Xtatix Pocket Candy Zest
Features
• USB2.0 transmission speed.
•
Supports multiple audio formats MP1, MP2, MP3, WMA,
WAV.
• FM stereo tuner automatic or manual station search, able
to store 20 stations
• U-disc function, driver not needed with Windows
2000/XP/Vista
• Record / repeat
• Record into WAV format voice file with microphone, select
sectional repeat or comparison repeat function.
• 6 EQ styles
• Normal, Rock, Pop, Classic, Jazz and Bass
• Blue Backlight
• Multiple play modes
• Normal, repeat one, repeat all, shuffle play and browse
play modes
• Auto OFF
• Programmable Auto OFF.
• Elegant menu
•
Visual picture menu. Language selection.
•
Fast forward and fast rewind
Sync
•
Safety precautions
1. To ensure your safety, please do not use the player in
damp locations or spray water onto the player.
2. It is recommended not to use the player in very hot/cold,
dusty or humid environments.
3. Please do not disassemble or repair the player by
yourself. Otherwise, quality guarantee will be voided.
Please use a professional technician if repair is required.
USER MANUAL
1
Advertisement
Related Manuals for Xtatix Pocket Candy Zent
Summary of Contents for Xtatix Pocket Candy Zent
-
Page 1: Safety Precautions
Xtatix Pocket Candy Zest USER MANUAL Features • USB2.0 transmission speed. • Supports multiple audio formats MP1, MP2, MP3, WMA, WAV. • FM stereo tuner automatic or manual station search, able to store 20 stations • U-disc function, driver not needed with Windows 2000/XP/Vista •... - Page 2 4. It is recommended that you do not listen to MP3 with earphones when you are driving. Please do not use earphones when you are engaging in any activity requiring your full concentration. 5. Your hearing ability may be permanently impaired from to the player with strong volume for a long period of time.
- Page 3 Shows full battery capacity. The battery capacity indicator will show power decreasing as the player is used Shows battery capacity is almost empty and the icon will flash. Simply recharge or replace the battery Key Operation The key operation includes short press, long press, press and hold, and press.
- Page 4 To enter Menu: Long press to enter the Menu. (Short press Mode key for play status) # 1. Mode: “Play Music” Short press to enter track menu. Press PLAY Button to start. OR scroll to desired track by moving Mode key to the right (forward), to the left (back), to desired track, press PLAY key to start playback at desired track.
- Page 5 Setting “Contrast”: Short press to enter setting for Contrast Mode. See bar; slide key right for increased contrast, slide key left for reduced contrast. Short press to set Contrast and return to Setting. Setting “Backlight”: Short press to set Blue Backlight. See bar: slide key right to increase Blue Backlight, slide key left to reduce Blue Backlight contrast.
- Page 6 Simple operation listen/play music: 1.Plug earphones into the earphone jack. 2.Short press Play key to turn on. 3. Press Mode key to enter “Play Music”, short press to enter, short pressPlay key again to start music. 4.Volume adjust: VOL+: to increase the volume VOL-: to reduce the volume Sync lyric: The player supports “*.LRC”...
- Page 7 The player supports storage of multiple record files under each folder. “Record” 1. Enter the menu, slide to record mode. 2.Short press Mode key to enter the record mode and the picture is given below: 3.Short press Play key to pause the record, and short press Mode key to enter the record play mode.
- Page 8 6. Volume adjust: Press VOL+: to increase the volume. Press VOL-: to decrease the volume Operation of FM Tuner 1. Enter the Menu. 2. Slide key to “FM Tuner” 3. Short press Mode key to enter “FM Tuner” 4. Automatic search: Press key for 2 seconds, the player searches forward or backward at a step of 100KHz and stops at the station searched.
- Page 9 “Setting” 1. Enter Menu. 2. Slide key to select “Setting”. Short press Mode key to enter “Setting”. 3. Slide key to “Backlight” 4. Short press to enter 5. Slide key to adjust “Backlight time”. Press PLAY key to exit. “Equalizer” 1.
- Page 10 2. Driver installation for Win98 If it is the first time for you to use MP3 player with WINDOWS 98, a driver needs to be installed before connection of MP3 player. Install as follows: 1. Insert the installation disk into CD-ROM. 2.
- Page 11 Troubleshooting...
- Page 12 Problem Solution No power Check if the battery is installed correctly. Check if the power is ON. No sound Confirm that the can be volume is not at 0 heard status and that from the there is no problem earphone. in the earphone connection.
- Page 13 Technical Specifications Item Specification MPEG 1, 2, 3, Music format WMA，WAV 56Kbps～256Kbps Bit rate Frequency 20Hz～20KHz range Signal/noise ≥86DB ratio ≥85DB (1KHZ Separation referenced signal) Frequency ≤3DB (20HZ~20KHZ) response Output power of the L 4mW, R 4mW earphone Normal, POP, Jazz, EQ mode Rock, Classic, Bass Display...
- Page 14 Memory FLASH media Memory 32MB - 1GB Play current ≤80mA Power off ≤300uA current One AAA No.7 alkali Battery battery Play time About 10 hours File system FAT, FAT32...
