OWNER'S MANUAL
YZF-R6T(C)
LIT-11626-18-45
5SL-28199-12

Advertisement

Table of Contents
loading

Related Manuals for Yamaha YZF-R6T(C)

Summary of Contents for Yamaha YZF-R6T(C)

  • Page 1 OWNER’S MANUAL YZF-R6T(C) LIT-11626-18-45 5SL-28199-12...
  • Page 2 EAU10041...
  • Page 3 Yamaha has met these standards without reducing the performance or economy of operation of the motorcycle. To maintain these high standards, it is important that you and your Yamaha dealer pay close attention to the recommended maintenance schedules and operating instructions contained within this manual.

  • Page 4: Important Manual Information

    This manual should be considered a permanent part of this motorcycle and should remain with it even if the motorcycle is subsequently sold. Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most current product information available at the time of printing, there may be minor discrepancies between your motorcycle and this manual.
  • Page 5 IMPORTANT MANUAL INFORMATION AND UNTIL YOU HAVE BEEN TRAINED IN SAFE AND PROPER RIDING TECHNIQUES. REGULAR INSPECTIONS AND CAREFUL MAINTENANCE, ALONG WITH GOOD RIDING SKILLS, WILL ENSURE THAT YOU SAFELY ENJOY THE CAPABILITIES AND THE RELIABILITY OF THIS MOTORCYCLE.
  • Page 6 IMPORTANT MANUAL INFORMATION EAU10192 AFFIX DEALER LABEL HERE YZF-R6T(C) OWNER’S MANUAL ©2004 by Yamaha Motor Corporation, U.S.A. 1st edition, August 2004 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Corporation, U.S.A. is expressly prohibited.

  • Page 7: Table Of Contents

    SAFETY INFORMATION ...1-1 Location of important labels ...1-5 DESCRIPTION ...2-1 Left view ...2-1 Right view ...2-2 Controls and instruments ...2-3 INSTRUMENT AND CONTROL FUNCTIONS ...3-1 Main switch/steering lock ...3-1 Indicator and warning lights ...3-2 Tachometer ...3-5 Multi-function display ...3-6 Handlebar switches ...3-9 Clutch lever ...3-10 Shift pedal ...3-11 Brake lever ...3-11...
  • Page 8 STORAGE ...7-1 Care ...7-1 Storage ...7-3 SPECIFICATIONS ...8-1 CONSUMER INFORMATION...9-1 Identification numbers ...9-1 Reporting safety defects ...9-3 Motorcycle noise regulation ...9-4 Maintenance record ...9-5 YAMAHA MOTOR CORPORATION, U.S.A. STREET AND ENDURO MOTORCYCLE LIMITED WARRANTY ...9-7 YAMAHA EXTENDED SERVICE (Y.E.S.) ...9-9...

  • Page 9: Safety Information

    EAU10281 MOTORCYCLES SINGLE TRACK VEHICLES. THEIR SAFE USE AND OPERATION ARE DEPEN- DENT UPON THE USE OF PROPER RIDING TECHNIQUES AS WELL AS THE EXPERTISE OF THE OPERA- TOR. EVERY OPERATOR SHOULD KNOW THE FOLLOWING REQUIRE- MENTS BEFORE RIDING THIS MOTORCYCLE.
  • Page 10 A passenger should also observe the above precautions. Modifications Modifications made to this motorcycle not approved by Yamaha, or the re- moval of original equipment, may ren- der the motorcycle unsafe for use and may cause severe personal injury. Modifications may also make your motorcycle illegal to use.
  • Page 11 Accessories Genuine Yamaha accessories have been specifically designed for use on this motorcycle. Since Yamaha cannot test all other accessories that may be available, you must personally be re- sponsible for the proper selection, in- stallation and use of non-Yamaha accessories.
  • Page 12 SAFETY INFORMATION tor and may limit control ability, therefore, such accessories are not recommended. Use caution when adding electri- cal accessories. If electrical acces- sories exceed the capacity of the motorcycle’s electrical system, an electric failure could result, which could cause a dangerous loss of lights or engine power.

  • Page 13: Location Of Important Labels

    SAFETY INFORMATION EAU10381 Location of important labels Please read the following important labels carefully before operating this vehicle.
  • Page 14 SAFETY INFORMATION CAUTION Cleaning with alkaline or acid cleaner, gasoline or solvent will damage windshield. Use neutral detergent. 5JW-00 PREMIUM UNLEADED GASOLINE ONLY 91 Min. Pump Octane (R+M) 2 290 kPa, {2.90 kgf/cm Improper loading can cause loss of control. Read owner’s manual for proper loading.
  • Page 15 California only California only SAFETY INFORMATION California only...

  • Page 16: Description

    DESCRIPTION Left view 1. Front fork rebound damping force adjusting screw (page 3-16) 2. Front fork spring preload adjusting bolt (page 3-16) 3. Fuse box 2 (page 6-35) 4. Coolant reservoir (page 6-14) 5. Shock absorber assembly spring preload adjusting ring (page 3-18) 6.

  • Page 17: Right View

    Right view 1. Luggage strap holder (page 3-19) 2. Helmet holder (page 3-15) 3. Fuse box 1 (page 6-35) 4. Main fuse (page 6-35) 5. Battery (page 6-34) 6. Air filter element (page 6-18) 7. Front brake fluid reservoir (page 6-27) 8.

  • Page 18: Controls And Instruments

    DESCRIPTION EAU10430 Controls and instruments 1. Clutch lever (page 3-10) 2. Left handlebar switches (page 3-9) 3. Multi-function display (page 3-6) 4. Main switch/steering lock (page 3-1) 5. Tachometer (page 3-5) 6. Right handlebar switches (page 3-9) 7. Throttle grip (page 6-20) 8.

  • Page 19: Instrument And Control Functions

    EAU10460 Main switch/steering lock The main switch/steering lock controls the ignition and lighting systems, and is used to lock the steering. The various positions are described below. EAU26900 All electrical circuits are supplied with power, and the meter lighting, taillight, license plate light and position lights come on, and the engine can be start- ed.

  • Page 20: Indicator And Warning Lights

    “ON”. If the warning light does not come on for a few seconds, then go off, have a Yamaha dealer check the electrical cir- cuit. ” NOTE: Even if the oil level is sufficient, the...
  • Page 21 The fuel level warning light will flash eight times, then go off for 2.5 seconds. If this occurs, have a Yamaha dealer check the vehicle. INSTRUMENT AND CONTROL FUNCTIONS EAU11422 Coolant temperature warning light “...
  • Page 22 INSTRUMENT AND CONTROL FUNCTIONS Coolant temperature Under 39 °C (Under 103 °F) 40–116 °C (104–241 °F) 117–139 °C (242–283 °F) Above 140 °C (Above 284 °F) Display Conditions Message “LO” is displayed. Temperature is displayed. Temperature display flashes. Warning light comes on. Message “HI”...

  • Page 23: Tachometer

    ” This warning light comes on or flashes when an electrical circuit monitoring the engine is defective. When this occurs, have a Yamaha dealer check the self- diagnosis system. (See page 3-6 for an explanation of the self-diagnosis de- vice.)

  • Page 24: Multi-Function Display

    INSTRUMENT AND CONTROL FUNCTIONS Multi-function display 1. Multi-function display 2. “SELECT” button 3. “RESET” button The multi-function display is equipped with the following: a speedometer (which shows the riding speed) an odometer (which shows the to- tal distance traveled) two tripmeters (which show the distance traveled since they were last set to zero) a fuel reserve tripmeter (which...
  • Page 25 (e.g., 11, 12, 13). If the multi-function display indicates any error codes, note the code number, and then have a Yamaha dealer check the vehicle. ECA11590 CAUTION: If the display indicates an error...
  • Page 26 INSTRUMENT AND CONTROL FUNCTIONS cedure, only the settings made be- fore the “SELECT” button was last pushed will be applied. In this mode, the multi-function dis- play shows the current setting for each function (except the shift tim- ing indicator light activity function). To adjust the display brightness 1.

  • Page 27: Handlebar Switches

    the indicator light can be set in in- crements of 500 r/min. From 12000 r/min to 16000 r/min, the in- dicator light can be set in incre- ments of 200 r/min. Be sure to set the deactivation function to a higher engine speed than for the activation function, otherwise the shift timing indicator light will remain deactivated.

  • Page 28: Clutch Lever

    INSTRUMENT AND CONTROL FUNCTIONS Dimmer switch “ ” Set this switch to “ ” for the high beam and to “ ” for the low beam. Turn signal switch “ ” To signal a right-hand turn, push this switch to “ ”.

  • Page 29: Shift Pedal

    EAU12870 Shift pedal 1. Shift pedal The shift pedal is located on the left side of the engine and is used in com- bination with the clutch lever when shifting the gears of the 6-speed con- stant-mesh transmission equipped on this motorcycle.

  • Page 30: Brake Pedal

    INSTRUMENT AND CONTROL FUNCTIONS Brake pedal 1. Brake pedal The brake pedal is on the right side of the motorcycle. To apply the rear brake, press down on the brake pedal. EAU12941 Fuel tank cap 1. Fuel tank cap lock cover 2.

  • Page 31: Fuel

    Your Yamaha engine has been de- signed to use premium unleaded gaso- line with a pump octane number [(R+M)/2] of 91 or higher, or a research 3-13 octane number of 95 or higher.

  • Page 32: Catalytic Converter

    INSTRUMENT AND CONTROL FUNCTIONS Catalytic converter This vehicle is equipped with a catalytic converter in the muffler. WARNING The exhaust system is hot after op- eration. Make sure that the exhaust system has cooled down before do- ing any maintenance work. CAUTION: The following precautions must be observed to prevent a fire hazard or...

  • Page 33: Helmet Holders

    2. While holding the key in that posi- tion, lift the front of the passenger seat and pull it forward. To install the passenger seat 1. Insert the projection on the rear of the passenger seat into the seat holder as shown, and then push the front of the seat down to lock it in place.

  • Page 34: Storage Compartment

    INSTRUMENT AND CONTROL FUNCTIONS Storage compartment 1. Storage compartment The storage compartment is located under the passenger seat. (See page 3-14.) WARNING Do not exceed the load limit of 3 kg (7 lb) for the storage com- partment. Do not exceed the maximum load of 191 kg (421 lb) (CAL) 192 kg (423 lb) (U49) for the ve- hicle.

  • Page 35: Specifications

    Rebound damping force 1. Rebound damping force adjusting screw To increase the rebound damping force and thereby harden the rebound damp- ing, turn the adjusting screw on each fork leg in direction (a). To decrease the rebound damping force and thereby soften the rebound damping, turn the adjusting screw on each fork leg in di- rection (b).

  • Page 36: Adjusting The Shock Absorber Assembly

    INSTRUMENT AND CONTROL FUNCTIONS Adjusting the shock absorber assembly This shock absorber assembly is equipped with a spring preload adjust- ing ring and rebound and compression damping force adjusting screws. CAUTION: Never attempt to turn an adjusting mechanism beyond the maximum or minimum settings.

  • Page 37: Luggage Strap Holders

    Do not deform or damage the gas cylinder in any way, as this will result in poor damping per- formance. Always have a Yamaha dealer service the shock absorber. 3-19 EAU15181 Luggage strap holders 1. Luggage strap holder 2.

  • Page 38: Sidestand

    Therefore, check this system regularly as described EAU15300 below and have a Yamaha dealer re- pair it if it does not function proper- EWA10240 3-20 EAU15311...
  • Page 39 This check is most reliable if performed with a warmed-up engine. The neutral switch may be defective. The motorcycle should not be ridden until checked by a Yamaha dealer. The sidestand switch may be defective. The motorcycle should not be ridden until checked by a Yamaha dealer.

  • Page 40: Pre-Operation Checks

    PRE-OPERATION CHECKS EAU15591 The condition of a vehicle is the owner’s responsibility. Vital components can start to deteriorate quickly and unexpectedly, even if the vehicle remains unused (for example, as a result of exposure to the elements). Any damage, fluid leakage or loss of tire air pressure could have serious consequences.

  • Page 41: Pre-Operation Check List

    • If necessary, add recommended coolant to specified level. • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 42 ITEM • Make sure that operation is smooth. • Check cable free play. Throttle grip • If necessary, have Yamaha dealer adjust cable free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables •...

  • Page 43: Operation And Important Riding Points

    NOTE: When the transmission is in the neutral position, the neutral indicator light should be on, otherwise have a Yamaha dealer check the electrical cir- cuit. 3. Start the engine by pushing the start switch. NOTE: If the engine fails to start, release the start switch, wait a few seconds, and then try again.

  • Page 44: Shifting

    OPERATION AND IMPORTANT RIDING POINTS CAUTION: For maximum engine life, always warm the engine up before starting off. Never accelerate hard when the engine is cold! NOTE: The engine is warm when it quickly re- sponds to the throttle. ECA11130 Shifting 1.

  • Page 45: Engine Break-In

    4. At the recommended shift points shown in the following table, close the throttle, and at the same time, quickly pull the clutch lever in. 5. Shift the transmission into second gear. (Make sure not to shift the transmission into the neutral posi- tion.) 6.

  • Page 46: Parking

    Keep the engine speed out of the tachometer red zone. If any engine trouble should oc- cur during the engine break-in period, immediately have a Yamaha dealer check the vehi- cle. ECA10301 Parking When parking, stop the engine, and then remove the key from the main switch.

  • Page 47: Periodic Maintenance And Minor Repair

    NOTE: If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you.
  • Page 48 PERIODIC MAINTENANCE AND MINOR REPAIR EWA10340 WARNING Modifications approved Yamaha may cause loss of perfor- mance, excessive emissions, and render the vehicle unsafe for use. Consult a Yamaha dealer before at- tempting any changes.

  • Page 49: Periodic Maintenance Chart For The Emission Control System

    • Check the air cut-off valve, reed Air induction sys- valve, and hose for damage. • Replace any damaged parts. * Since these items require special tools, data and technical skills, have a Yamaha dealer perform the service. PERIODIC MAINTENANCE AND MINOR REPAIR INITIAL 600 mi...

  • Page 50: General Maintenance And Lubrication Chart

    PERIODIC MAINTENANCE AND MINOR REPAIR General maintenance and lubrication chart ITEM • Check condition and damage. 1 * Air filter element • Replace if necessary. • Check operation. 2 * Clutch • Adjust or replace cable. • Check operation, fluid level, and 3 * Front brake for fluid leakage.
  • Page 51 ITEM ROUTINE • Check bearing assemblies for Swingarm pivot looseness. bearings • Moderately repack with lithium- soap-based grease. • Check chain slack, alignment and condition. Drive chain • Adjust and lubricate chain with a special O-ring chain lubricant thoroughly. • Check bearing assemblies for looseness.
  • Page 52 24 * if necessary. ing and cable • Lubricate the throttle grip housing and cable. * Since these items require special tools, data and technical skills, have a Yamaha dealer perform the service. INITIAL 600 mi 4000 mi ROUTINE (1000 km)
  • Page 53 NOTE: From 24000 mi (37000 km) or 36 months, repeat the maintenance intervals starting from 8000 mi (13000 km) or 12 months. NOTE: The air filter needs more frequent service if you are riding in unusually wet or dusty areas. Hydraulic brake service •...

  • Page 54: Removing And Installing Cowlings And Panels

    PERIODIC MAINTENANCE AND MINOR REPAIR Removing and installing cowlings and panels The cowlings and panels shown need to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time a cowling or panel needs to be re- moved and installed.
  • Page 55 1. Bolt 2. Cowling B 1. Cowling A 2. Cowling B To install the cowling 1. Fit the slots and projections at the rear bottom of each cowling to- gether, and then slide the cowling into place. PERIODIC MAINTENANCE AND MINOR REPAIR 1.

  • Page 56: Checking The Spark Plugs

    Do not attempt to diagnose such problems yourself. Instead, have a Yamaha deal- er check the vehicle. If a spark plug shows signs of electrode erosion and excessive carbon or other deposits, it should be replaced.

  • Page 57: Canister (For California Only)

    NOTE: If a torque wrench is not available when installing a spark plug, a good estimate of the correct torque is 1/4–1/2 turn past finger tight. However, the spark plug should be tightened to the speci- fied torque as soon as possible. ECA10840 CAUTION: Do not use any tools to remove or in-...
  • Page 58 PERIODIC MAINTENANCE AND MINOR REPAIR 4. Remove the engine oil dipstick and wipe it clean, insert it back into the hole (without screwing it in), and then remove it again to check the oil level. 1. Dipstick 2. Maximum level mark 3.
  • Page 59 2. Engine oil filter cartridge PERIODIC MAINTENANCE AND MINOR REPAIR NOTE: An oil filter wrench is available at a Yamaha dealer. 7. Apply a thin coat of engine oil to the O-ring of the new oil filter car- tridge. 1. O-ring...

  • Page 60: Coolant

    CAUTION: ECA11620 If the oil level warning light flickers or remains on, immediately turn the engine off and have a Yamaha dealer check the vehicle. 14. Turn the engine off, and then check the oil level and correct it if necessary.
  • Page 61 6-15 If water has been added to the coolant, have a Yamaha dealer check the antifreeze content of the coolant as soon as possible, otherwise the effectiveness of the coolant will be reduced.
  • Page 62 PERIODIC MAINTENANCE AND MINOR REPAIR 2. Remove panel A, and cowlings A and B. (See page 6-8.) 3. Place a container under the engine to collect the used coolant. 4. Loosen the clamp screw, and then disconnect the air intake duct. 1.
  • Page 63 10. Remove the coolant reservoir by removing the bolts. 11. Remove the coolant reservoir cap, and then turn the coolant reservoir upside down to empty it. 1. Coolant reservoir cap 2. Coolant reservoir 3. Bolt 12. After the coolant is completely drained, thoroughly flush the cool- ing system with clean tap water.

  • Page 64: Checking The Air Filter Element

    21. Start the engine, and then check the vehicle for coolant leakage. If coolant is leaking, have a Yamaha dealer check the cooling system. 22. Connect the air intake duct, and then tighten the clamp screw.
  • Page 65 If any fuel hose is dam- aged, do not start the engine but have a Yamaha dealer replace the hose, otherwise fuel may leak. Make sure that the fuel hoses are properly connected and routed, and not pinched.

  • Page 66: Air Intake Duct

    1. Throttle cable free play The throttle cable free play should mea- sure 6.0–8.0 mm (0.24–0.31 in) at the throttle grip. Periodically check the throttle cable free play and, if neces- sary, have a Yamaha dealer adjust it.

  • Page 67: Valve Clearance

    The valve clearance changes with use, resulting in improper air-fuel mixture and/or engine noise. To prevent this from occurring, the valve clearance must be adjusted by a Yamaha dealer at the intervals specified in the periodic maintenance and lubrication chart. PERIODIC MAINTENANCE AND MINOR REPAIR...
  • Page 68 (minimum tread depth), if the tire has a nail or glass fragments in it, or if the sidewall is cracked, con- tact a Yamaha dealer immediately and have the tire replaced. Minimum tire tread depth (front and rear): 1.0 mm (0.04 in)
  • Page 69 After extensive tests, only the tires listed below have been ap- proved this model Yamaha Motor Co., Ltd. Always make sure that the valve caps are securely installed to prevent air pressure leakage. Use only the tire valves and valve cores listed below to avoid tire deflation during a high-speed ride.

  • Page 70: Cast Wheels

    The wheel rims should be checked for cracks, bends or warpage be- fore each ride. If any damage is found, have a Yamaha dealer re- place the wheel. Do not attempt even the smallest repair to the wheel. A deformed or cracked wheel must be replaced.

  • Page 71: Adjusting The Clutch Lever Free Play

    EAU22060 Adjusting the clutch lever free play 1. Clutch lever free play adjusting bolt 2. Clutch lever free play The clutch lever free play should mea- sure 10.0–15.0 mm (0.39–0.59 in) as shown. Periodically check the clutch le- ver free play and, if necessary, adjust it as follows.

  • Page 72: Adjusting The Rear Brake Light Switch

    If a brake pad has worn to the 6-26 EAU22390 point that the wear indicator almost touches the brake disc, have a Yamaha dealer replace the brake pads as a set. Rear brake pads EAU22410 1. Lining thickness Check each rear brake pad for damage and measure the lining thickness.

  • Page 73: Checking The Brake Fluid Level

    As the brake pads wear, it is nor- mal for the brake fluid level to grad- ually go down. However, if the brake fluid level goes down sud- denly, have a Yamaha dealer check the cause.

  • Page 74: Changing The Brake Fluid

    PERIODIC MAINTENANCE AND MINOR REPAIR Changing the brake fluid Have a Yamaha dealer change the brake fluid at the intervals specified in the NOTE after the periodic mainte- nance and lubrication chart. In addition, have the oil seals of the master cylin-...

  • Page 75: Lubricating The Drive Chain

    NOTE: Using the alignment marks on each side of the swingarm, make sure that both chain pullers are in the same posi- tion for proper wheel alignment. 1. Axle nut 2. Drive chain slack adjusting bolt 3. Locknut 4. Alignment marks ECA10570 CAUTION: Improper drive chain slack will over-...

  • Page 76: Checking And Lubricating The Cables

    If a cable is damaged or does not move smoothly, have a Yamaha dealer check or replace it. Recommended lubricant: Yamaha Chain and Cable Lube or engine oil SAE 10W-30 (API SE)

  • Page 77: Checking And Lubricating The Brake And Shift Pedals

    EAU23131 Checking and lubricating the brake and shift pedals The operation of the brake and shift pedals should be checked before each ride, and the pedal pivots should be lu- bricated if necessary. PERIODIC MAINTENANCE AND MINOR REPAIR Recommended lubricant: Lithium-soap-based grease (all-pur- pose grease) 6-31...

  • Page 78: Checking And Lubricating The Sidestand

    EWA10730 WARNING If the sidestand does not move up and down smoothly, have a Yamaha dealer check or repair it. Recommended lubricant: Lithium-soap-based grease (all-pur- pose grease) 6-32 EAUM1650...

  • Page 79: Checking The Front Fork

    PERIODIC MAINTENANCE AND MINOR REPAIR ECA10590 CAUTION: If any damage is found or the front fork does not operate smoothly, have a Yamaha dealer check or re- pair it. 6-33 EAU23280 Checking the steering Worn or loose steering bearings may cause danger.

  • Page 80: Checking The Wheel Bearings

    To charge the battery Have a Yamaha dealer charge the bat- tery as soon as possible if it seems to have discharged. Keep in mind that the battery tends to discharge more quickly if the vehicle is equipped with optional electrical accessories.

  • Page 81: Replacing The Fuses

    Using a conventional battery charger will damage the battery. If you do not have access to a sealed-type (MF) battery charg- er, have a Yamaha dealer charge your battery. 6-35 EAU23702 Replacing the fuses The main fuse and fuse box 1 are locat- ed under the rider seat.

  • Page 82: Replacing A Headlight Bulb

    3. Turn the key to “ON” and turn on the electrical circuit in question to check if the device operates. 4. If the fuse immediately blows again, have a Yamaha dealer check the electrical system. 6-36 EAU23940 Replacing a headlight bulb This model is equipped with quartz bulb headlights.
  • Page 83 1. Do not touch the glass part of the bulb. 6. Connect the headlight coupler. 7. Install the headlight bulb cover by turning it clockwise. 8. Install the panel. 9. Have a Yamaha dealer adjust the headlight beam if necessary.

  • Page 84: Tail/Brake Light

    Tail/brake light This model is equipped with an LED type of tail/brake light. If the tail/brake light does not come on, have a Yamaha dealer check it. EAU24180 Replacing a turn signal light bulb 1. Remove the turn signal light lens by removing the screw.

  • Page 85: Supporting The Motorcycle

    3. Remove the defective bulb by pull- ing it out. 4. Insert a new bulb into the socket. 5. Install the socket (together with the bulb) by pushing it in. 6. Install the license plate light unit by installing the screws. PERIODIC MAINTENANCE AND MINOR REPAIR EAU24350 Supporting the motorcycle...

  • Page 86: Front Wheel

    PERIODIC MAINTENANCE AND MINOR REPAIR Front wheel To remove the front wheel WARNING It is advisable to have a Yamaha dealer service the wheel. Securely support the motor- cycle so that there is no danger of it falling over. 1. Loosen the wheel axle pinch bolts, the axle bolt, and then the brake caliper bolts.
  • Page 87 NOTE: Make sure that there is enough space between the brake pads before install- ing the brake calipers onto the brake discs. Tightening torque: Brake caliper bolt: 35 Nm (3.5 m·kgf, 25 ft·lbf) 5. Install the brake hose holders and reflectors by installing the bolts and nuts.

  • Page 88: Rear Wheel

    PERIODIC MAINTENANCE AND MINOR REPAIR Rear wheel To remove the rear wheel WARNING It is advisable to have a Yamaha dealer service the wheel. Securely support the motor- cycle so that there is no danger of it falling over. 1. Loosen the axle nut.

  • Page 89: Troubleshooting

    The following troubleshooting charts represent quick and easy procedures for checking these vital systems your- self. However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.

  • Page 90: Troubleshooting Charts

    There is no compression. check the vehicle. Wipe off with a dry cloth and correct the spark plug gaps, or replace the spark plugs. Have a Yamaha dealer check the vehicle. The engine turns over The battery is good. quickly.
  • Page 91 The coolant level is low. Check the cooling system for leakage. Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. 6-45 EWA10400 There is Have a Yamaha dealer check leakage.

  • Page 92: Motorcycle Care And Storage

    MOTORCYCLE CARE AND STORAGE Care While the open design of a motorcycle reveals the attractiveness of the tech- nology, it also makes it more vulnera- ble. Rust and corrosion can develop even if high-quality components are used. A rusty exhaust pipe may go un- noticed on a car, however, it detracts from the overall appearance of a motor- cycle.
  • Page 93 After normal use Remove dirt with warm water, a mild detergent, and a soft, clean sponge, and then rinse thoroughly with clean water. Use a toothbrush or bottlebrush for hard-to-reach areas. Stubborn dirt and insects will come off more easily if the area is covered with a wet cloth for a few minutes before cleaning.

  • Page 94: Storage

    Avoid using abrasive polishing compounds as they will wear away the paint. NOTE: Consult a Yamaha dealer for advice on what products to use. ECA10800 Storage Short-term Always store your motorcycle in a cool, dry place and, if necessary, protect it against dust with a porous cover.
  • Page 95 4. Lubricate all control cables and the pivoting points of all levers and pedals as well as of the side- stand/centerstand. 5. Check and, if necessary, correct the tire air pressure, and then lift the motorcycle so that both of its wheels are off the ground.

  • Page 96: Specifications

    SPECIFICATIONS Dimensions: Overall length: 2045 mm (80.5 in) Overall width: 690 mm (27.2 in) Overall height: 1105 mm (43.5 in) Seat height: 830 mm (32.7 in) Wheelbase: 1385 mm (54.5 in) Ground clearance: 145 mm (5.71 in) Minimum turning radius: 3800 mm (149.6 in) Weight: With oil and fuel:...
  • Page 97 2nd: 37/19 (1.947) 3rd: 28/18 (1.556) 4th: 32/24 (1.333) 5th: 25/21 (1.190) 6th: 26/24 (1.083) Chassis: Frame type: Diamond Caster angle: 24.50 ° Trail: 95.0 mm (3.74 in) Front tire: Type: Tubeless Size: 120/70 ZR17M/C (58W) Manufacturer/model: DUNLOP/D218F M Rear tire: Type: Tubeless Size:...
  • Page 98 SPECIFICATIONS Charging system: AC magneto Battery: Model: GT9B-4 Voltage, capacity: 12 V, 8.0 Ah Headlight: Bulb type: Halogen bulb Bulb voltage, wattage x quantity: Headlight: 12 V, 55.0 W × 2 Tail/brake light: Front turn signal/position light: 12 V, 21 W/5.0 W × 2 Rear turn signal light: 12 V, 21.0 W ×...

  • Page 99: Consumer Information

    Record the key identification number, vehicle identification number and mod- el label information in the spaces pro- vided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehi- cle is stolen. KEY IDENTIFICATION NUMBER:...
  • Page 100 1. Model label The model label is affixed to the frame under the rider seat. (See page 3-14.) Record the information on this label in the space provided. This information will be needed when ordering spare parts from a Yamaha dealer.

  • Page 101: Reporting Safety Defects

    If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Yamaha Motor Corporation, U.S.A. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.

  • Page 102: Motorcycle Noise Regulation

    CONSUMER INFORMATION Motorcycle noise regulation TAMPERING WITH NOISE CONTROL SYSTEM PROHIBITED: Federal law prohibits the following acts or the causing thereof: (1) The removal or rendering inoperative by any person other than for purposes of maintenance, repair, or replacement of any device or element of design incorporated into any new ve- hicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use or (2) the use of the vehicle after such device or element of design has been removed or rendered inoperative by any person.

  • Page 103: Maintenance Record

    Maintenance record Copies of work orders and/or receipts for parts purchased and installed on your vehicle will be required to document that maintenance has been completed in accordance with the emissions warranty. The chart below is printed only as a reminder that maintenance work is required.
  • Page 104 CONSUMER INFORMATION Maintenance interval 36000 mi (55000 km) or 54 months 40000 mi (61000 km) or 60 months Date of Mileage service Servicing dealer Remarks name and address...

  • Page 105: Yamaha Motor Corporation, U.s.a. Street And Enduro Motorcycle Limited Warranty

    CONSUMER INFORMATION EAU26661 YAMAHA MOTOR CORPORATION, U.S.A. STREET AND ENDURO MOTORCYCLE LIMITED WARRANTY...
  • Page 106 CONSUMER INFORMATION...

  • Page 107: Yamaha Extended Service (Y.e.s.)

    This excellent Y.E.S. plan coverage is only available to Yamaha owners like you, and only while your Yamaha is still within the Yamaha Limited Warranty period. So visit your authorized Yamaha dealer to get all the facts. He can show you how easy it is to protect your investment with Yamaha Extended Service.
  • Page 108 Yamaha Limited Warranty expires. A special note: If visiting your dealer isn’t convenient, contact Yamaha with your Primary ID number (your frame number). We’ll be happy to help you get the Y.E.S. coverage you need.
  • Page 109 Accessories and replacement parts ... 6-24 Air filter element, checking ... 6-18 Air intake duct ... 6-20 Battery ... 6-34 Brake and clutch levers, checking and lubricating... 6-31 Brake and shift pedals, checking and lubricating... 6-31 Brake fluid, changing ... 6-28 Brake fluid level, checking ...
  • Page 110 INDEX Tires ... 6-21 Tool kit ... 6-1 Troubleshooting ... 6-43 Troubleshooting charts ... 6-44 Turn signal indicator lights ... 3-2 Turn signal light bulb, replacing ... 6-38 Turn signal switch ... 3-10 Valve clearance ... 6-21 Vehicle identification number ... 9-1 Warranty, extended...
  • Page 111 YAMAHA MOTOR CO., LTD. PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2004.08-2.7×1 CR...
