Thank you for selecting this YAMAHA Compact Disc Player.
OWNER'S MANUAL
CONTENTS
Safety Instructions.................... 2
Connections ............................. 4
Loading the Disc/Disc Play....... 6
Random-Sequence Play .......... 9
Repeat Play.............................. 9
Program Play.......................... 10
Index Search .......................... 11
Recording to Tape ................. 12
Control Transmitter ................. 16
Compact Discs ....................... 16
Troubleshooting ...................... 17
Specifications ......................... 17
CDX-470
Natural Sound Compact Disc Player
Random Access Programmable Play
Single Track/Entire Disc Repeat Play
Automatic Tape-Programming
Automatic Peak Level Searching Capability
Display Brightness Changing Capability
IMPORTANT!
Please record the serial number of this
unit in the space below.
Model:
Serial No.:
The serial number is located on the rear
of the unit.
Retain this Owner's Manual in a safe
place for future reference.
WARNING
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE
THIS UNIT TO RAIN OR MOISTURE.
Random-Sequence Play
Remote Control Capability
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK), NO USER-SERVICEABLE
PARTS INSIDE, REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
• Explanation of Graphical Symbols
The lightning flash with arrowhead
symbol, within an equilateral triangle,
is intended to alert you to the
presence of uninsulated "dangerous
voltage" within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended to alert
you to the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the
appliance.
Advertisement
Table of Contents
Related Manuals for Yamaha YHT-470
Summary of Contents for Yamaha YHT-470
-
Page 1: Table Of Contents
Thank you for selecting this YAMAHA Compact Disc Player. OWNER’S MANUAL CONTENTS Safety Instructions... 2 Connections ... 4 Identification of Components... 5 Loading the Disc/Disc Play... 6 Random-Sequence Play ... 9 Repeat Play... 9 Program Play... 10 Index Search ... 11 Track Programming for Recording to Tape ... -
Page 2: Safety Instructions
SAFETY INSTRUCTIONS Read Instructions – All the safety and operating instructions should be read before the unit is operated. Retain Instructions – The safety and operating instructions should be retained for future reference. Heed Warnings – All warnings on the unit and in the operating instructions should be adhered to. - Page 3 – and, most importantly, without affecting your sensitive hearing. Since hearing damage from loud sounds is often undetectable until it is too late, YAMAHA and the Electronic Industries Association’s Consumer Electronics Group recommend you to avoid prolonged exposure from excessive volume levels.
-
Page 4: Connections
• Before making any connections, switch OFF the power to the unit and the amplifier or other component. • Connect the “LINE OUT” terminals to the “CD” (or “AUX”) terminals of the amplifier. If the amplifier does not have such terminals, use the “TAPE PB”... -
Page 5: Identification Of Components
IDENTIFICATION OF COMPONENTS FRONT PANEL POWER switch Disc tray NATURAL SOUND COMPACT DISC PLAYER POWER REMOTE CONTROL TRANSMITTER * The control functions on the main unit and on the remote control transmitter are virtually identical, with the exceptions below. Display panel Remote control sensor OPEN/CLOSE Numeric buttons... -
Page 6: Loading The Disc/Disc Play
LOADING THE DISC/DISC PLAY POWER Label side upward OPEN/CLOSE Display information at disc play Shows the track number to be played. Shows the time displays. (Refer to “Selecting time displays” on page 8.) Displays the numbers that correspond to the numbers of tracks (as high as number 20) on the disc. - Page 7 To stop play temporarily PAUSE To resume play, press the PAUSE button again or press the PLAY button. DIRECT PLAY Select a desired track using the numeric button. The selected trak number is displayed Example: To select track 25 Press twice, then immediately press If a track number higher than the highest track number on the disc is selected, the last track on the disc will be...
-
Page 8: Changing Brightness Of The Display
Selecting time displays You can select any of the four time displays by pressing the TIME display modeselect button. Elapsed time of the track now playing Remaining time of the track now playing Note The remaining time will not be displayed for track number 25 or higher. -
Page 9: Random-Sequence Play
RANDOM-SEQUENCE PLAY You can have the unit play the tracks on a disc in a random sequence selected by the unit’s microcomputer. To perform random-sequence play RANDOM To cancel random-sequence play RANDOM You can play any desired track or the entire disc repeatedly by pressing the REPEAT button. The repeat play mode will change whenever you press the REPEAT button. -
Page 10: Program Play
You can enjoy listening to your favorite tracks in any desired order using programmed play. As many as 25 tracks can be programmed for a disc. Stop the unit. STOP PROG Display information during program play Shows the program number for the track to be set next. Shows the selected track number. -
Page 11: Index Search
To stop program play Press the STOP button. The first track number programmed will be displayed. To resume play, press the PLAY button. Play will begin from the beginning of the program. To cancel a programmed setting There are several methods, as described below. •... -
Page 12: Track Programming For Recording To Tape
TRACK PROGRAMMING FOR RECORDING TO TAPE This convenient feature can be used to program tracks on a disc for recording to tape. By only memorizing the tape’s total possible recording time, the unit will automatically program tracks or help you to program tracks so they will fit onto the tape with the least amount of unrecorded space remaining at each end of the tape. - Page 13 Manual tape-programming This is for recording desired tracks in any desired order onto a tape. Follow steps 1 – 3 on page 12. PROG Select the track numbers (to be recorded on side A) in the desired order. * Programmed track numbers are illuminated on the display.
- Page 14 Random sequential tape-programming The unit will automatically program tracks in random sequential order for recording to tape. Follow steps 1 – 3 on page 12. RANDOM * The unit will automatically program tracks for side A and side B separately considering the tape’s total time. Begin recording on the tape deck and press the PLAY button on this unit at the same time.
- Page 15 Automatic searching of the peak level on a disc This convenient feature automatically searches the part on a disc where the source level peaks, and next plays the part repeatedly. For recording to tape, this feature is very helpful to adjust the recording level on the tape deck. Stop the unit.
-
Page 16: Notes About The Remote Control Transmitter
NOTES ABOUT THE REMOTE CONTROL TRANSMITTER Battery installation Battery replacement If you find that the remote control transmitter must be used closer to the main unit, the batteries are weak. Replace both batteries with new ones. Notes • Use only AA, R6, UM-3 batteries for replacement. •... -
Page 17: Troubleshooting
If the unit fails to operate normally, check the following points to determine whether the fault can be corrected by the simple measures suggested. If it cannot be corrected, or if the fault is not listed in the SYMPTOM column, disconnect the power cord and contact your authorized YAMAHA dealer or service center for help. SYMPTOM The player does not switch ON when the POWER switch is pressed. - Page 18 YAMAHA ELECTRONICS (UK) LTD. YAMAHA HOUSE, 200 RICKMANSWORTH ROAD WATFORD, HERTS WD1 7JS, ENGLAND YAMAHA SCANDINAVIA A.B. J A WETTERGRENS GATA 1, BOX 30053, 400 43 VÄSTRA FRÖLUNDA, SWEDEN YAMAHA MUSIC AUSTRALIA PTY, LTD. 17-33 MARKET ST., SOUTH MELBOURNE, 3205 VIC., AUSTRALIA...
