- Page 1 ELCC-TB-KF Cantilever axis Instructions | Operat- 8087950 8087950 2018-05 [8087952]...
- Page 2 Translation of the original instructions Festo — ELCC-TB-KF — 2018-05...
-
Page 3: Table Of Contents
Checking the cover strip....................10 10.3 Cleaning........................11 10.4 Lubrication........................12 Malfunctions....................... 14 11.1 Fault clearance......................14 11.2 Repair..........................15 Disassembly........................ 15 Disposal........................15 Technical data......................16 14.1 Technical data, mechanical................... 16 14.2 Technical data, characteristic curves................18 Festo — ELCC-TB-KF — 2018-05... -
Page 4: Further Applicable Documents
The qualified personnel must be familiar with installation of electrical control systems. Further information – Accessories è www.festo.com/catalogue. – Spare parts è www.festo.com/spareparts. Service Contact your regional Festo contact person if you have technical questions è www.festo.com. Festo — ELCC-TB-KF — 2018-05... -
Page 5: Product Overview
3 Cantilever profile 8 Slot for mounting accessories 4 Drive head 9 Lubrication hole 5 Interface for motor attachment 10 Supply port for clamping unit or sealing air Fig. 2 Product design ELCC-TB-KF Festo — ELCC-TB-KF — 2018-05... -
Page 6: Transport
The axis and motor will thus be perfectly harmonised with one another. – Use the Festo engineering software “PositioningDrives” to design the axis è www.festo.com. – Observe the limit values for forces, torques and speeds è 14 Technical data. , . -
Page 7: Mounting
Keep the tilt moment resulting from the force (parallel to the axis of movement) and lever arm as small as possible. 2. Fasten the axis with centring sleeves and screws to all threads 7. 3. Tighten the screws. Festo — ELCC-TB-KF — 2018-05... -
Page 8: Attachment
2. Fasten the actuator using the centring sleeves and screws to all threads 1. 3. Tighten screws evenly. Size 90/110 Screw – – – Centring [H7] [mm] Tab. 3 Screw size and centring Festo — ELCC-TB-KF — 2018-05... -
Page 9: Mounting Accessories
The axis can move through the complete intended positioning cycle. – The axis stops as soon as a limit switch is reached. If the proximity sensors fail to respond: è 11.1 Fault clearance and instructional manual for proximity switch. Festo — ELCC-TB-KF — 2018-05... -
Page 10: Operation
1. Check the toothed belt for wear (e.g. toothed-belt friction) after 1000 km of operating distance and then after every 500 km of operating distance. 2. If there are signs of toothed belt wear, send the axis to Festo or contact Festo service è www.festo.com. -
Page 11: Cleaning
Maintenance If the cover strip can no longer be retensioned: • Replace belt reversal devices and cover strip è www.festo.com/spareparts. 10.3 Cleaning Do not clean the guide elements (e.g. guide rails). 1. Clean the product with a soft cloth. Do not use aggressive cleaning agents. -
Page 12: Lubrication
è Fig.9. 3. Grease the guide at each of the two relubrication openings 1 and 2 è Fig.8. Accessories and permitted lubricant è Tab. 5 Maintenance accessories. Fig. 9 Lubrication interval dependent on load comparison factor Festo — ELCC-TB-KF — 2018-05... - Page 13 Pressure grease gun with pinpoint nozzle 647958/LUB-1 Blast pipe, axial outlet 647959/LUB-1-TR-I Blast pipe, radial outlet 647960/LUB-1-TR-L Roller bearing grease, ELCC-TB-KF LUB-KC1 from Festo Roller bearing grease, ELCC-TB-KF-...-F1 Elkalub VP922, Chemie-Technik, Vöhringen 1) Spare parts catalogue è www.festo.com/spareparts. Tab. 5 Maintenance accessories Festo — ELCC-TB-KF — 2018-05...
-
Page 14: Malfunctions
Change parameters. Insufficient lubrication at guide. Lubricating the axis 10 Maintenance. è Guide unit is defective. Send axis to Festo or contact the local Festo service. Wear on toothed belt/guide or Send axis to Festo or contact belt reversal point the local Festo service. -
Page 15: Repair
Wear Send axis to Festo or contact the local Festo service. Tab. 6 11.2 Repair Send the product to the Festo repair service for repair. Disassembly WARNING! Unexpected movement of components. Injury due to impacts or crushing. • Before working on the product, switch off the control and secure it to prevent it from being switched back on accidentally. -
Page 16: Technical Data
2nd degree of surface torque 241 x 10 960 x 10 2668 x 10 6831 x 10 304 x 10 929 x 10 2049 x 10 4926 x 10 Distance to guide centre point [mm] 29.9 39.1 43.8 Festo — ELCC-TB-KF — 2018-05... - Page 17 1230 2285 Determination of the load compensation factor for combined loads: 1) The design software PositioningDrives or the catalogue are available for sizing è www.festo.com/sp. The values specified here are provided to determine the relubrication interval Tab. 8 Forces and torques...
-
Page 18: Technical Data, Characteristic Curves
Tab. 10 Technical data on clamping unit ELCC-...-C 14.2 Technical data, characteristic curves Deflection f of the profile depending on the cantilever extension A and the payload m Horizontal drive head Vertical drive head Tab. 11 Alignment of the drive head Festo — ELCC-TB-KF — 2018-05... - Page 19 Technical data m = 0 kg m = 10 kg m = 5 kg Fig. 10 ELCC-TB-KF-60, horizontal m = 0 kg m = 10 kg m = 5 kg Fig. 11 ELCC-TB-KF-60, vertical Festo — ELCC-TB-KF — 2018-05...
- Page 20 = 35 kg m = 20 kg Fig. 12 ELCC-TB-KF-70, horizontal m = 0 kg m = 30 kg m = 10 kg m = 35 kg m = 20 kg Fig. 13 ELCC-TB-KF-70, vertical Festo — ELCC-TB-KF — 2018-05...
- Page 21 = 50 kg Fig. 14 ELCC-TB-KF-90, horizontal m = 0 kg m = 30 kg m = 10 kg m = 40 kg m = 20 kg m = 50 kg Fig. 15 ELCC-TB-KF-90, vertical Festo — ELCC-TB-KF — 2018-05...
- Page 22 = 50 kg m = 30 kg Fig. 16 ELCC-TB-KF-110, horizontal m = 0 kg m = 40 kg m = 20 kg m = 50 kg m = 30 kg Fig. 17 ELCC-TB-KF-110, vertical Festo — ELCC-TB-KF — 2018-05...
- Page 24 Copyright: Festo AG & Co. KG Ruiter Straße 82 73734 Esslingen Germany Phone: +49 711 347-0 Fax: +49 711 347-2144 Reproduction, distribution or sale of this document or communic- e-mail: ation of its contents to others without express authorization is service_international@festo.com...
