Cisco 7500 Series Replacing Manual page 26

Chassis interface board

Hide thumbs Also See for 7500 Series:

Table of Contents

Replacing the CI in the Cisco 7513

Step 3

Note

sections, and then to replace the cover, proceed to Step 4, which follows.

Step 4

Step 5

This completes the backplane maintenance cover removal and replacement procedure.

Removing and Replacing the CI

The CI (shown in Figure 17) provides environmental monitoring and logic functions for the Cisco

7513.

Figure 17

Standoff

screw holes

Note

cover panels and backplane maintenance cover. If not, refer to the appropriate procedures in this

section to remove these items.

26 Replacing the Chassis Interface (CI) Board in the Cisco 7500 Series Chassis

Carefully guide the cover up and away from the chassis.

Depending on the replacement procedures you need to perform, refer to the appropriate

To replace the cover, carefully guide the cover over the ten screws. (See Figure 16.)

Align the cover; then tighten all ten screws that secure it to the chassis.

Chassis Interface (MAS-7500CI=)

Chassis interface

Replace the CI only if it fails. This procedure assumes to have already removed the chassis

Standoff

screw holes
