Xilinx Velleman 01ADASM Instruction Manual

DIGITAL I/O MODULE
KIT / ASSEMBLED
This trainer comes in kit form.
It provides all necessary fea-
tures for experimentation and
prototyping of digital circuits.
This trainer includes 8-SPDT
toggle DIP switches, 8-LED indicators, clock conditioning circuit, two
pulse switches, and 26 screwless terminal blocks for easy circuit
connection. The kit comes with easy to follow instructions.
Part No.
3200DIGKIT
3200DIGASSMB
DIGITAL TRAINER
MODEL NO. DT3
KIT VERSION ONLY
This Digital Trainer comes in
kit form and provides all the
functions necessary for digital
experimentation and prototyp-
ing. The DT3's features include
8 binary switches (4 buffered), 8 LED indicators, a clock condi-
tioning circuit, pulse switch with 0 to + 5V or + 5V to 0V output
and 7 board mounted tie blocks for easy circuit connections. The
kit comes with easy to follow assembly instructions.
Part No. Price
3200DT-3 $24.95
USB EXPERIMENT

INTERFACE BOARD

The K8055 interface board
features 5 digital input and
8 digital output channels.
There are also 2 analog
inputs and outputs with 8 bit
resolution. Number of inputs/
outputs can be expanded by connecting up to a maximum
of four cards the PC's USB connectors. All communication
routines are contained in a Dynamic Link Library (DLL). Write
custom Windows (98SE, 2000, Me, XP0 applications in Delphi,
Visual Basic, C++ Builder or any other 32-bit Windows applica-
tion development tool that supports calls to a DLL.
DIAGNOSTIC/TEST SOFTWARE:
— Separate output / input test
— Clear all / set all function
— Counter function on inputs
1 and 2
— Analog output set sliders
— Analog input bar-graph indicator
— Conversion time 20ms per
command
Part No. Description
32VK8055 Kit Version
32VKMV110 Assembled Version
Call Toll Free: 1 (800) 972-2225
Back to Catalog Download Main Page (http://www.elexp.com/a_print.htm)
TRAINERS / CONTROLLERS / SOFTWARE
Price
$27.95
38.95
SPECIFICATIONS:
5 digital inputs, 8 outputs
2 analog inputs and outputs
Power supply through USB
Diagnostic software with
DLL included
Requirements – Pent. CPU,
SB1.0, Windows 98SE,
CD ROM player & mouse
1-4
$44.95
72.00
ANALOG-DIGITAL TRAINER
SINGLE BOARD
Compact, affordable
and practical. Offers all
the necessary features
for any curriculum
requiring electronic
lab training and
experimentation. Includes a
multiple output power supply,
signal generator, indepen-
dent clocks, logic switches,
tri-state LED indicators,
frequency function and more. This is a powerful training and
prototyping tool. Comes complete with 12vdc adapter with din
connector to mate directly to board, plus operation manual.
• Portable: Easily transported. Large solderless breadboard area
(1,640 tie points)
• Power Supply: ±9V and +5V @ 500ma
• Digital: 16 tri-state multi-color LED indicatiors which remain in
a normally lit pattern which alerts user that the LED is function-
ing (color then changes when in operation). Two independent
clocks, 16 logic switches, 2 momentary switches.
• Analog: Sine and Square wave generator. Variable amplitude,
variable offset, variable frequency to 20K
• Operation manual and power adapter (±12V) included
• Optional – 240 page circuit experiment and training book used
by leading technical colleges. Emphasizes the relationship
between design, analysis and testing. To fully utilize optional
Experiment Book including circuit analysis, some additional
hardware items (available from ELECTRONIX EXPRESS) and
software may be needed.
Part No.
01ADASM
2700MJW70
31WI470144879
USB INTERFACE BOARD
USB Experimenter's Board is
designed to introduce you to using
a USB interface in your hardware
designs. The Board is built around
a Cypress Cy7C63001A Universal
Serial Bus Microcontroller chip
which has been pre-programmed to
accept a variety of commands in a
relatively simple format. A Windows-based test program is sup-
plied, as well as full documentation of the USB chip.
This board has 12 I/O lines: 4 output bits and 8 input bits. You
connect to the I/O bits using jumper wires (not included). In
addition, the board has 4 LEDs which can be jumpered to the
outputs and an 8-bit DIP switch that can be jumpered to the
inputs. The board is available as a kit or pre-assembled.
Part No.
5+
3200USBKIT
$39.95
3200USBASM
65.00
(732) 381-8020
• In NJ:
Description
Single Board Analog-Digital Trainer
140 Piece Jumper Wire Kit
240 Page Experiment/Training Book
Description
USB Kit
USB Assembled
(732) 381-1006
• Fax:
(732) 381-1572
Price
$74.95
4.50
32.95
Price
$28.95
33.95
71
