Summary of Contents for Yamaha CD-R/RW Drive CRW6416SX
- Page 1 POWER CRW6416SX...
- Page 2 If these corrective measures do not produce satisfactory results, please contact the local retailer authorized to distribute this type of product. If you can not locate the appropriate retailer, please contact Yamaha Systems Technology, Inc. 100 Century Center Court, San Jose, CA95112, U.S.A.
- Page 3 CD-R/RW Drive CD-R/RW Drive CRW6416SX CRW6416SX SERIES SERIES POWE WER R C C R R W W 6 6 4 4 1 1 6 6 S S X X OWNER’S MANUAL...
-
Page 4: Safety Precautions
Otherwise, there is an increased risk of electrical shock, fire or damage to the device. Return the device immediately to the store at which it was purchased or alternatively, to the nearest Yamaha Service Center (listed at the back of this manual). - Page 5 Otherwise, dust can build up inside the device, increasing the risk of fire or damage. For information about servicing charges, contact the store at which the device was purchased or alternatively, the nearest Yamaha Service Center (listed at the back of this manual). The device should be serviced about once a year.
- Page 6 WARRANTY YAMAHA AND SUPPLIERS ACCEPT NO LIABILITY FOR THE LOSS OF ANY DATA OR ANY PROBLEMS CAUSED AS A RESULT. AS A PRECAUTION, IT IS RECOMMENDED THAT THE DISCS ARE TESTED AFTER THEY HAVE BEEN WRITTEN TO. FURTHERMORE, UNDER NO CIRCUMSTANCES DOES YAMAHA AND SUPPLIERS GUARANTEE THE RELIABILITY OF THE MEDIA.
-
Page 7: Table Of Contents
This document may not, in whole or in part, be copied, photocopied, reproduced, translated, transmitted or reduced to any electronic medium of machine readable form without prior consent in writing from Yamaha. Windows is a registered trademark of Microsoft Corporation. -
Page 8: Setup Flowchart
Setup Flowchart These flowcharts show the procedure for setting up the CRW6416SX drive. For easy cross-referencing, the relevant pages in this manual are also given. Windows Users STEP Do you have a SCSI adapter card? Check that the SCSI adapter STEP card is recognized correctly Go to Control Panel | System | Device... -
Page 9: Macintosh Users
Macintosh Users STEP Does your Macintosh have a built-in SCSI connector? Set up the CRW6416SX drive STEP 1. Set the switches at the rear of the drive. (P.10, 11) 2. Connect the SCSI and power cables, then switch the drive on. (P.16-18) Install the CD writing STEP software... -
Page 10: Introduction
Introduction Features of the CRW6416SX Drive 6X Speed Writing to CD-R, 4X Speed Writing to CD-RW and 16X Speed Reading The CRW6416SX drive can write to CD-R at 6X, 4X or 1X speed and write/overwrite to CD-RW at 4X or 2X speed. It can also read from CD-R and CD-ROM media at up to 16X speed. -
Page 11: System Configuration
A SCSI card to connect SCSI devices (including the CRW6416SX) to your computer. Make sure it has a half-pitch 50-pin D-sub external connector. Yamaha recommends any of Adaptec’ s AHA-2940-series cards (PCI slot). n Many Apple Macintosh computers have built-in SCSI connectors. However, if your Macintosh does not have a built-in SCSI connector, you will need to obtain a PCI bus SCSI adapter card. -
Page 12: Software
System Configuration Software The software requirements for using the CRW6416SX drive are as follows: CD writing software. This software must support the CRW6416SX drive for writing to CD-R or CD-RW. n For details about how to install and use the software, refer to the documentation that came with it. -
Page 13: Media
Media The CRW6416SX drive is compatible with discs which meet the following specifications: CD-R discs: Use discs that conform to the Orange Book Part 2 standards. When writing to CD-R at 4X or 6X speed, you should use discs that have been designed for high-speed recording. -
Page 14: Tools
System Configuration Tool Phillips Screwdriver You will need to use this when removing the cover of your computer and installing a SCSI adapter card. n Make sure your screwdriver’ s head is the correct size for the screws you need to remove. -
Page 15: Front And Rear Of Unit
Front and Rear of Unit Front Panel The CRW6416SX drive’ s front panel features the following: Disc tray Manual Eject hole The tray is used to Only use this if no hold the disc. other method is It slides out from available for the drive unit when unloading a disc. -
Page 16: Rear Panel
Front and Rear of Unit Rear Panel The CRW6416SX drive’ s rear panel features the following: Serial number This consists of 3 letters and 7 digits. You may need to refer to this number when requesting User Support services. SER. NO. AC IN CDR ID Power connector... -
Page 17: Installation
Installation This section gives a step-by-step guide to setting up your CRW6416SX drive. First Steps Before connecting your CRW6416SX drive to your computer, you need to set up the drive using the switches located at the rear of the unit. You’ll need to set the following: SCSI ID number Termination... - Page 18 Installation 2 Termination Terminators prevent SCSI signals from being reflected off the last device in the chain. The SCSI terminator switch should be set to “ON” if your CRW6416SX drive is the last device on the SCSI chain. If it is not the last device on the chain, the TERMINATOR switch should be set to “OFF .”...
-
Page 19: Setting Up The Crw6416Sx Drive
Setting Up The CRW6416SX Drive There are three stages to setting up your CRW6416SX drive. Installing a SCSI adapter card You will need to open the casing of your computer and insert a SCSI adapter card (sold separately) if one has not been installed already. n You will need a Phillips screwdriver to open the casing of the computer and to secure the SCSI adapter card in its slot. -
Page 20: Installing A Scsi Adapter Card
Setting Up The CRW6416SX Drive Installing a SCSI Adapter Card 1 Power down your computer and unplug it from the AC outlet. If you proceed without doing this, you run the risk of receiving an electric shock and/or short-circuiting and damaging components including the CRW6416SX drive. - Page 21 3 Touch a metal part of the computer’ s chassis or power supply unit to drain any static charge that may have built up inside your body. Drain any static charge You can permanently damage equipment if you touch it while there is any static charge in your body.
- Page 22 Setting Up The CRW6416SX Drive 5 Insert your SCSI adapter card into the slot using both hands. Make sure it is seated firmly in the slot. Then secure the card by replacing the screw used for the blanking plate. 6 Attach the outer casing of the computer and any screws that were removed. Then reconnect the computer to the electrical outlet but do not power it up yet.
-
Page 23: Connecting The Drive
Setting Up The CRW6416SX Drive Connecting the Drive 1 Connect one end of the SCSI cable to your SCSI adapter card. SCSI adapter card connector Connect SCSI cable... - Page 24 Setting Up The CRW6416SX Drive The connector of your SCSI adapter card may vary. The following are the most common types of SCSI connector: Half-pitch 50-pin D-sub Half-pitch 50-pin Centronics The CRW6416SX drive requires a half-pitch 50-pin D-sub connector. You will need to obtain a SCSI cable with connectors suitable for both your drive and your SCSI adapter card.
- Page 25 2 Connect the other end of the SCSI cable to the rear of your CRW6416SX drive. Either SCSI connector (marked “SCSI-1” and “SCSI-2”) may be used. Connect SCSI cable 3 Connect the D-shaped end of the included power cable to the power connector at the rear of your CRW6416SX drive.
- Page 26 Setting Up The CRW6416SX Drive 4 Power up your CRW6416SX drive first, then your computer. Power ON Always power up the devices in your SCSI chain before powering up your computer. This will ensure that they are recognized by the computer’s operating system.
-
Page 27: Verifying The Hardware Installlation
Verifying the Hardware Installation Windows Users 1 When the computer’ s operating system is loading, your SCSI adapter card will be recognized and you will be prompted to install the drivers for it. Follow the on-screen instructions and choose to reboot your computer at the end of the driver installation procedure. -
Page 28: Macintosh Users
Setting Up The CRW6416SX Drive 3 Double-click “YAMAHA CRW6416S” listed under CDROM, and click the Settings tab. Check the “Sync data transfer” checkbox. With “Sync data transfer” enabled, the data transfer between your CRW6416SX drive and your computer is synchronized, meaning that the maximum possible data transfer rate can be achieved. -
Page 29: Operation
Operation This section explains how to operate the CRW6416SX drive after you have installed it. Loading a Disc 1 Press the Eject button on the CRW6416SX drive’ s front panel. 2 Place the disc onto the tray with its label or printing facing upward. 3 Press the Eject button to close the tray. - Page 30 Operation Manually Ejecting a Disc If the disc tray fails to open for some reason, such as a power outage, it can be opened manually. Manual Eject hole You should only attempt to eject a disc manually as a last resort. Malfunctions may occur if you do this too frequently.
-
Page 31: Troubleshooting
Troubleshooting Please also refer to the YAMAHA CD-R/RW Drives web site for more information. YAMAHA CD-R/RW Drives web site URL: http://www.yamaha.co.jp/english/product/computer/ The drive does not power up. Is the drive’ s power cable attached correctly? The computer does not start up. - Page 32 There may be problems with the disc itself. If the drive fails to recognize a variety of discs including audio CDs, CD-ROMs and blank CD-R/RW discs (the ON/DISC LED remains lit in orange after any discs have been inserted), you should contact your nearest Yamaha dealer.
- Page 33 Errors occur when backing up at 6X speed from a separate CD- ROM drive to the CRW6416SX drive. A possible reason is that the CD-ROM drive is not suitable. Please use a high-speed CD-ROM drive. However, for various possible reasons, you may still encounter errors even if you are using a 32X or 42X speed CD- ROM drive.
-
Page 34: Appendix
Appendix Writing Modes Disc-at-Once (DAO) This mode is used when writing a complete disc in a single pass without pausing. Data cannot be added later, even if the full capacity of the blank disc has not been used. Example: General CD-ROM Track 1 Session 1 Lead-in... - Page 35 Session-at-Once (SAO) This mode is used when writing each session in a single pass without pausing. More sessions can be added later if there is enough space left on the disc. Example: CD Extra Audio Audio Track 1 Track 2 (Session 1) n With CD Extra, the audio is written in the first session and the data is written in the second.
-
Page 36: About The Firmware
URL for YAMAHA CD-R/RW Drives web site http://www.yamaha.co.jp/english/product/computer/ The most recent user support information, including firmware updates, can be found in the CD-R area of Yamaha’ s web site. Please check this information regularly. n The firmware is completely unrelated to the CD writing application software. -
Page 37: Led Indicator Messages
LED Indicator Messages Status Power on (reset) Ready (no disc) Loading disc Ejecting disc Ready (disc loaded) Seeking Preparing to write Writing Writing (test mode) Reading Lit: Orange Blinking: Orange Lit: Green Blinking: Green POWER CRW6416SX ON/DISC LED READ/WRITE LED —: Off Appendix... -
Page 38: Crw6416Sx Specifications
Appendix CRW6416SX Specifications Supported Write/Read Format Writing Methods Writing/Reading Speed Writing CD-R Reading 9X-16X (max) Partial CAV CD-R CD-RW 2X, 4X Writing/ReWriting: Orange Book Part III Version Data Capacity Data Transfer Rate Burst Transfer Rate Data Buffer Size Average Random Access Time CD-DA CD-ROM CD-ROM XA... - Page 39 Sector Size Interface Installing style Disc Loading Type Audio Out Voltage Rating Current Draw Power Consumption Operating Environment Dimensions (includes projection) Weight The CRW6416SX series complies with the following specifications Compliance Specifications Country / Region Category Item Safety Electrical Laser Emission Canada Safety...
-
Page 40: Index
Appendix Index Active Desktop ...26 BIOS ...24 Buffer Underrun ...26 CD-DA ...6 CD-R discs ...6 CD-RW discs ...6 CDR IDE selector switch...9 Data CD ...6 Device Manager...20 Disc tray ...8 Disc-at-Once (DAO) ...27 Eject button ...8 Ejecting a Disc ...22 firmware ...29 Front Panel... - Page 41 If you have any questions, please contact your dealer or one of the following companies. Pour plus de détails sur les produits, veuillez vous adresser à Yamaha ou au distributeur le plus proche figurant dans la liste suivante : Bei weiteren Fragen wenden Sie sich Sitte an Ihren Händler oder eine der folgenden Firmen.
