- Page 1 DVD PLAYER LECTEUR DE DVD DV-S5950 HDMI...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. • Explanation of Graphical Symbols The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert you to the presence of uninsulated “dangerous... - Page 3 - and, most importantly, without affecting your sensitive hearing. Since hearing damage from loud sounds is often undetectable until it is too late, YAMAHA and the Electronic Industries Association’s Consumer Electronics Group recommend you to avoid prolonged exposure from excessive volume levels.
- Page 4 YAMAHA will not be held responsible for any damage resulting from use of this unit with a voltage other than as specified.
-
Page 5: Table Of Contents
Introduction Region codes ...3 Supplied accessories ...3 Notes about discs/content format...3 Cleaning discs...4 Patent information ...4 Functional Overview Front panel ...5 Rear panel ...5 Remote control ...6 Connections General notes on connections...7 Audio connections...7 Digital connection ...7 Analog connection...7 Video connections ...8 Component video jacks <A>...8 S-video jack <B>... - Page 6 Contents Setup Menu General setup menu ... 22 Locking/Unlocking the disc for viewing...22 Dimming the front panel display...22 Programming disc tracks (except MP3/WMA/ JPEG/DivX)...22 OSD language ...23 Screen saver ...23 Sleep timer ...23 Auto standby...24 ® DivX VOD registration code...24 Audio setup menu...
-
Page 7: Introduction
Thank you for purchasing this unit. This Owner’s Manual explains the basic operation of this unit. Region codes DVD discs must be labeled ALL regions or Region 1 in order to play on this unit. You cannot play discs labeled for other regions. -
Page 8: Cleaning Discs
Introduction Cleaning discs • When a disc becomes dirty, clean it with a cleaning cloth. Wipe the disc from the center out. Do not wipe in a circular motion. • Do not use solvents such as benzine, thinner, commercially available cleaners, or antistatic spray intended for analog records. -
Page 9: Functional Overview
Front panel STANDBY/ON Turns on this unit or sets it to the standby mode. Disc tray Loads a disc in the disc tray. OPEN/CLOSE (/) Opens or closes the disc tray. HDMI indicator Lights up when an HDMI component is connected, and signals output via the HDMI jack of this unit. -
Page 10: Remote Control
Functional Overview Remote control TOP MENU RETURN ON SCREEN MENU SETUP ENTER STOP PLAY PAUSE SUBTITLE ANGLE ZOOM AUDIO REPEAT SCAN MUTE DVD13 Turns on this unit or sets it to the standby mode. TOP MENU/RETURN Displays the top-level disc (DVD). Moves back to the previous menu (DVD*/ VCD). -
Page 11: Connections
General notes on connections Be sure to turn off this unit and unplug the power supply cable, before you make or change connections. • Depending on the equipment you wish to connect, there are various ways to make connections. Possible connections are described below. -
Page 12: Video Connections
Connections Video connections If your AV receiver has video output jacks, connect your receiver and then your TV so that you can use one TV for several different video sources (LD, VCR, etc.) by simply switching the input source selector of your receiver. -
Page 13: Hdmi Connections
HDMI connections HDMI jack Connect the HDMI output jack of this unit to an HDMI input jack of your TV using a commercially available HDMI cable. HDMI HDMI cable HDMI IN You need to set “HDMI AUDIO” (see page 26) and “HDMI VIDEO” (see page 30). Notes: –... -
Page 14: Getting Started
Getting Started Step 1: Inserting batteries into the remote control 1 Open the battery compartment. 2 Insert the two supplied batteries (AA, R06, UM-3) following the indications (+/–) inside the compartment. 3 Close the cover. Notes: – Insert batteries correctly according to the polarity markings (+/–). -
Page 15: Step 2: Turning On The Power
Step 2: Turning on the power 1 Connect the AC power cord to the power outlet. 2 Turn on your TV and AV receiver. 3 Select the appropriate input source of the AV receiver connected to this unit. Refer to the manual supplied with your AV receiver for details. -
Page 16: Setting An Aspect Ratio For Your Tv
Getting Started Setting an aspect ratio for your You can set the aspect ratio of this unit to match your TV. If the aspect ratio of your TV is 4:3, you do not need to change this setting. If you have a widescreen TV, change this setting according to the following procedure. -
Page 17: Setting The Audio, Subtitle And Disc Menu Languages (Dvd-Video Only)
Setting the audio, subtitle and disc menu languages (DVD-Video only) PREFERENCE PAGE AUDIO ENGLISH SUBTITLE CHINESE (SIMP) DISC MENU FRENCH PARENTAL SPANISH VR LIST PORTUGUESE MP3/JPEG NAV POLISH DIVX SUBTITLE ITALIAN PASSWORD TURKISH 1 Press STOP (9) twice, and then press SETUP. -
Page 18: Disc Operation
Disc Operation IMPORTANT! – If the inhibition icon ( on the TV screen when a button is pressed, the function for that button is not available on the current disc or at the current time. – Depending on the DVD or VIDEO CD disc, some operations may operate differently or be restricted. -
Page 19: Selecting The Various Repeat/Shuffle Functions
Selecting the various repeat/ shuffle functions Repeat and shuffle • Each time you press REPEAT during playback, the front panel display changes as follows: RPT ONE (repeat chapter) RPT TT (repeat title) RPT ALL (repeat disc) SHUFFLE (shuffle) RPT SHF (shuffle repeat) RPT OFF (repeat off) VCD/SVCD/CD RPT ONE (repeat track) -
Page 20: Zooming In
Disc Operation Zooming in This function allows you to enlarge or lessen the picture on the TV screen and to pan through the enlarged picture. 1 During playback, press ZOOM repeatedly to display the picture at different scales. • Use to pan through the 1 / 2/3 / 4 enlarged picture. -
Page 21: Special Dvd Features
Title/Chapter/Track selection (DVD/VCD) 1 Press 3 / 4 to select [TITLE] or [CHAPTER] (DVD) or [TRACK] (VCD). 2 Press ENTER/OK to confirm the selection. 3 Select a title, chapter or track number using the numeric buttons (0-9). Time search (DVD/VCD) 1 Press 3 / 4 to select [TT TIME] or [CH TIME] (DVD) or [TRACK TIME] or [DISC TIME] (VCD). -
Page 22: Audio
Disc Operation Audio Changing the audio language and/or format • Press AUDIO repeatedly to select an audio language. Subtitles • Press SUBTITLE repeatedly to select a subtitle language. Special VCD/SVCD features Playback control (PBC) For VCD with playback control (PBC) feature (version 2.0 only) Press MENU to toggle between “PBC ON”... -
Page 23: Playing Data Discs (Mp3/Wma/Jpeg/Divx)
3 Press ENTER/OK. Thumbnail pictures appear on the TV screen. TYPE:TITLE SELECT(01-06):- - EXIT MENU (Example of 6 thumbnails in the display) 4 Use to select a track or use the 1 / 2/3 / 4 numeric buttons (0-9) to input the selected track number. -
Page 24: Selecting A Folder And Track/File
Disc Operation Selecting a folder and track/file 1 Press 3 / 4 to select a folder, and then press ENTER/OK to open the folder. 2 Press 3 / 4 to select a track/file. 3 Press ENTER/OK to confirm your selection. Playback starts from the selected file to the end of the folder. -
Page 25: Playback With Multi-Angles
Playback with multi-angles • During playback, press rotate the picture on the TV screen. 1: rotates the picture counter-clockwise 2: rotates the picture clockwise 3: flips the picture vertically 4: flips the picture horizontally Scan effect • Press ANGLE repeatedly to choose a scan effect. -
Page 26: Setup Menu
Setup Menu Setup is carried out on the TV screen, enabling you to customize this unit to suit your own particular requirements. General setup menu 1 Press SETUP 2 Press 1 / 2 to select “GENERAL SETUP PAGE”. 3 Press ENTER/OK to confirm your selection. -
Page 27: Osd Language
PROGRAM: TRACK (01-17) 1 04 6 _ _ 2 10 7 _ _ 3 _ _ 8 _ _ 9 _ _ 4 _ _ 10 _ _ 5 _ _ EXIT START To input your favorite tracks/chapters 3 Use the numeric buttons (0-9) to enter a valid track/chapter number. -
Page 28: Auto Standby
2 Press 3 / 4 to select a setting, and then press ENTER/OK to confirm your selection. ® DivX VOD registration code Yamaha provides you with a DivX (Video On Demand) registration code that allows you to rent and purchase videos ® using the DivX VOD service. -
Page 29: Setting The Digital Output
VIRTUAL SURR Select this to virtually reproduce the surround channels. 2 Press 3 / 4 to select a setting, and then press ENTER/OK to confirm your selection. Setting the digital output The [DIGITAL AUDIO] options are: “DIGITAL OUTPUT” and “LPCM OUTPUT”. -
Page 30: Setting The Hdmi Audio
Setup Menu Setting the HDMI audio When you connect this unit to an HDMI compatible component via the HDMI jack, select to turn on or off the HDMI audio output. 1 In ‘AUDIO SETUP PAGE’, press 34 to highlight [HDMI AUDIO], then press 2. Select this to turn on the HDMI audio output. -
Page 31: Lip Synchronization
Select this to level out the volume. This feature is only available for movies with the Dolby Digital mode. Select this when you want to enjoy the full dynamic range of surround sound. 2 Press 3 / 4 to select a setting, and then press ENTER/OK to confirm your selection. -
Page 32: Progressive
VIDEO MONITOR COMPATIBILITY WITH THIS MODEL 525P AND 625P DVD PLAYER, PLEASE CONTACT OUR CUSTOMER SERVICE CENTER. This unit is compatible with the complete line of YAMAHA products, including the projectors DPX-1300, DPX-830 and the plasma monitor PDM-4220. SETUP progressive scan. -
Page 33: Picture Setting
Picture setting This unit comes with three predefined sets of picture color settings and one personal setting that you can define yourself. 1 In “VIDEO SETUP PAGE”, press 3 / 4 to highlight [PICTURE SETTING], and then press 2. STANDARD Select this for the standard picture setting. -
Page 34: Selecting The Black Level
Setup Menu Selecting the black level If you set the TV type to NTSC, set the black level shift to ON to improve the color contrast during playback. The black level setting has no effect if the TV type is set to PAL. -
Page 35: Preference Setup Menu
HDMI VIDEO Enables you to adjust the resolution depending on the monitor you are using. Note: – For settings other than [AUTO], HDMI video output may not be display properly if a resolution output setting is not supported by the HDMI-compatible monitor you are using. -
Page 36: Audio, Subtitle And Disc Menu
Setup Menu Audio, subtitle and disc menu These menus contain various language options for the audio, subtitles and disc menus recorded on the DVD-Video. For details, see “Setting the audio, subtitle and disc menu languages (DVD-Video only)” on page 13. Restricting playback with parental control Some DVDs may have a parental level... - Page 37 To play back a disc in VR format 3 Press SETUP to close the setup menu. 4 Press PLAY (B) to begin to play back the setting you selected. Previewing VR format 5 During playback, press SCAN. A list appears on the TV screen. SELECT DIGEST TYPE: TITLE DIGEST TITLE INTERVAL...
-
Page 38: Mp3/Jpeg Menu
Setup Menu MP3/JPEG menu MP3/JPEG Navigator can be set only if the disc was recorded with a menu. It allows you to select different display menus for easy navigation. 1 In “PREFERENCE PAGE”, press 3 / 4 to highlight [MP3/JPEG NAV], and then press 2. -
Page 39: Changing The Password
Changing the password The same password is used for both parental control and disc lock. Enter your six-digit password when prompted on the screen. The default password is 000 000. 1 In “PREFERENCE PAGE”, press 3 / 4 to highlight [PASSWORD], and then press 2 to select [CHANGE]. - Page 40 Language Codes These codes can be used to select other languages. This does not affect the options in “AUDIO”, “SUBTITLE” or “DISC MENU”. Abkhazian Afar Afrikaans Albanian Amharic Arabic Armenian Assamese Avestan Aymara Azerbaijani Bashkir Basque Belarusian Bengali Bihari Bislama Bokmål, Norwegian Bosnian Breton...
- Page 41 These codes can be used to select other languages. This does not affect the options in “AUDIO”, “SUBTITLE” or “DISC MENU”. Maori Marathi Marshallese Moldavian Mongolian Nauru Navaho, Navajo Navajo; Navaho Ndebele, North Ndebele, South Ndonga Nepali Northern Sami North Ndebele Norwegian Norwegian Bokmål;...
- Page 42 Refer to the chart below when this unit does not function properly. If the problem you are experiencing is not listed below or if the instruction below does not help, set this unit to the standby mode, disconnect the power cord, and contact the nearest authorized YAMAHA dealer or service center. Problem No power...
- Page 43 Problem No audio at digital output Disc does not play Picture freezes momentarily during playback This unit does not respond to the remote control Buttons do not work This unit does not respond to some operating commands during playback This unit cannot read CDs/ DVDs Menu items cannot be selected...
- Page 44 Glossary Analog: Sound that has not been turned into numbers. Analog sound varies, while digital sound has specific numerical values. These jacks send audio through two channels, the left and right. Aspect ratio: The ratio of vertical and horizontal sizes of a displayed image. The horizontal vs.
- Page 45 HDCP: HDCP (High-bandwidth Digital Content Protection) developed by Intel corporation, is a method to encrypt digital video and audio data for purpose of content protection. For further information on HDCP, visit the HDCP website at “www.digital-cp.com”. Interactive menu: Interactive video menus offer unprecedented convenience and control so you can quickly navigate between various scenes or bonus features, and select from audio track...
- Page 46 Specifications PLAYBACK SYSTEM DVD Video Video CD & SVCD PICTURE CD CD-R, CD-RW DVD+R, DVD+RW, DVD+R DL DVD-R, DVD-RW, DVD-R DL VIDEO PERFORMANCE Video (CVBS) Output 1 Vpp into 75 ohm S-Video output Y: 1 Vpp into 75 ohm C: 0.3 Vpp into 75 ohm Component video output Y: 1 Vpp into 75 ohm 75 ohm...
