Xerox WORKCENTRE 5135 Specification

Xerox WORKCENTRE 5135 Specification

Black-and-white multifunction printer
Hide thumbs Also See for WORKCENTRE 5135:

Advertisement

Quick Links

Download this manual
WorkCentre
Black-and-White Multifunction Printer
Output Speed
Printing and Copying
First-copy-out Time (FCOT) – letter size, from platen to offset catch tray
Copy Specifications
Copying
Document Scanner
Sides (input:output)
Quantity
Resolution
Concurrency
1
Copy Pre-Collation
Memory (EPC)
Basic Copy
Features/Options
A minimum of 256 MB EPC memory required
1
5150
®
WorkCentre 5150
shown with Office Finisher
WorkCentre 5150
Up to 50 ipm (images per minute) 8.5 x 11 in. (A4/210 x 297 mm)
Up to 36 ipm 8.5 x 14 in. (216 x 356 mm)
Up to 31 ipm 11 x 17 in. (A3/297 x 420 mm)
As fast as 3.4 seconds
Duplex Automatic Document Handler (DADH). Scans sizes up to 11 x 17 in. (A3/297 x 420 mm) SEF
1:1, 1:2, 2:2 and 2:1
1 to 9,999
600 x 600 x 8 bit dpi input / 4800 x 600 dpi interpolated output
Unlimited program-ahead consistent with configuration (Copy, Print, Fax and Scan)
128 MB – Copier (expandable to 512 MB)
384 MB – Copier/Printer (expandable to 512 MB)
Features
Collation
Automatic 2-Sided/Duplex
Auto Reduction and Enlargement to fit selected paper size
Auto Paper Select
Auto Tray Switching
Options
Hole Punching
Stapling
Booklet Creation
Detailed Specifications
1

Advertisement

loading

Related Manuals for Xerox WORKCENTRE 5135

Summary of Contents for Xerox WORKCENTRE 5135

  • Page 1 WorkCentre ® Black-and-White Multifunction Printer WorkCentre 5150 shown with Office Finisher WorkCentre 5150 Output Speed Printing and Copying Up to 50 ipm (images per minute) 8.5 x 11 in. (A4/210 x 297 mm) Up to 36 ipm 8.5 x 14 in. (216 x 356 mm) Up to 31 ipm 11 x 17 in.
  • Page 2 Foreign Device Interface Interface to third-party access control devices, coin machines, card readers (FDI) (Optional) Supports a variety of vending stations available through the Xerox Custom Application Service USB Port PC interface for upload/download of internal auditron data and Xerox Copier Assistant...
  • Page 3 WorkCentre 5150 ® Paper Handling – Two Front Loading Paper Trays Capacity 500 sheets each Sizes User adjustable from 5.5 x 8.5 in. (A5/148 x 210 mm) to 11 x 17 in. (A3/297 x 420 mm) Weights 16 lb to 53 lb bond/110 lb index (60 to 200 gsm) Types Letterhead Preprinted forms...
  • Page 4 WorkCentre 5150 ® Output Option – Office Finisher Option Capacity Top Tray – 250 sheets Stacking Tray – 2,000 sheets Sizes 4.25 x 5.5 in. (A6/105 x 148 mm) to 11 x 17 in. (A3/297 x 420 mm) Weights 16 lb to 57 lb bond/80 lb cover (60 to 216 gsm) Stapling 50 sheets Single (any corner) and dual...
  • Page 5 WorkCentre 5150 ® Network Printing – Print Driver Options Job Type • Secure, Sample, Delay • LAN Fax-with fax option • Save and Save & Print Paper Selection by attribute (including transparency separators) Duplex (2-sided) Finishing • Multiple Stapling positions •...
  • Page 6 Windows Vista/Vista 64 Bit, Windows Walk-up (PS), Microsoft Certified Macintosh System 8.x – 10.2 Macintosh System 10.3 and higher Makes it easy for mobile users to find, use and manage Xerox and non-Xerox devices in every new location. Plug into Xerox Mobile Express Driver (X-MED) a new network, and X-MED automatically discovers available printers and provides status and capability informa- ®...
  • Page 7 Services for device management directly from OpenView Xerox Barcode Pro PS Enables intelligent PostScript printing on Xerox multifunction systems by storing Xerox software, as well as, the barcode (Information available at fonts on the printer hard disk. Enables the printing of barcodes from any application (SAP R/3 client or mainframe) www.xeroxofficesap...
  • Page 8 • Scan to Home displays one template and populates with the user’s directory path after authentication • Scan to network server / directory • Scan to Mailbox • Scan to Windows XP client via Windows Image Acquisition (WIA) or TWAIN driver downloadable from www.xerox.com Network Protocol Novell (NCP via IPX/SPX)
  • Page 9 ScanSoft OmniPage Pro Office (for desktop/client installation) – Professional OCR software for digital archiving and document conversion Image Retriever – provides fully automated retrieval of scanned images direct from a scan enabled Xerox WorkCentre to individual desktops. Also includes an email inbox polling capability.
  • Page 10 WorkCentre 5150 ® Fax Receive Features One- or two-sided printing Stapled or unstapled, hole punch Receive print mode – Manual (size, margin, stock, header)/Auto Auto answer delay Secure receive Junk fax prevention Fax Reports Activity Dial directory Group directory Options Pending Jobs Fax Mailboxes Up to 100 password-protected...
  • Page 11 Staple on/off Collate on/off Secure print on/off Finisher output tray selection (top tray or main tray) Supported Network Multiple vendors, certified by the Xerox Alliance Partner Program. For details visit Fax Vendors Device Management Specifications Accounting Features – Internal Auditron Tracking...
  • Page 12 CSV file, user required to enter XSA ID into the print driver when submitting a print job, similar to secure print. Xerox Standard Accounting can be used in conjunction with an external device via the FDI (e.g. Coin Op or Card Reader) Accounting Features – Network Accounting Enablement Kit (optional) Enhanced network accounting with up to the minute data on how the WorkCentre system is being used;...
  • Page 13 Walkup Fax with LAN Fax: One line Xerox Scan to PC Desktop Xerox Unicode International Printing Kit Enablement for Network Accounting and Xerox Alliance Partner Solutions Network Scanning Upgrade (includes Network Scanning, Scan to Email, Network Server Fax and Internet Fax) Electrical Requirements...
  • Page 14 WorkCentre 5150 ® Dimensions and Weights (Copier) Width Configuration With OCT 38 in. / 955 mm With Office Finisher 48 in. / 1,214 mm Dimensions and Weights (Copier / Printer) Width Configuration With DADF 49 in. / 1,240 mm and OCT With DADF and Office 59 in.

  • Page 15: Smart Kits

    ©2011 Xerox Corporation. All rights reserved. XEROX®, XEROX and Design®, CentreWare®, WorkCentre® and Copier Assistant® are trademarks of Xerox Corporation in the United States and/or other countries. PostScript is a registered trademark of Adobe Systems Incorporated in the United States and/or other countries. Other marks are trademarks or registered trademarks of the companies with which they are associated. In support of Xerox’s environmental leadership goals, these models may contain some recycled components that are reconditioned.
