Yamaha YHT-385BG Specifications

With serious sound performance and user-friendly features , the YHT-
385BG comes supplied with Yamaha's universal iPod dock, the YDS-
10S.
Advanced Facilities
1
• Compressed Music Enhancer
• Compatible with iPod via INCLUDED Yamaha YDS-10S
• Front panel mini jack for portable player connection
• On-screen display
High Sound Quality
• 6.1-channel, powerful surround sound:
2
570W=95W x 6 RMS; 810W=135W x 6 Max
• Digital ToP-ART and High Current Amplification
• Direct Stereo for high quality 2-channel sound reproduction
• 192kHz/24-Bit DACs for all channels
High Picture Quality
3
• HDTV compatible 3 component video inputs
• Component video up-conversion
• Digital video processing with TBC (Time Base Corrector)
Superior Speaker Design
4
• Two-way acoustic suspension design featuring coaxial and full-
range drivers (main/rear/rear centre) and coaxial plus dual full-
range drivers (centre).
• Excellent sound quality and smart, compact design.
• Magnetic Shielding Allows Placement Near a TV (All Speakers)
YHT-385BG
6.1 Channel Home Theatre Package
* iPod not included
YHT-385BG Main Specifications
Receiver (HTR-5950S)
Minimum RMS Output Power
(8 ohms, 20 Hz—20 kHz, 0.06% THD)
Front L/R Channels
Centre Channel
Surround L/R Channels
Surround Back Channel
Dynamic Power (1 kHz)
8/6/4/2 ohms
Total Harmonic Distortion (CD, Front Sp Out)
(50 W/8 ohms)
Dimensions (W x H x D)
Weight
Speakers—Front and Surrounds (NS-P436BG)
Design
Woofers
Magnetically Shielded
Frequency Response
Input Power (Max./Nom.)
Sensitivity
Impedance
Dimensions (W x H x D)
Weight
Speakers—Centre (NS-P436BG)
Design
Woofers
Magnetically Shielded
Frequency Response
Input Power (Max./Nom.)
Sensitivity
Impedance
Dimensions (W x H x D)
Weight
95 W + 95 W
95 W
95 W + 95 W
95 W
130/165/195/240 W
0.06%
435 x 161 x 391 mm
10.5 kg
2-way acoustic suspension
5cm Coaxial two-way driver
5cm Full range driver
Yes
30 Hz–60 kHz
100 W/30 W
85 dB/2.83 V/1 m
6 ohms
87 x 184 x 147 mm
1.2 kg
2-way acoustic suspension
5cm Coaxial two-way driver
Dual 5cm Full range driver
Yes
30 Hz–60 kHz
100 W/30 W
86 dB/2.83 V/1 m
6 ohms
273 x 81 x 147 mm
1.7 kg
