- Page 1 OWNER’S MANUAL FJR1300N 5JW-28199-20...
- Page 3 EAU00000 Congratulations on your purchase of the Yamaha FJR1300. This model is the result of Yamaha’s vast experience in the production of fine sporting, touring, and paceset- ting racing machines. It represents the high degree of craftsmanship and reliability that have made Yamaha a leader in these fields.
- Page 4 This manual should be considered a permanent part of this motorcycle and should remain with it even if the motorcycle is subsequently sold. Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most current product information available at the time of printing, there may be minor discrepancies between your motorcycle and this manual.
-
Page 5: Important Manual Information
IMPORTANT MANUAL INFORMATION EW000002 WARNING PLEASE READ THIS MANUAL CAREFULLY AND COMPLETELY BEFORE OPERATING THIS MOTORCYCLE. - Page 6 IMPORTANT MANUAL INFORMATION EAU03337 FJR1300N OWNER’S MANUAL © 2001 by Yamaha Motor Co., Ltd. 1st Edition, March 2001 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.
-
Page 7: Table Of Contents
EAU00009 TABLE OF CONTENTS 1 SAFETY INFORMATION 2 DESCRIPTION 3 INSTRUMENT AND CONTROL FUNCTIONS 4 PRE-OPERATION CHECKS 5 OPERATION AND IMPORTANT RIDING POINTS 6 PERIODIC MAINTENANCE AND MINOR REPAIR 7 MOTORCYCLE CARE AND STORAGE 8 SPECIFICATIONS 9 CONSUMER INFORMATION INDEX... -
Page 9: Safety Information
SAFETY INFORMATION Safe riding ... 1-1 Protective apparel ... 1-3 Modifications ... 1-3 Loading and accessories ... 1-3 Gasoline and exhaust gas... 1-5 Location of important labels ... 1-7... -
Page 10: Safe Riding
S AFETY INFORMATION MOTORCYCLES ARE SINGLE TRACK VEHICLES. THEIR SAFE USE AND OPERATION ARE DE- PENDENT UPON THE USE OF PROPER RIDING TECHNIQUES AS WELL AS THE EXPERTISE OF THE OPERATOR. EVERY OPERATOR SHOULD KNOW THE FOLLOWING REQUIREMENTS BE- FORE RIDING THIS MOTORCYCLE. HE OR SHE SHOULD: 1. - Page 11 4. Many accidents involve inexperienced operators. In fact, many operators who have been involved in accidents do not even have a current motorcycle license. a. Make sure that you are qualified and that you only lend your motorcycle to other qualified opera- tors.
-
Page 12: Protective Apparel
6. A passenger should also observe the above precautions. Modifications Modifications made to this motorcycle not approved by Yamaha, or the removal of original equipment, may render the motorcycle unsafe for use and may cause severe personal injury. Modifications may also make your motorcycle illegal to use. - Page 13 Genuine Yamaha accessories have been specifically designed for use on this motorcycle. Since Yamaha cannot test all other accessories that may be available, you must personally be responsible for the proper selection, installation and use of non-Yamaha accessories. Use extreme caution when select- ing and installing any accessories.
-
Page 14: Gasoline And Exhaust Gas
SAFETY INFORMATION a. Accessories fitted to the handlebar or the front fork area can create instability due to improper weight distribution or aerodynamic changes. If accessories are added to the handlebar or front fork area, they must be as lightweight as possible and should be kept to a minimum. b. - Page 15 3. Always turn the engine off before leaving the motorcycle unattended and remove the key from the main switch. When parking the motorcycle, note the following: a. The engine and exhaust system may be hot, therefore, park the motorcycle in a place where pe- destrians or children are not likely to touch these hot areas.
-
Page 16: Location Of Important Labels
SAFETY INFORMATION Location of important labels Please read the following important labels carefully before operating this motorcycle. WARNING Before you operate this vehicle, read the owner’s manual. English EAU02977 3HP-21568-E0 4AA-22259-40... -
Page 17: Description
DESCRIPTION Left view ... 2-1 Right view... 2-2 Controls and instruments ... 2-3... - Page 18 D ESCRIPTION Left view 1. Fuse box 2. Front fork spring preload adjusting bolt 3. Front fork rebound damping force adjusting knob 4. Engine oil filler cap 5. Owner’s tool kit 6. Rider seat 7. Passenger seat 8. Rear carrier 9.
- Page 19 Right view 17. Passenger footrest 18. Coolant reservoir 19. Battery 20. Windshield 21. Main fuse and fuel injection system fuse 22. Front fork compression damping force adjusting screw 23. Brake pedal 24. Rider footrest (page 6-13) (page 6-29) (page 6-30) (page 3-12) (page 3-7) DESCRIPTION...
- Page 20 DESCRIPTION Controls and instruments 1. Clutch lever 2. Left handlebar switches 3. Tachometer 4. Speedometer 5. Multi-function display 6. Right handlebar switches 7. Brake lever 8. Throttle grip 9. Main switch/steering lock (page 3-6) (page 3-5) (page 3-3) (page 3-3) (page 3-3) (page 3-5) (page 3-7)
-
Page 21: Instrument And Control Functions
INSTRUMENT AND CONTROL FUNCTIONS Main switch/steering lock ... 3-1 Indicator and warning lights ... 3-2 Speedometer ... 3-3 Tachometer ... 3-3 Multi-function display ... 3-3 Handlebar switches ... 3-5 Clutch lever ... 3-6 Shift pedal ... 3-6 Brake lever ... 3-7 Brake pedal ... -
Page 22: Main Switch/Steering Lock
I NSTRUMENT AND CONTROL FUNCTIONS Main switch/steering lock The main switch/steering lock controls the ignition and lighting systems, and is used to lock the steering. The various positions are described below. All electrical systems are supplied with power, and the headlight, meter light- ing and taillight come on, and the en- gine can be started. -
Page 23: Instrument And Control Functions
3. Push the start switch. If the warning light does not come on while push- ing the start switch, have a Yamaha dealer check the electrical circuit. NOTE: Even if the oil level is sufficient, the... -
Page 24: Speedometer
INSTRUMENT AND CONTROL FUNCTIONS 1. Tachometer 2. Speedometer 3. Multi-function display Speedometer The speedometer shows the riding speed. 1. Tachometer 2. Tachometer red zone Tachometer EAU04031 The electric tachometer allows the rider to monitor the engine speed and keep it within the ideal power range. -
Page 25: Self-Diagnosis Device
(e.g., 11, 12, 13). If the clock indicates such an error code, note the code number, and then have a Yamaha dealer check the motorcycle. ECA00100 CAUTION: If the clock indicates an error code,... -
Page 26: Handlebar Switches
INSTRUMENT AND CONTROL FUNCTIONS 1. Pass switch “ ” 2. Windshield position adjusting switch “ 3. Dimmer switch “ ” 4. Turn signal switch “ ” 5. Horn switch “ ” Handlebar switches Pass switch “ ” Press this switch to flash the headlight. Dimmer switch “... -
Page 27: Clutch Lever
EAU00153 Clutch lever The clutch lever is located at the left handlebar grip. To disengage the clutch, pull the lever toward the handle- bar grip. To engage the clutch, release the lever. The lever should be pulled rapidly and released slowly for smooth clutch operation. -
Page 28: Brake Lever
INSTRUMENT AND CONTROL FUNCTIONS Brake lever The brake lever is located at the right handlebar grip. To apply the front brake, pull the lever toward the handle- bar grip. EAU00161 1. Brake lever position adjusting dial 2. Arrow mark 3. Brake lever a. -
Page 29: Fuel Tank Cap
1. Fuel tank cap lock cover 2. Unlock. EAU04068 Fuel tank cap To open the fuel tank cap Open the fuel tank cap lock cover, in- sert the key into the lock, and then turn it 1/4 turn clockwise. The lock will be re- leased and the fuel tank cap can be opened. -
Page 30: Fuel
INSTRUMENT AND CONTROL FUNCTIONS 1. Fuel tank filler tube 2. Fuel level Fuel Make sure that there is sufficient fuel in the tank. Fill the fuel tank to the bottom of the filler tube as shown. WARNING Do not overfill the fuel tank, oth- erwise it may overflow when the fuel warms up and expands. -
Page 31: Seats
1. Rider seat lock 2. Unlock. EAU03945 Seats Rider seat To remove the rider seat 1. Insert the key into the seat lock, and then turn it as shown. 2. Pull the rider seat off. INSTRUMENT AND CONTROL FUNCTIONS 1. Projection 2. -
Page 32: Storage Compartment
INSTRUMENT AND CONTROL FUNCTIONS Storage compartment The storage compartment is located under the passenger seat. (See page 3-10 for passenger seat opening and closing procedures.) WARNING Do not exceed the load limit of 3 kg for the storage compart- ment. Do not exceed the maximum load of 208 kg for the vehicle. - Page 33 1. Current setting 2. Front fork cap bolt NOTE: Align the appropriate groove on the ad- justing mechanism with the top of the front fork cap bolt. CI-01E Stan- Hard Soft dard Setting INSTRUMENT AND CONTROL FUNCTIONS Rebound damping force To increase the rebound damping force and thereby harden the rebound damping, turn the adjusting knob on...
-
Page 34: Adjusting The Shock Absorber Assembly
INSTRUMENT AND CONTROL FUNCTIONS CAUTION: Never attempt to turn an adjusting mechanism beyond the maximum or minimum settings. NOTE: Although the total number of clicks of a damping force adjusting mechanism may not exactly match the above spec- ifications due to small differences in production, the actual number of clicks always represents the entire adjusting range. - Page 35 Do not deform or damage the gas cylinder in any way, as this will result in poor damping per- formance. Always have a Yamaha dealer service the shock absorber. 3-14...
-
Page 36: Matching The Front And Rear Suspension Settings
INSTRUMENT AND CONTROL FUNCTIONS Matching the front and rear suspension settings Use this table as a guide to match the suspension and damping adjustments of the front fork and shock absorber assembly according to various load conditions. CI-11E Load condition Spring preload Rider only With passenger or cargo... -
Page 37: Locks For The Optional Side Cases And Travel Trunk
When used to replace the locks of the optional side cases and travel trunk, which can be obtained at a Yamaha dealer, these locks can be operated with the ignition key. Keep these locks in a safe place to prevent losing them. -
Page 38: Ignition Circuit Cut-Off System
EAU03741 WARNING The vehicle must be placed on the centerstand during this in- spection. If a malfunction is noted, have a Yamaha dealer check the sys- tem before riding. 3-17 EW000046... - Page 39 ”. The neutral switch may be defective. The motorcycle should not be ridden until checked by a Yamaha dealer. The sidestand switch may be defective. The motorcycle should not be ridden until checked by a Yamaha dealer.
-
Page 41: Pre-Operation Checks
PRE-OPERATION CHECKS Pre-operation check list ... 4-1... - Page 42 • If necessary, add recommended coolant to specified level. • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. Front brake • Check fluid level in reservoir. • If necessary, add recommended brake fluid to specified level.
- Page 43 ITEM • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. Clutch • Check fluid level in reservoir. • If necessary, add recommended brake fluid to specified level. • Check hydraulic system for leakage. • Make sure that operation is smooth.
- Page 44 PRE-OPERATION CHECKS NOTE: Pre-operation checks should be made each time the motorcycle is used. Such an inspection can be accomplished in a very short time; and the added safety it assures is more than worth the time involved. EWA00033 WARNING If any item in the Pre-operation check list is not working properly, have it inspected and repaired before operating the motorcycle.
-
Page 45: Operation And Important Riding Points
OPERATION AND IMPORTANT RIDING POINTS Starting and warming up a cold engine ... 5-1 Shifting ... 5-2 Tips for reducing fuel consumption ... 5-3 Engine break-in ... 5-3 Parking ... 5-4... -
Page 46: Starting And Warming Up A Cold Engine
NOTE: engine, When the transmission is in the neutral position, the neutral indicator light should be on, otherwise have a procedure Yamaha dealer check the electrical cir- cuit. 3. Start the engine by pushing the start switch. EAU00372 ECA00083 light... -
Page 47: Shifting
NOTE: If the engine fails to start, release the start switch, wait a few seconds, and then try again. Each starting attempt should be as short as possible to pre- serve the battery. Do not crank the en- gine more than 10 seconds on any one attempt. -
Page 48: Tips For Reducing Fuel Consumption
The vehicle can now be operated nor- mally. CAUTION: Keep the engine speed out of the tachometer red zone. If any engine trouble should oc- cur during the engine break-in period, immediately Yamaha dealer check the vehicle. EAU04032* above above EC000056* EC000053 have... -
Page 49: Parking
EAU00461 Parking When parking, stop the engine, and then remove the key from the main switch. EW000058 WARNING Since the engine and exhaust system can become very hot, park in a place where pedestri- ans or children are not likely to touch them.
