WD1 7JS, ENGLAND YAMAHA SCANDINAVIA A.B. J A WETTERGRENS GATA 1, BOX 30053, 400 43 VÄSTRA FRÖLUNDA, SWEDEN YAMAHA MUSIC AUSTRALIA PTY, LTD. 17-33 MARKET ST., SOUTH MELBOURNE, 3205 VIC., AUSTRALIA...
