Yamaha CC-70W Owner's Manual

Natural sound mini component system.
Hide thumbs

Advertisement

CC-70W / CC-70S
CC-70W is composed of RX-S70, CDC-S90, KXW-S70 and NX-S70.
CC-70S is composed of RX-S70, CDC-S90, KX-S90 and NX-S70.
* For U.K. and Europe models, NX-S70 is optional in some areas.
OWNER'S MANUAL
CONTENTS
SAFETY INSTRUCTIONS.......................Inside Front Cover-1
INTRODUCTION....................................................................2
FEATURES ............................................................................2
SUPPLIED ACCESSORIES...................................................2
PRECAUTIONS ..................................................................2-3
REAR PANEL PARTS.........................................................4-6
REMOTE CONTROL TRANSMITTER ................................7-9
(for Speaker System NX-S70 only).........................................9
PREPARATION FOR USE..............................................10-11
OPEN/CLOSE THE CONTROL DOOR................................12
SETTING THE CLOCK.........................................................13
SOUND CONTROL ..............................................................14
Natural Sound Mini Component System
Page
COMPACT DISC PLAYER OPERATION........................14-21
TUNING OPERATION.....................................................22-24
(for KXW-S70 Double Cassette Deck) ............................25-28
(for KX-S90 Single Cassette Deck) .................................29-31
RECORDING COMPACT DISCS....................................32-37
OTHER RECORDINGS...................................................38-39
HOW TO USE THE BUILT-IN TIMER .............................40-43
USING EXTERNAL UNITS .............................................44-45
MAINTENANCE....................................................................45
SPECIFICATIONS................................................................46
TROUBLESHOOTING..........................................................47
(for Speaker System NX-S70 only).......................................48
IMPORTANT!
Please record the serial number of this unit in the
space below.
Model:
Serial No.:
The serial number is located on the rear of the
unit.
Retain this Owner's Manual in a safe place for
future reference.
Active Servo
Technology
Page

Advertisement

   Also See for Yamaha CC-70W

   Related Manuals for Yamaha CC-70W

   Summary of Contents for Yamaha CC-70W

  • Page 1: Table Of Contents

    CC-70W / CC-70S CC-70W is composed of RX-S70, CDC-S90, KXW-S70 and NX-S70. CC-70S is composed of RX-S70, CDC-S90, KX-S90 and NX-S70. * For U.K. and Europe models, NX-S70 is optional in some areas. OWNER’S MANUAL CONTENTS SAFETY INSTRUCTIONS...Inside Front Cover-1 INTRODUCTION...2...

  • Page 2: Safety Instructions

    SAFETY INSTRUCTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. • Explanation of Graphical Symbols The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert you to the presence of uninsulated “dangerous...

  • Page 3

    This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements. Modifications not expressly approved by Yamaha may void your authority, granted by the FCC, to use the product. 2. IMPORTANT : When connecting this product to accessories and/or another product use only high quality shielded cables.

  • Page 4: Introduction

    INTRODUCTION Thank you for purchasing this YAMAHA product. We hope it will give you many years of trouble-free enjoyment. For the best performance, read this manual carefully. It will guide you in operating your YAMAHA product. This Owner’s Manual covers two models of tape deck, KXW-S70 and KX-S90. So please check the model name of your tape deck and use this owner’s manual effectively excluding unnecessary information.

  • Page 5

    Using this product with a higher voltage than that which is specified is dangerous and may result in a fire or other type of accident causing damage. YAMAHA will not be held responsible for any damage resulting from use of this unit with a voltage other than that which is specified.

  • Page 6: Names Of Controls, Indicators And Rear Panel Parts

    NAMES OF CONTROLS, INDICATORS AND REAR PANEL PARTS 5 6 7 8 For CD Player 12 13 14 TRACK TOTAL REMAIN ED I T For Receiver PRESET T I M ER S LEE P M EM O RY AUTO TUNING CD Player (CDC-S90) 1.

  • Page 7

    NAMES OF CONTROLS, INDICATORS AND REAR PANEL PARTS 58 59 67 68 69 70 71 72 73 74 EMPTY Double Cassette Tape Deck (KXW-S70) 48. DECK A Cassette Compartment 49. DECK A Select Button and Indicator 50. DECK B Select Button and Indicator 51.

  • Page 8

    9. AC Supply Lead SPEAKERS SELECTOR switch (U.K. and Europe models only) If you connect YAMAHA NX-S70 speaker system to this unit, set this switch to “NX-S70”. If you connect a speaker system other than NX-S70 to this unit, set this switch to “CONVENTIONAL”.

  • Page 9

    REMOTE CONTROL TRANSMITTER TUNER DIRECT TIME PROG TAPE EDIT SEARCH STOP PLAY/PAUSE SKIP DISC SKIP RANDOM REPEAT PRESET A/B/C/D/E DOWN TUNER PLAY STOP PLAY TAPE REC/PAUSE DECK PHONO/AUX POWER SLEEP DISPLAY VOLUME TUNER DIRECT TIME PROG TAPE EDIT SEARCH STOP PLAY/PAUSE SKIP DISC SKIP...

  • Page 10: Remote Control Transmitter

    REMOTE CONTROL TRANSMITTER 22 23 24 25 26 PLAY STOP PLAY TAPE REC/PAUSE DECK PHONO/AUX POWER SLEEP DISPLAY VOLUME Tape Deck Control Buttons 22. Play Button: 23. Stop Button: 24. Play Button: 25. Fast Wind Button: 26. DECK A/B Select Buttons (for KXW-S70 only) 27.

  • Page 11: Removing The Front Grille (for Speaker System Nx-s70 Only)

    REMOTE CONTROL TRANSMITTER Remote control sensor 0.2 m – 6 m (8” – 20’) REMOVING THE FRONT GRILLE (for Speaker System NX-S70 only) Proper use of the remote control transmitter Aim (within the range of 60° with no obstacles) the remote control transmitter at the remote control sensor and operate as shown.

  • Page 12: Preparation For Use

    PREPARATION FOR USE Placing examples RX-S70 CDC-S90 KXW-S70 or KX-S90 CDC-S90 RX-S70 KXW-S70 or KX-S90 15 m (49 feet) 7.5 m (25 feet) Earth rod * For U.K. and Europe models, “AM” is replaced by “MW LW”. Placing the system This system can be placed any way you like, however, be sure not to place another unit or any object on top of the receiver to prevent the ventilation holes on the top panel of...

  • Page 13: System Connection

    Set the SPEAKERS SELECTOR switch on the rear panel of the receiver to the proper position before connections. If you use YAMAHA Active Servo Processing Speaker System NX-S70, set this switch to “NX-S70”. If you use a speaker system other than NX-S70, set this switch to “CONVENTIONAL”.

  • Page 14: Open/close The Control Door

    OPEN/CLOSE THE CONTROL DOOR TURNING THE POWER ON/OFF TO THIS SYSTEM PLAY STOP PLAY TAPE REC/PAUSE DECK POWER SLEEP DISPLAY VOLUME When it is not necessary to operate controls inside the control door, close the door. To open or close the door, press the right edge until it clicks. If the AC supply lead is connected to the AC outlet, this system can be turned ON and OFF (STANDBY mode) by pressing the POWER switch on the front panel of the...

  • Page 15: Setting The Clock

    SETTING THE CLOCK DISPLAY TUNING MEMORY DOWN TIME ADJ HOUR MINUTE TUNING MEMORY DOWN TIME ADJ HOUR MINUTE While the power is on, press the DISPLAY button to display the time. If the power is off, you can proceed to the next step.

  • Page 16: Sound Control

    SOUND CONTROL VOLUME BALANCE BASS TREBLE – – COMPACT DISC PLAYER OPERATION Volume Front panel operation Rotate the VOLUME control towards 10 to increase the volume, and towards 0 to decrease the volume. Remote control operation Press the VOLUME + button to increase the volume and the VOLUME VOLUME –...

  • Page 17

    COMPACT DISC PLAYER OPERATION Receiver POWER CD Player Disc select buttons TUNER DIRECT TIME PROG TAPE EDIT SEARCH STOP PLAY/PAUSE SKIP DISC SKIP RANDOM REPEAT PRESET A/B/C/D/E DOWN TUNER PLAY STOP PLAY TAPE REC/PAUSE DECK PHONO/AUX POWER POWER SLEEP DISPLAY VOLUME CD playback Press the CD input selector button.

  • Page 18

    COMPACT DISC PLAYER OPERATION TUNER DIRECT TIME PROG TAPE EDIT SEARCH STOP PLAY/PAUSE SKIP DISC SKIP RANDOM REPEAT PRESET A/B/C/D/E DOWN TUNER PLAY STOP PLAY TAPE REC/PAUSE DECK PHONO/AUX POWER SLEEP DISPLAY VOLUME Direct operation Even when an input source other than CD player is selected, pressing the play/pause button, a disc select button, a track number input button or the RANDOM play button, or pressing the front edge of the disc table gently will start playback...

  • Page 19

    COMPACT DISC PLAYER OPERATION CD Player TUNER DIRECT TIME PROG TAPE EDIT SEARCH STOP PLAY/PAUSE SKIP DISC SKIP RANDOM REPEAT PRESET A/B/C/D/E DOWN TUNER PLAY STOP PLAY TAPE REC/PAUSE DECK PHONO/AUX POWER SLEEP DISPLAY VOLUME “Skip search” and “Manual search” are performed using the same buttons.

  • Page 20

    COMPACT DISC PLAYER OPERATION CD Player TUNER DIRECT TIME PROG TAPE EDIT SEARCH STOP PLAY/PAUSE SKIP DISC SKIP RANDOM REPEAT PRESET A/B/C/D/E DOWN TUNER PLAY STOP PLAY TAPE REC/PAUSE DECK PHONO/AUX POWER SLEEP DISPLAY VOLUME Display information during programming TRACK Playback order Selected track number Selected disc...

  • Page 21

    COMPACT DISC PLAYER OPERATION CD Player PROG TUNER DIRECT TIME PROG TAPE EDIT SEARCH STOP PLAY/PAUSE SKIP DISC SKIP RANDOM REPEAT PRESET A/B/C/D/E DOWN TUNER PLAY STOP PLAY TAPE REC/PAUSE DECK PHONO/AUX POWER SLEEP DISPLAY VOLUME To stop program play •...

  • Page 22

    COMPACT DISC PLAYER OPERATION CD Player TUNER DIRECT TIME PROG TAPE EDIT SEARCH STOP PLAY/PAUSE SKIP DISC SKIP RANDOM REPEAT PRESET A/B/C/D/E DOWN TUNER PLAY STOP PLAY TAPE REC/PAUSE DECK PHONO/AUX POWER SLEEP DISPLAY VOLUME S REP A REP F REP Repeat play All discs, an entire disc, a single track or a programmed sequence can be continuously repeated.

  • Page 23

    COMPACT DISC PLAYER OPERATION CD Player TUNER DIRECT TIME PROG TAPE EDIT SEARCH STOP PLAY/PAUSE SKIP DISC SKIP RANDOM REPEAT PRESET A/B/C/D/E DOWN TUNER PLAY STOP PLAY TAPE REC/PAUSE DECK PHONO/AUX POWER SLEEP DISPLAY VOLUME TIME TRACK TUNER DIRECT TRACK TIME PROG TAPE...

  • Page 24: Tuning Operation

    TUNING OPERATION Receiver “AM” is for U.S.A., Canada, Australia and General models. “MW/LW” is for U.K. and Europe models. Normally, if station signals are strong and there is no interference, quick automatic-search tuning (Automatic tuning) is possible. However, if signals of the station you want to select are weak, you must tune to it manually (Manual tuning).

  • Page 25

    TUNING OPERATION 2, 5 TUNER DIRECT TIME PROG TAPE EDIT SEARCH STOP PLAY/PAUSE SKIP DISC SKIP RANDOM REPEAT PRESET A/B/C/D/E DOWN TUNER PLAY STOP PLAY TAPE REC/PAUSE DECK PHONO/AUX POWER SLEEP DISPLAY VOLUME Preset tuning This unit can store station frequencies selected by tuning operation.

  • Page 26: Automatic Preset Tuning

    TUNING OPERATION Receiver Fundamental rules of internal automatic preset tuning operation Basically, FM stations are programmed onto area A, B and C, and AM stations are programmed onto area D and E (MW stations are onto D and LW stations are onto E) in that order automatically.

  • Page 27: Tape Deck Operation (for Kxw-s70 Double Cassette Deck)

    TAPE DECK OPERATION (for KXW-S70 Double Cassette Deck) Detection hole General information • Do not use C-120 tapes, tapes with internal reels or poor- quality tapes, since they can cause malfunctions. • Before loading a tape into the cassette compartment, tighten the slack tape with a pen or pencil.

  • Page 28

    TAPE DECK OPERATION (for KXW-S70 Double Cassette Deck) Receiver DECK A select button DECK B select button Tape Deck Tape A or tape B playback Press the TAPE input selector button. Open the DECK A or DECK B cassette compartment by pressing the EJECT button.

  • Page 29

    TAPE DECK OPERATION (for KXW-S70 Double Cassette Deck) Tape Deck TUNER DIRECT TIME PROG TAPE EDIT SEARCH STOP PLAY/PAUSE SKIP DISC SKIP RANDOM REPEAT PRESET A/B/C/D/E DOWN TUNER PLAY STOP PLAY TAPE REC/PAUSE DECK PHONO/AUX POWER SLEEP DISPLAY VOLUME Winding the tape If during playback, first press the stop Next press the fast wind wind the tape.

  • Page 30

    TAPE DECK OPERATION (for KXW-S70 Double Cassette Deck) Tape Deck TUNER DIRECT TIME PROG TAPE EDIT SEARCH STOP PLAY/PAUSE SKIP DISC SKIP RANDOM REPEAT PRESET A/B/C/D/E DOWN TUNER PLAY STOP PLAY TAPE REC/PAUSE DECK PHONO/AUX POWER SLEEP DISPLAY VOLUME Dolby B and C Type Noise Reduction With cassette tapes, the most noticeable form of noise is high frequency hiss.

  • Page 31: Tape Deck Operation (for Kx-s90 Single Cassette Deck)

    TAPE DECK OPERATION (for KX-S90 Single Cassette Deck) Detection hole Receiver Side A upward. Tape Deck EMPTY 6 4 5 General information • Do not use C-120 tapes, tapes with internal reels or poor- quality tapes, since they can cause malfunctions. •...

  • Page 32

    TAPE DECK OPERATION (for KX-S90 Single Cassette Deck) RESET LINEAR COUNTER EMPTY Dolby B and C Type Noise Reduction With cassette tapes, the most noticeable form of noise is high frequency hiss. To reduce this hiss noise, this unit has been equipped with a newly developed Dolby C noise reduction system in addition to its conventional Dolby B NR.

  • Page 33

    TAPE DECK OPERATION (for KX-S90 Single Cassette Deck) Tape Deck EMPTY TUNER DIRECT TIME PROG TAPE EDIT SEARCH STOP PLAY/PAUSE SKIP DISC SKIP RANDOM REPEAT PRESET A/B/C/D/E DOWN TUNER PLAY STOP PLAY TAPE REC/PAUSE DECK PHONO/AUX POWER SLEEP DISPLAY VOLUME Winding the tape If during playback, first press the stop Next press the fast wind...

  • Page 34: Recording Compact Discs

    RECORDING COMPACT DISCS Receiver CD Player Tape Deck (KXW-S70) Tape Deck (KX-S90) EMPTY 3 4 5 2 TUNER DIRECT TIME PROG TAPE EDIT SEARCH STOP PLAY/PAUSE SKIP DISC SKIP RANDOM REPEAT PRESET A/B/C/D/E DOWN TUNER PLAY STOP PLAY TAPE REC/PAUSE DECK PHONO/AUX POWER...

  • Page 35

    RECORDING COMPACT DISCS CD Player Tape Deck (KXW-S70) Tape Deck (KX-S90) EMPTY TUNER DIRECT TIME PROG TAPE EDIT SEARCH STOP PLAY/PAUSE SKIP DISC SKIP RANDOM REPEAT PRESET A/B/C/D/E DOWN TUNER PLAY STOP PLAY TAPE REC/PAUSE DECK PHONO/AUX POWER SLEEP DISPLAY VOLUME To stop recording temporarily Press the stop...

  • Page 36

    RECORDING COMPACT DISCS Receiver CD Player Tape Deck (KXW-S70) Tape Deck (KX-S90) EMPTY TUNER DIRECT TIME PROG TAPE EDIT SEARCH STOP PLAY/PAUSE SKIP DISC SKIP RANDOM REPEAT PRESET A/B/C/D/E DOWN TUNER PLAY STOP PLAY TAPE REC/PAUSE DECK PHONO/AUX POWER SLEEP DISPLAY VOLUME Recording CD(s) on both sides of...

  • Page 37

    RECORDING COMPACT DISCS Receiver CD Player Tape Deck (KXW-S70) Tape Deck (KX-S90) EMPTY TUNER DIRECT TIME PROG TAPE EDIT SEARCH STOP PLAY/PAUSE SKIP DISC SKIP RANDOM REPEAT PRESET A/B/C/D/E DOWN TUNER PLAY STOP PLAY TAPE REC/PAUSE DECK PHONO/AUX POWER SLEEP DISPLAY VOLUME Automatic tape-editing...

  • Page 38

    RECORDING COMPACT DISCS CD player Tape Deck (KXW-S70) Tape Deck (KX-S90) EMPTY TUNER DIRECT TIME PROG TAPE EDIT SEARCH STOP PLAY/PAUSE SKIP DISC SKIP RANDOM REPEAT PRESET A/B/C/D/E DOWN TUNER PLAY STOP PLAY TAPE REC/PAUSE DECK PHONO/AUX POWER SLEEP DISPLAY VOLUME Notes •...

  • Page 39

    RECORDING COMPACT DISCS Receiver CD Player TUNER DIRECT TIME PROG TAPE EDIT SEARCH STOP PLAY/PAUSE SKIP DISC SKIP RANDOM REPEAT PRESET A/B/C/D/E DOWN TUNER PLAY STOP PLAY TAPE REC/PAUSE DECK PHONO/AUX POWER SLEEP DISPLAY VOLUME Display information during programming Selected disc Side of the tape TRACK Total remaining time on...

  • Page 40: Other Recordings

    OTHER RECORDINGS Receiver Tape Deck (KXW-S70) Tape Deck (KX-S90) EMPTY TUNER DIRECT TIME PROG TAPE EDIT SEARCH STOP PLAY/PAUSE SKIP DISC SKIP RANDOM REPEAT PRESET A/B/C/D/E DOWN TUNER PLAY STOP PLAY TAPE REC/PAUSE DECK PHONO/AUX POWER SLEEP DISPLAY VOLUME Recording from the built-in tuner Press the TUNER input selector button.

  • Page 41

    OTHER RECORDINGS Receiver Tape Deck (KXW-S70) Tape Deck (KX-S90) EMPTY TUNER DIRECT TIME PROG TAPE EDIT SEARCH STOP PLAY/PAUSE SKIP DISC SKIP RANDOM REPEAT PRESET A/B/C/D/E DOWN TUNER PLAY STOP PLAY TAPE REC/PAUSE DECK PHONO/AUX POWER SLEEP DISPLAY VOLUME Dubbing (by using KXW-S70 only) •...

  • Page 42: How To Use The Built-in Timer

    HOW TO USE THE BUILT-IN TIMER Receiver Timer play By using the built-in timer, you can set the time when the unit turns on and a source begins playing automatically, and the time when the unit turns off automatically. Prepare the source to be played. For tuner: Tune in to the station you will listen to.

  • Page 43

    HOW TO USE THE BUILT-IN TIMER POWER TIME ADJ 2- , DISPLAY TIMER At ON TIME/time setting mode [“ON TIME” appears on the display, and soon it is changed to a time setting mode.] Set to the time when the timer play begins by using the HOUR button and the MINUTE button.

  • Page 44: Timer Recording

    HOW TO USE THE BUILT-IN TIMER Receiver DISPLAY TIMER TAPE POWER Tape Deck (KXW-S70) Tape Deck (KX-S90) EMPTY Timer recording (To record a tuner program) Load a blank tape into the cassette compartment. (For KXW-S70, load a tape into the DECK B cassette compartment.) Tune to the station of which program you want to record.

  • Page 45

    HOW TO USE THE BUILT-IN TIMER POWER DISPLAY AUTO MEMO TUNER DIRECT TIME PROG TAPE EDIT SEARCH STOP PLAY/PAUSE SKIP DISC SKIP RANDOM REPEAT PRESET A/B/C/D/E DOWN TUNER PLAY STOP PLAY TAPE REC/PAUSE DECK PHONO/AUX POWER POWER SLEEP DISPLAY VOLUME SLEEP Sleep timer operation This unit can be turned off automatically.

  • Page 46: Using External Units

    USING EXTERNAL UNITS Auxiliary (AUX) Connect the output lead of a video cassette player, video disc player, etc. to the AUX inputs of this unit. (red right channel, white Press the AUX input selector button. Operate the unit connected to the AUX inputs. Start recording with this unit, if so desired.

  • Page 47: Maintenance

    USING EXTERNAL UNITS MAINTENANCE KXW-S70 (DECK A) KXW-S70 (DECK B) Headphones • Be sure that your headphones have a 3.5 mm (1/8”) diameter plug and are between 16 ohms and 50 ohms impedance. Recommended impedance is 32 ohms. • When headphones are connected, the speakers are defeated automatically.

  • Page 48: Specifications

    SPECIFICATIONS As a part of policy of continuous improvement, YAMAHA reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. Receiver (RX-S70) Minimum RMS Output Power per Channel 6 ohms, 20 Hz to 20 kHz, 0.04% THD ...

  • Page 49: Troubleshooting

    If it cannot, or if the fault is not listed in the SYMPTOM column, disconnect the power cord and contact your authorized YAMAHA dealer or service center for help. Should be service required, the servicer will need all three pieces [RX-S70, CDC-S90, (KXW-S70 or KX-S90)].

  • Page 50: Active Servo Technology (for Speaker System Nx-s70 Only)

    ACTIVE SERVO TECHNOLOGY (for Speaker System NX-S70 only) High- amplitude bass sound Port Signals of low amplitude The theory of the Active Servo Technology is based upon two major factors, the Helmholtz resonator and negative- impedance drive. Active Servo Processing speakers reproduce the bass frequencies through an “air woofer”, which is a small port or opening in the speaker’s cabinet.

  • Page 51

    YAMAHA ELECTRONIK EUROPA G.m.b.H. SIEMENSSTR. 22-34, D-2084 RELLINGEN BEI HAMBURG, F.R. OF GERMANY YAMAHA ELECTRONIQUE FRANCE S.A. 17 RUE DES CAMPANULES, LOGNES 77321 MARNE LA VALLEE CEDEX 2, FRANCE YAMAHA ELECTRONICS (UK) LTD. YAMAHA HOUSE, 200 RICKMANSWORTH ROAD WATFORD, HERTS WD1 7JS, ENGLAND YAMAHA SCANDINAVIA A.B.
