Yamaha Clavinova CLP-820 Owner's Manual

Yamaha clavinova owner's manual
Hide thumbs

Advertisement

IMPORTANT
Check your power supply
Make sure that your local AC mains voltage matches the volt-
age specified on the name plate on the bottom panel. In some
areas a voltage selector may be provided on the bottom panel
of the main keyboard unit near the power cord. Make sure that
the voltage selector is set for the voltage in your area. The
voltage selector is set at 240V when the unit is initially
shipped. To change the setting use a "minus" screwdriver to
rotate the selector dial so that the correct voltage appears next
to the pointer on the panel.

Advertisement

loading

  Also See for Yamaha Clavinova CLP-820

  Related Manuals for Yamaha Clavinova CLP-820

  Summary of Contents for Yamaha Clavinova CLP-820

  • Page 1 IMPORTANT Check your power supply Make sure that your local AC mains voltage matches the volt- age specified on the name plate on the bottom panel. In some areas a voltage selector may be provided on the bottom panel of the main keyboard unit near the power cord. Make sure that the voltage selector is set for the voltage in your area.
  • Page 2: Special Message Section

    SPECIFICATIONS SUBJECT TO CHANGE: The information contained in this manual is believed to be correct at the time of printing. However, Yamaha reserves the right to change or modify any of the specifications without notice or obligation to update existing units.
  • Page 3 SAVING USER DATA • Save all data to an external device such as the Yamaha MIDI Data Filer MDF3, in order to help prevent the loss of important data due to a malfunction or user operating error.
  • Page 4: Included Accessories

    Thank you for choosing a Yamaha Clavinova. Your Clavinova is a fine musical instrument that employs advanced Yamaha music technology. With the proper care, your Clavinova will give you many years of musical pleasure. Stereo sampling of the acoustic piano voices offers unmatched realism and expressive power, while the AWM (Advanced Wave Memory) tone generator system offers rich, realistic reproductions of all other voices.
  • Page 5: Table Of Contents

    The Control Panel Key Cover & Music Stand Connections Selecting & Playing Voices Playing the Demonstration Tunes Voice Demo ... 12 Piano Song ... 13 Piano Song A-B Repeat ... 14 Piano Song Part Cancel ... 15 Synchro Start ... 15 Left Pedal Start/Stop ...
  • Page 6: The Control Panel

    The Control Panel CLP-820/820S MASTER VOLUME DEMO ROOM HALL 1 HARD HALL 2 MEDIUM STAGE SOFT TRANSPOSE REVERB TOUCH CLP-840 MASTER VOLUME BRILLIANCE DEMO BRIGHT ROOM CHORUS HALL 1 SYMPHONIC HARD HALL 2 TREMOLO MEDIUM STAGE DELAY SOFT TRANSPOSE REVERB EFFECT TOUCH MELLOW...
  • Page 7 5 [TRANSPOSE] Button The [TRANSPOSE] button allows access to the Clavinova’s TRANSPOSE function (to shift the pitch of the entire keyboard up or down in semitone intervals). 6 [REVERB] Button The [REVERB] button selects a number of digital reverb effects that you can use for extra depth and expressive power.
  • Page 8: Key Cover & Music Stand

    Key Cover & Music Stand Key Cover Be careful to avoid catching your fingers when opening or closing the cover. Be careful to avoid catching your fingers when opening or closing the cover. • Hold the cover with both hands when moving it, and do not release it until it is fully opened or closed.
  • Page 9: Music Stand

    Music Stand To raise the music stand: Pull the stand up and toward yourself as far as it will go. Flip down the two metal supports at the left and the right on the rear of the music stand. Lower the music stand so that it rests on the metal supports. As shown in the illustration, the angle of the music stand can be set in one of three positions, according to the position of the metal supports.
  • Page 10: Connections

    1 AUX IN L/L+R and R Jacks These jacks are intended for use with an external tone generator module such as the Yamaha DOU-10 Disk Orchestra Unit. The stereo outputs from the external tone generator module are connected to the AUX IN L/L+R and R jacks, allowing the sound of the tone generator to be reproduced via the Clavinova’s internal sound system and speakers.
  • Page 11: Selecting & Playing Voices

    Selecting & Playing Voices POWER MASTER VOLUME CLP-880 GRAND CLASSICAL JAZZ ROCK PIANO PIANO PIANO E. PIANO 1 PIANO HARPSI- PIPE CHURCH JAZZ CHORD STRINGS ORGAN ORGAN ORGAN BRILLIANCE BRIGHT ROOM CHORUS HALL 1 SYMPHONIC HALL 2 TREMOLO STAGE DELAY REVERB EFFECT MELLOW...
  • Page 12: Playing The Demonstration Tunes

    Playing the Demonstration Tunes Demonstration tunes are provided that effectively demonstrate each of the Clavinova’s voices. There are also 50 piano songs that you can play individually, all in sequence, or in random order. Here’s how you can select and play the demo tunes.
  • Page 13: Piano Song

    Piano Song Engage the Piano Song Mode PIANO Press the [PIANO SONG] button to engage the piano song mode — SONG the [PIANO SONG], [1] and [2] indicators will light. Play a Piano Song To play any of the 50 piano songs provided, use the [SONG SE- SONG LECT SELECT...
  • Page 14: Piano Song A-B Repeat

    Playing the Demonstration Tunes FUNCTION FUNCTION RECORDER START/ STOP CLP-880/860/840/820/820S Piano Song A-B Repeat The A-B Repeat function can be used to continuously repeat a specified phrase within a piano song. Combined with the Part Cancel function described below, this provides an excellent way to practice difficult phrases.
  • Page 15: Piano Song Part Cancel

    Piano Song Part Cancel be turned on and off as required so you can practice the corresponding part on the keyboard. The right-hand part is played by the recorder’s [1] track, and the left-hand part is played by recorder’s [2] track. (Some of the songs are arrangements for four-hands, tracks [1] and [2] corre- spond to primo and secondo parts of the arrangement.) Turn the Desired Part Off...
  • Page 16: The Dual Mode

    The Dual Mode The dual mode makes it possible to play two voices simultaneously across the entire range of the keyboard. JAZZ ROCK IANO PIANO E. PIANO 1 E. PIAN Voice numbering priority GRAND CLASSICAL JAZZ ROCK PIANO PIANO PIANO PIANO E.
  • Page 17: (Clp-880/860)

    The Split Mode The split mode makes it possible to play two different voices on the keyboard — one with the left hand and another with the right hand. The Left Voice is played on all keys to the left of (and including) a specified “split point” key, while the Right Voice is played on all keys to the right of the split point key.
  • Page 18: Reverb

    Reverb The [REVERB] button selects a number of digital reverb effects that you can use for extra depth and expressive power. ROOM HALL 1 HALL 2 STAGE REVERB ROOM HALL 1 HALL 2 STAGE SONG SELECT REVERB – / NO / YES CLP-880/860/840/820/820S To select a reverb type press the [REVERB] button a few times...
  • Page 19: The Effect (Clp-880/860/840)

    The Effect The [EFFECT] button allows you to select one of the effects that can give your sound greater depth and animation. CHORUS SYMPHONIC TREMOLO DELAY EFFECT CHORUS SYMPHONIC TREMOLO DELAY SONG SELECT EFFECT – / NO / YES Brilliance (CLP-880/860/840) This control can be used to change the tonality or “timbre”...
  • Page 20: The Pedals

    The Pedals The CLP-820 S has two and other models have three foot pedals that produce a range of expressive effects similar to those produced by the pedals on an acoustic piano. CLP-880/860/840/820 Soft pedal Damper pedal Sostenuto pedal CLP-820S Damper pedal Soft/Sostenuto pedal CLP-880/860/840/820/820S...
  • Page 21: Touch Sensitivity

    Touch Sensitivity Four different types of keyboard touch sensitivity — HARD, MEDIUM, SOFT or FIXED — can be selected to match different playing styles and preferences. HARD MEDIUM SOFT TOUCH Transposition The Clavinova’s TRANSPOSE function makes it possible to shift the pitch of the entire keyboard up or down in semitone intervals up to a maximum of 12 semitones (i.e.
  • Page 22: Tuning

    Tuning Tuning makes it possible to adjust the pitch of the Clavinova over a 427.0 Hz … 453.0 Hz (corresponding to the A3 note’s Hz) range in approximately 0.2 Hertz intervals. Pitch control is useful for tuning the Clavinova to match other instruments or recorded music.
  • Page 23: The Metronome & Tempo Control

    The Metronome & Tempo Control The Clavinova built-in metronome is a convenient feature for practice, and it can also provide a solid rhythmic guide when recording using the Recorder feature, described in the next section. The Metronome METRO- NOME Beat indicator METRO- SONG NOME...
  • Page 24: Using The Recorder

    Using the Recorder The Clavinova features a two-track recorder that let you record what you play on the keyboard and then play it back. Two tracks mean that you can “overdub” one part on top of another, using a different voice if you like. The recorder feature is a useful adjunct to any keyboard study program, since it lets you hear exactly how you sound from the listener’s perspective.
  • Page 25: Changing The Initial Settings

    Start Recording keyboard or press the [START/STOP] button. The current measure number will appear on the display while recording. RECORDER START/ STOP RECORDER Stop Recording stop recording. START/ STOP now contains data. Changing the Initial Settings RECORDER made in step 1 of the recording procedure are actually recorded by the Clavinova.
  • Page 26: Playback

    It is also possible to store it to an external MIDI storage device such as the Yamaha MIDI Data Filer MDF3 by using the Bulk Data Dump function described on page 36.
  • Page 27: The Function Mode

    The Function Mode The [FUNCTION] button provides access to a range of functions that give the Clavinova extraordinary versatility. The functions are categorized in groups as follows: CLP-840/ CLP-880/ 820/820S 860 – – FUNCTION TEMPO FUNCTION Operation Example Press [+/YES] (sub-mode) Use FUNCTION [<], [>] Press [–/NO] or [+/YES]...
  • Page 28: F1 Tuning

    The Function Mode Tuning In addition to the tuning method described on page 22, overall tuning can also be accom- plished via the F1 function. After selecting “F1”, use the [–/NO] and [+/YES] buttons to lower or raise the pitch in approximately 0.2 Hz increments (the first time the [–/NO] or [+/YES] button is pressed simply switches to the tuning value display without actually changing the tuning).
  • Page 29: F3 Dual Mode Functions

    Dual Mode Functions After selecting “F3. Y ”, press the [+/YES] button to engage the dual-mode function sub- mode, then use the FUNCTION [<] and [>] buttons to select the desired dual mode func- tion, as listed below. If the Dual mode is not engaged “F3. - ” will appear instead of “F3. Y ” and the Dual mode functions cannot be selected.
  • Page 30: F3.5: 1St Voice Effect Depth (Clp-880/860/840)

    The Function Mode F3.5: 1st Voice Effect Depth F3.6: 2nd Voice Effect Depth These functions make it possible to individually set the depth of the effect for the 1st and 2nd dual-mode Voices (“1st” and “2nd” is explained on page 16). Use the [–/NO] and [+/ YES] buttons to set the effect depth for the corresponding voice as required.
  • Page 31: F4.3: Right Voice Octave Shift

    F4.3: Right Voice Octave Shift F4.4: Left Voice Octave Shift Depending on which voices you combine using the split mode, the combination may sound better if one of the voices is shifted up or down an octave. Use the [–/NO] and [+/YES] buttons to set the octave of the Left or Right Voice as required.
  • Page 32: F4 Clp-840/820/820S Left Pedal Mode

    The Function Mode CLP-840/820/820S Left Pedal Mode This function sets the left pedal for normal soft-pedal operation, for song start/stop opera- tion, or for sostenuto (CLP-820S only) operation. Use the [–/NO] and [+/YES] buttons to select the desired left-pedal mode. “1” is the normal soft-pedal mode, “2” is the start/stop mode, and “3”...
  • Page 33: F5 Clp-840/820/820S Metronome Volume

    CLP-840/820/820S Metronome Volume CLP-880/860 Metronome Volume SHORTCUT: You can jump directly to the metronome functions by pressing the [FUNC- The volume of the metronome sound can be changed. After selecting “F5” or “F6”, use the [–/NO] and [+/YES] buttons to set the metronome volume as required. The volume range is from 1 through 20.
  • Page 34: F7 Clp-840/820/820S Midi Functions

    The Function Mode CLP-840/820/820S MIDI Functions CLP-880/860 MIDI Functions A Brief Introduction to MIDI MIDI Cable MIDI OUT Clavinova note and velocity (touch response) information via the MIDI OUT connector whenever a note is played on the keyboard. If the MIDI OUT connector is connected to the MIDI IN connector of a second keyboard (synthesizer, etc.) or a tone generator (essentially a synthesizer with no keyboard), the second keyboard or tone generator will respond precisely to notes played on the original transmitting keyboard.
  • Page 35: F7.3/F8.3: Local Control On/Off

    In any MIDI control setup, the MIDI channels of the transmitting and receiving equipment must be matched for proper data transfer. A “Multi-timbre” receive mode is also available, which allows simultaneous reception of different parts on all 16 MIDI channels, allowing the Clavinova to play multi-channel song data received from a music computer or sequencer.
  • Page 36: F7.5/F8.5: Control Change On/Off

    MIDI OUT terminal. This is particularly useful if you will be recording performances to a MIDI sequence recorder such as the Yamaha MIDI Data Filer MDF3 which will be used to control the Clavinova on playback. By transmitting the Clavinova panel set-...
  • Page 37: F8 Clp-840/820/820S Backup Functions

    CLP-840/820/820S Backup Functions CLP-880/860 Backup Functions After selecting “F8. Y ” or “F9. Y ”, press the [+/YES] button to engage the backup function sub-mode, then use the FUNCTION [<] and [>] buttons to select the desired backup func- tion, as listed below. •...
  • Page 38: Connecting To A Personal Computer

    Connecting to a Personal Computer Although the Clavinova can be connected to a personal computer via the MIDI IN/OUT connectors and a MIDI interface, the TO HOST connector and HOST SELECT switch allow direct connection to Apple Macintosh or IBM-PC/AT personal computers for sequencing and other music applications without the need for a separate MIDI interface.
  • Page 39: Connecting To An Ibm-Pc/At Series Computer

    HOST SELECT switch to “PC-1”. • When using the TO HOST terminal to connect to a personal computer using Windows, a Yamaha MIDI driver must be installed in the personal computer. The Yamaha MIDI driver can be obtained at Yamaha’s home page on the World Wide Web, <http://www.yamaha.co.jp/english/xg/>.
  • Page 40: Factory Preset Recall

    If “Scn” appears on the display an internal malfunction has occurred. In this case, contact your Yamaha dealer. Options & Expander Modules Options BC-8 Bench A comfortable bench styled to match your Yamaha Clavinova. HPE-160 Stereo Headphones High-performance lightweight dynamic headphones with extra-soft ear pads.
  • Page 41: Demo Song List

    • Certains morceaux de démonstration énumérés ci-dessus sont de courts extraits des compositions originales. Les morceaux originaux sont protégés par la loi sur les droits d’auteur (© 1998 par YAMAHA CORPORATION). • Algunas de las piezas de demostración arriba mencionadas son pasajes cortos de las composiciones originales.
  • Page 42: Factory Setting List

    Factory Setting List/Liste der Vorgabeeinstellungen/ Liste des réglages/Lista de ajustes de fábrica Voice Dual Mode Split Mode Split Mode Left Voice Reverb Type Reverb Depth Effect Type Effect Depth Touch Sensitivity Volume in the FIXED Mode Metronome Metronome Time Signature Tempo Transpose Function...
  • Page 43: Midi Data Format

    MIDI Data Format/MIDI-Datenformat/ Format des données MIDI/Formato de datos MIDI If you’re already very familiar with MIDI, or are using a computer to control your music hardware with computer- generated MIDI messages, the data provided in this section can help you to control the Clavinova. Falls Sie bereits mit MIDI vertraut sind oder einen Compu- ter zur Erzeugung von MIDI-Steuermeldungen für die Instrumente verwenden, können Sie sich zur Steuerung des...
  • Page 44 • Caution: If an error occurs during MIDI reception, the Damper, Sostenuto, and Soft effects for all channels are turned off and an All Note Off occurs. 6. SYSTEM EXCLUSIVE MESSAGES (Yamaha MIDI Format) Panel Data Transmit Data format: [F0H] -> [43H] -> [0nH] -> [7CH] -> ... ->...
  • Page 45 (1) XG Native Parameter Change Data format: [F0H] -> [43H] -> [1nH] -> [4CH] -> [hhH] -> [mmH] -> [ll H] -> [ddH] -> [F7H] = Exclusive status = YAMAHA ID = When received, n=0~F. When transmitted, n=0. = Model ID of XG...
  • Page 46 MIDI Data Format/MIDI-Datenformat/Format des données MIDI/Formato de datos MIDI <Table 1> MIDI Parameter Change table ( SYSTEM ) Address (H) Size (H) Data (H) 00 00 00 020C - 05F4(*1) MASTER TUNE 00 - 7F — 34 - 4C(*2) TOTAL SIZE *1: Values lower than 020CH select -50 cents.
  • Page 47: Midi Implementation Chart

    YAMAHA [Clavinova] Model: CLP-880/860/840/820/820S Function Basic Default Channel Changed 1~16 Default Mode Messages Altered ***************** Note 9~120 Number : True voice ***************** O 9nH, v=1~127 Velocity Note on X 9nH, v=0 Note off After key’s Touch Ch’s Pitch Bender Control Change...
  • Page 48: Clp-880: Keyboard Stand Assembly

    Bundled pedal cord inside Cord holders B and C are already attached on the CLP-880PE. The 5 x 40 mm long gold screws are not supplied with the CLP-880PE. CLP-880: Keyboard Stand Assembly • Be careful not to confuse parts, and be sure to install all parts in the correct direction.
  • Page 49 5 x 40 mm long gold screws It is not necessary to perform this procedure on the CLP-880PE. Assemble the side panels (B) and feet (C). Secure the feet (C) to the side panels (B) with the 5 x 40 millimeter long gold-colored screws 1 (3 each).
  • Page 50 4 x 12 mm round-head screws Attach the front panel (E). The front panel attaches to the front end of the pedal box and side panels. Fit the front panel into position and eliminate any gaps between the front and side panels. Align the small hole in each six brackets and attach the front panel using the six 4 x 12 millimeter round-head screws 3.
  • Page 51 6 x 16 mm flat-head screws Connect the speaker cord. The speaker cord from the speaker box must be plugged into the corresponding connector in the main unit. The plug only goes in one way (the lug on the connector should face the rear of the main unit, as shown in the illustration), so don’t try to force it in the wrong way around.
  • Page 52 4 x 12 mm round-head screws 4 x 20 mm tapping screws Attach the rear panel (F). With the rear panel slightly angled as shown in the illustration, lower it onto the feet’s protruding edge at the rear of the pedal box.
  • Page 53: Connect The Pedal Cord

    < Connect the pedal cord. The pedal cord from the pedal box must be plugged into the PEDAL connector on the rear of the main unit. Once connected, attach the cord holders to the rear panel as shown, then clip the cord into the holders.
  • Page 54 Set the adjuster. For stability, an adjuster is provided on the bottom of the pedal box (D). Rotate the adjuster until it comes in firm contact with the floor surface. The adjuster ensures stable pedal operation and facilitates pedal effect control. If the adjuster is not in firm contact with the floor surface, distorted sound may result.
  • Page 55 • When moving the instrument after assembly, always hold the lower surface of the main unit, NEVER the top portion or keyboard cover. Improper handling can result in damage to the instrument or personal injury. After completing the assembly, please check the following.
  • Page 56: Clp-860/840/820: Keyboard Stand Assembly

    Bundled pedal cord inside Cord holders CLP-860/840/820: Keyboard Stand Assembly The CLP-860/840/820 all require the same assembly procedures. Illustrations use the CLP-860 for reference. • Be careful not to confuse parts, and be sure to install all parts in the correct direction.
  • Page 57 5 x 40 mm long gold screws Secure the feet (E) to the side panels (D) with the 5 x 40 millimeter long gold-colored screws 1 (3 each). Depending on the unit type, the feet (E) may or may not have cutouts.
  • Page 58 4 x 20 mm tapping screws lower it onto the feet’s protruding edge at the rear of the pedal box. Then, while eliminating any gaps between the rear and side panels, secure the top of the rear panel to the side panel brackets using two 4 x 12 mm round-head screws 3.
  • Page 59 10 cm 10 cm Be sure to place your hands at least 10 centimeters from either end of the main unit when positioning it. on its bottom panel (toward the rear of the main unit) just behind the grooves in the brackets located at the top of the side panels. Then slide the main unit forward until it stops.
  • Page 60 Use the vinyl tie that was removed from the bundled pedal cord in step to tie up any slack in the pedal cord. PEDAL connector on the rear of the main unit. Once con- nected, attach the cord holders to the rear panel as shown, then clip the cord into the holders.
  • Page 61 < pedal box (C). Rotate the adjuster until it comes in firm contact with the floor surface. The adjuster ensures stable pedal operation and facilitates pedal effect control. If the adjuster is not in firm contact with the floor surface, distorted sound may result. •...
  • Page 62: Clp-820S: Keyboard Stand Assembly

    Bundled pedal cord inside CLP-820S: Keyboard Stand Assembly • Be careful not to confuse parts, and be sure to install all parts in the correct direction. Please assemble in accordance with the sequence given below. • Assembly should be carried out by at least two persons. •...
  • Page 63 5 x 40 mm long gold screws Assemble the side panels (D) and feet (E). Secure the feet (E) to the side panels (D) with the 5 x 40 millimeter long gold-colored screws 1 (3 each). Depending on the unit type, the feet (E) may or may not have cutouts.
  • Page 64 The center panel (B) is installed between the side panels (D) with the brackets on each end toward the rear of the stand assem- bly. Place the square holes in the center-panel brackets over the lugs extending from the side panels, then slide down. Each side of the center panel is attached using two 6 x 16 flat-head screws CLP-880/860/840/820/820S 6 x 16 mm flat-head screws...
  • Page 65 10 cm Be sure to place your hands at least 10 centimeters from either end of the main unit when posi- tioning it. Install the main unit (A). Place the main unit (A) on the side panels (D) with the screws on its bottom panel (toward the rear of the main unit) just behind the grooves in the brackets located at the top of the side panels.
  • Page 66 Use the vinyl tie that was removed from the bundled pedal cord in step to tie up any slack in the pedal cord. panel. Plug the free end of the cord into the PEDAL connector on the rear of the main unit. the voltage selector which is provided in some areas.
  • Page 67 < For stability, an adjuster is provided on the bottom of the pedal box (C). Rotate the adjuster until it comes in firm contact with the floor surface. The adjuster ensures stable pedal operation and facilitates pedal effect control. If the adjuster is not in firm contact with the floor surface, distorted sound may result.
  • Page 68: Specifications

    • Specifications and descriptions in this owner’s manual are for information purposes only. Yamaha Corp. reserves the right to change or modify products or specifications at any time without prior notice. Since specifications, equipment or options may not be the same in every locale, please check with your Yamaha dealer.
  • Page 69: Important Safety Instructions

    Please make sure that benches are stable and any optional fixtures (where applicable) are well secured BEFORE using. Benches supplied by Yamaha are designed for seating only. No other uses are recommended. CLP-880/860/840/820/820S...
  • Page 70 BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND. • This applies only to products distributed by Yamaha Canada Music Ltd. • Ceci ne s’applique qu’aux produits distribués par Yamaha Canada Musique Ltée. regulations does not guarantee that interference will not occur in all installations.
  • Page 71 For details of products, please contact your nearest Yamaha or the authorized distributor listed below. Pour plus de détails sur les produits, veuillez-vous adresser à Yamaha ou au distributeur le plus proche de vous figurant dans la liste suivante. NORTH AMERICA CANADA Yamaha Canada Music Ltd.
  • Page 72 M.D.G., EMI Division, Yamaha Corporation © 1998 Yamaha Corporation V320140 911POCP2.3-07D0 Printed in Japan This document is printed on chlorine free (ECF) paper.
