Version 1.10 upgrade manual.
Hide thumbs


Advertisement

Version 1.10 of the Clavinova firmware adds the following functionality to CVP-501, CVP-503, CVP-505, and
CVP-509 models.
• Support for the Wi-Fi Protected Access (WPA) wireless encryption standard (with the exception of certain
USB-LAN adaptors
• Support for the Wi-Fi Protected Setup (WPS)
networks (with the exception of certain USB-LAN adaptors
• Support for the following USB-LAN adaptors.
Wireless: Buffalo WLI-UC-GN
Edimax EW-7711UAn
Belkin F6D4050
Wired:
LINKSYS USB300M
macally AIR2NET
*
1: For more details, please visit the Yamaha Piano / Keyboard website (below) and refer to the list of USB devices confirmed as
working with our products. http://music.yamaha.com/download
*2: For more details, please refer to the Internet Connection Guide, which can be downloaded from the Yamaha Manual Library
website. http://www.yamaha.co.jp/manual/english/
Confirming the Current Version
1.
Turn on the Clavinova.
This can be done by pressing the Power switch located at
the right of the front panel.
2.
Confirm the instrument's current firmware
version as follows.
2-1
Press the [FUNCTION] button.
2-2
Press the [J] (UTILITY) button.
2-3
E
F
Using the TAB [
] / [
] buttons, select the OWNER tab
and display the Owner setting screen.
2-4
Press the [7
] (VERSION) button to display the current
firmware version. If the displayed version number is less
than 1.10, the firmware should be upgraded.
CVP-509/505/503/501
Version 1.10 Upgrade Manual
*1
)
*2
standard, which makes it easier to setup wireless home
Buffalo WLI-UC-GNHP Planex GW-USMicroN
Edimax EW-7711UTn
LogiLink WL0049A
AIRLINK101 ASOHOUSB 10/100Mbps Fast Ethernet USB 2.0 Adapter
INTELLINET Hi-Speed USB 2.0 to Fast Ethernet Adapter
*1
)
Planex GW-USMini2N
Hawking HWUN3
Tenda W311U
LogiLink WL0054
2-5
Press the [8
] (EXIT) button or the [EXIT] button to close
the window.
3.
Turn off the Clavinova.
This can be done by pressing the Power switch located at
the right of the front panel.
Upgrading the Firmware
To upgrade the Clavinova firmware, place the upgrade data on a
USB flash memory device and then carry out the upgrading
procedure as described below.
1.
Plug the USB flash memory device containing
the upgrade data into the Clavinova.
2.
Hold down the [START/STOP] button and press
the Power switch
Continue to hold down the [START/STOP] button until the
following message is displayed.
3.
Install the upgrade data.
To do so, release the [START/STOP] button and then press
it once again.
1
