Yamaha CDC-745 Owner's Manual

Natural sound compact disc player 5-disc carousel auto-changer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Disc Scanning Capability Useful for Disc Searching or Disc Checking
CD Synchronized Recording with a Compatible YAMAHA Tape Deck
Thank you for selecting this YAMAHA Compact Disc Player.
OWNER'S MANUAL
CONTENTS
Safety Instructions.................... 2
Connections ............................. 4
Program Play.......................... 12
Repeat Play............................ 16
Index Search .......................... 16
Recording to Tape ...................17
Control Transmitter ................. 22
Compact Discs ....................... 22
Troubleshooting ...................... 23
Specifications ......................... 23
CDC-845/7 45
PLAYXCHANGE; Disc Changing Capability while Playing Another
IMPORTANT!
Please record the serial number of this
unit in the space below.
Model:
Serial No.:
The serial number is located on the rear
of the unit.
Retain this Owner's Manual in a safe
place for future reference.
WARNING
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE
THIS UNIT TO RAIN OR MOISTURE.
Natural Sound Compact Disc Player
5-Disc Carousel Auto-Changer
Random Access Programmable Play
Single Track/Entire Disc/All Disc Repeat Play
Automatic Tape-Programming
Automatic Peak Level Searching Capability
Program Data Filing Capability
Display Brightness Changing Capability
Random-Sequence Play

Optical Digital Output

Remote Control Capability
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK), NO USER-SERVICEABLE
PARTS INSIDE, REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
• Explanation of Graphical Symbols
The lightning flash with arrowhead
symbol, within an equilateral triangle,
is intended to alert you to the
presence of uninsulated "dangerous
voltage" within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended to alert
you to the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the
appliance.
