Xerox Phaser 860 User Manual

Xerox phaser 860 color printer user guide
Hide thumbs Also See for Phaser 860:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual, Installation Manual
P H A S E R
8 6 0
®
C O L O R
P R I N T E R
User Guide

Advertisement

Table of Contents
loading

Related Manuals for Xerox Phaser 860

Summary of Contents for Xerox Phaser 860

  • Page 1 P H A S E R 8 6 0 ® C O L O R P R I N T E R User Guide...
  • Page 2 Phaser 860 Color Printer ® User Guide 071-0726-00 June 2001...
  • Page 3 Copyright © 2001 Xerox Corporation. Unpublished rights reserved under the copyright laws of the United States. Contents of this publication may not be reproduced in any form without permission of Xerox Corporation. ® ® Phaser , PhaserShare , ColorStix ®...
  • Page 4 ® PANTONE Colors generated by the Phaser 860 Color Printer are four- and/or three-color process simulations and may not match PANTONE-identified solid color standards. Use current PANTONE Color Reference Manuals for accurate colors. PANTONE Color simulations are only obtainable on this product when driven by qualified Pantone-licensed software packages.

  • Page 5: Table Of Contents

    Contents Printer Warranty ........vii User safety summary ....... x Printer Parts and Supplies .
  • Page 6 Xerox web sites ........

  • Page 7: Printer Warranty

    Printer Warranty Xerox warrants that the Phaser 860 Printer will be free from defects in materials and workmanship for a period of one (1) year from the date of shipment. If the product proves defective during the warranty period, Xerox, at its option, will:...

  • Page 8: Consumables Warranty

    Consumables Warranty Xerox warrants that ColorStix® II Ink will be free from defects in materials and workmanship for a period of one (1) year from date of installation. All other Customer Replaceable Consumables (CRCs) will be covered for a period of ninety (90) days (six (6) months where longer periods are required by law) from the date of installation, but not more than one (1) year from date of shipment.
  • Page 9 Acts or cause any part or all of this warranty to be void, is called a "Non-excludable Condition". To the full extent permitted by law, Fuji Xerox’s sole and total liability to the customer for a breach of any Non-excludable Condition (including for any consequential loss suffered by the customer) is limited, except as otherwise stated herein, to (at Fuji Xerox’s option) replacing or repairing the goods, or resupplying, or...

  • Page 10: User Safety Summary

    If any of the following conditions occur, switch off the printer power immediately, disconnect the power cord, and call an authorized service representative. The power cord is damaged or frayed. Liquid has spilled into the printer. Phaser 860 Color Printer...
  • Page 11 The printer is exposed to water. Any part of the printer is damaged. Maintenance Safety Do not attempt any maintenance procedure that is not specifically described in the documentation supplied with your printer. Do not use aerosol cleaners. The use of supplies that are not approved may cause poor performance and could create a dangerous condition.
  • Page 12 Exercise care in moving or relocating the printer. It is front heavy and could tip forward. Follow the recommended procedure when moving the printer from one location to another. Refer to the Phaser 860 Setup Instructions and page 68 of this User Guide.
  • Page 13 Do not open the covers while printing. Do not switch off the printer power while printing. Do not move the printer while printing. Refer to page 68 for instructions for moving the printer. User Guide 0726-40 0726-41 xiii...
  • Page 14 If the product loses the ground connection, usage of knobs and controls (and other conductive parts) can cause an electrical shock. Electrical products may be hazardous if misused. Warning For your protection, do not defeat any door switches. 4525-105 4525-104 Phaser 860 Color Printer...

  • Page 15: Printer Parts And Supplies

    Inside the printer, all handles and points of user interaction are green. Disposable parts in the Maintenance Kit are orange. To order supplies and accessories, contact your local dealer or visit the Xerox web site: www.xerox.com/officeprinting/supplies/ Customer-Replaceable Consumables (CRCs) Maintenance Kits...

  • Page 16: Customer-Replaceable Units (Crus)

    Phaser 860 ColorStix® II Ink Item 3 Free Black ColorStix II ink 5 Black ColorStix II ink 5 Cyan ColorStix II ink 5 Magenta ColorStix II ink 5 Yellow ColorStix II ink 5 Cyan ColorStix II ink plus 2 Free Black Colorstix II ink...

  • Page 17: Accessories

    Accessories Trays Item Standard Paper/Transparency Tray Holds 200 sheets of paper Holds 50 sheets of labels Holds 50 transparencies Legal Paper Tray Holds 200 sheets of legal paper High-Capacity Transparency/ Label Tray Holds 175 transparencies Holds 100 sheets of labels High-Capacity Paper Tray Assembly Item Holds 500 sheets of Letter-size or A4-size paper...
  • Page 18 Up to 192 Mbytes maximum The printer has two memory slots. When adding memory, you can use 64-Mbyte and 128-Mbyte DIMMs in combination. Part Number 860HD Part Number 860FN 860FP Size Part Numbers 64 Mbytes ZMC64 128 Mbytes ZMC128 Phaser 860 Color Printer...

  • Page 19: Paper And Specialty Media

    Paper and specialty media Xerox Phaser paper, transparencies, labels, and business cards have been developed and tested specifically for use in your Phaser 860 color printer. They will provide optimal print quality, reliability, and durability. Xerox Phaser Professional Printing Paper...
  • Page 20 Xerox Phaser Professional Printing Paper Item Phaser Premium Cover Paper 160 g/m (60 lb. cover) Phaser High Resolution Photo Paper 170 g/m Phaser High Resolution Photo Paper 170 g/m Phaser 860 Transparency Film Item Size Premium A/Letter (U. S.) 8.5 x 11 in.
  • Page 21 Premium Die-cut Business Cards Size Description A/Letter (U. S.) 25 sheets; 8.5 x 11 in. 10 pre-cut cards per sheet heavyweight: 190 g/m A4 (Metric Letter) 25 sheets; 210 x 297 mm 10 pre-cut cards per sheet heavyweight: 190 g/m User Guide Part Number 016-1898-00...

  • Page 22: Front Panel

    OK key — selects the highlighted menu setting Information key — (press at any time) displays additional information on the message or menu on the display screen P h a s e r 8 6 0 Phaser 860 Color Printer 0726-42...

  • Page 23: Printing A Menu Map

    Printing a Menu Map The Menu Map shows you where features, such as the information pages, are located in the front panel’s menu structure. With Menus highlighted, press the OK key. Scroll to Print Menu Map by pressing the Scroll Up or Scroll Down key.

  • Page 24: Features

    Features Your Phaser 860 Color Printer comes with many useful features to help you create the best possible printed documents. You can access the printer features in the printer driver, which you use when you send a print job to the printer. To ensure that you have access to all of the printer features, make sure you have installed the printer driver that comes on your Phaser 860 Printer CD-ROM.

  • Page 25: Print Quality Modes

    Print quality modes You can choose between different print quality modes to obtain the best combination of speed and print quality for your job. Print quality mode Fast Color Fastest color print mode Ink-saving mode since prints lighter than Standard mode Useful for text and business graphics Ideal for previewing work Produces fast, high-quality...

  • Page 26: Tekcolor™ Color Corrections

    Matches commercial Toyo printing inks on coated paper Matches the Fuji Color Art System for commercial North American proofs Produces a black-and-white version of a document Colors converted to grayscale Use to print page masters for photocopying in black-and-white Phaser 860 Color Printer...

  • Page 27: Paper And Print Media

    Paper and Print Media Paper tips Only use the supported paper types, sizes, and weights. Do not use perforated paper. Store the paper on a flat surface, in a relatively low-humidity environment. Avoid storing paper in such a way as to cause wrinkling, bending, curling, etc.
  • Page 28 Transparency ency Tray * Tray ** /Label Tray * • • • • • • • • • • • Phaser 860 Color Printer Legal Manual Paper -Feed Tray * Slot • • • • • • • • •...

  • Page 29: Print Area Of Supported Paper Sizes

    Print area of supported paper sizes The image area of a print is slightly smaller than the paper size. You may need to adjust the page margins in your application software to match the print area. When sending a job to the printer, select the paper size in the printer driver.
  • Page 30 152 x 197 mm 5 mm 100 x 206 mm 5 mm 110 x 221 mm 5 mm 80 x 191 mm 5 mm Phaser 860 Color Printer Left/ right margins (C/D) .275 in. .275 in. .275 in. 7 mm...

  • Page 31: Loading Trays

    Loading Trays For a list of the recommended paper, transparencies, and labels that can be used in each type of tray, refer to page 14. Loading the Standard Paper/Transparency Tray You can also refer to the labels inside the tray for loading instructions. Pull out the tray.
  • Page 32 Slide the tray back into the printer. Note Do not place paper that was printed on one side back into the printer to print on the second side. Pre-printed pages may stick together. 0726-02 Transparency 0726-04 0726-06 Phaser 860 Color Printer 0726-03 0726-05...

  • Page 33: Loading The Optional High-Capacity Paper Tray

    Loading the Optional High-Capacity Paper Tray The optional high-capacity paper tray assembly is located under the base printer. You can have one or two high-capacity paper tray assemblies. The trays are then called the Middle Tray and Lower Tray in the printer driver software. Note Do NOT load transparencies in a high-capacity tray.
  • Page 34 For two-sided jobs, place the letterhead paper face down with the letterhead toward the back of the tray. Remove any sheets that are damaged. 0726-10 0726-77 Phaser 860 Color Printer...
  • Page 35 Tilt the back left corner of the tray downward slightly and shake the tray front-to-back several times until the paper is uniformly aligned along the left side of the tray and rear paper stop. Re-insert the tray in the printer. User Guide 0726-11 0726-13...

  • Page 36: Loading The Optional High-Capacity Transparency/Label Tray

    Observe the fill lines on the left side of the tray. Don't load transparencies above the Transparency fill line. Don't load labels above the Label fill line. 0726-54 Phaser 860 Color Printer...

  • Page 37: Loading The Optional Legal Paper Tray

    If you loaded transparencies, make sure that the tray switch on the front-right side of the tray is set to Transparency (back position). If you loaded labels, make sure that the tray switch is set to Label (forward position). Transparency Slide the tray back into the printer.
  • Page 38 Make sure that you place the paper under the tabs in the back of the tray. Slide the tray back into the printer. To print on this paper, be sure to select Legal for the Paper Size in the printer driver. 0726-47 0726-06 Phaser 860 Color Printer...
  • Page 39 Note If necessary, install the Output Tray Extension into the holes on the back of the printer. This extension keeps your legal-size paper from falling off the printer after it is printed. User Guide 0726-70...

  • Page 40: Manual-Feed Printing

    Manual Feed-Transparency as the Paper Source. Note You also use the printer driver to select whether to print on one side or two sides. Send the job to the printer. If necessary, open the manual-feed slot. 0726-61 Phaser 860 Color Printer...
  • Page 41 If necessary, adjust the guide on the right side of the slot for Letter-size (and Legal-size) or A4-size paper. When the front panel displays the Waiting for Manual Feed prompt, insert one sheet or envelope into the manual feed slot until the printer pulls it in.
  • Page 42 Check the first print to make sure the image placement is correct. Wait for the front panel to display the prompt again before inserting the next sheet. 0726-46 0726-55 Phaser 860 Color Printer...

  • Page 43: Printing On Special Media

    Letterhead paper — see page 38 Printing on Phaser High-Resolution Photo Paper The Phaser High-Resolution Photo Paper can be printed on one side only, since it has a Xerox logo on the reverse side. Refer to page 5 for more information. You can either: Place up to 50 sheets of the photo paper face up in the standard paper/transparency tray.

  • Page 44: Printing On Labels And Business Cards

    Printing on labels and business cards Guidelines Use only Phaser 860 Printer Color Printing Labels or Xerox Phaser Premium Business Cards; refer to page 6 for more information. If any of the labels or business cards on a sheet are missing, do not use that sheet;...
  • Page 45 Choose to manually feed the labels. Don’t place the labels in the manual-feed slot until you are prompted by the printer’s front panel to do so. To print on business cards, use the manual-feed slot. Don’t place the sheet of business cards in the manual-feed slot until you are prompted by the printer’s front panel to do so.

  • Page 46: Printing On Transparencies

    Printing on transparencies Note Use only Phaser 860 Premium or Standard Transparencies. Refer to page 6 for more information. Handle transparencies by the edges and with both hands to avoid fingerprints and creases, which can cause poor print quality. To print on transparencies:...
  • Page 47 If you selected Manual Feed-Transparency, wait until the printer’s front panel prompts you, then insert the first sheet into the manual-feed slot so that the notch of the transparency is on the right side and enters the manual-feed slot last. Wait until you are prompted again before adding the next transparency.

  • Page 48: Printing On Envelopes

    Select your envelope size. Select Manual Feed-Paper as the Paper Source. If your application has a tool for creating envelopes, select the feed method that matches the illustration in Step 4. Send the job to the printer Phaser 860 Color Printer...
  • Page 49 When the printer’s front panel prompts you, insert the envelope in the manual-feed slot: Short side enters first. Flap is face up and closed. Printing envelopes from Microsoft WORD for Windows From the Tools menu, select Envelopes and Labels. In the Envelopes and Labels dialog box, click the Envelopes tab and type the delivery and return addresses.
  • Page 50 Click the OK button. In the Print dialog box, in General options, select Manual Feed Paper for Paper Source and click the Print button. When the printer’s front panel prompts you, insert the envelope in the manual-feed slot. Phaser 860 Color Printer...
  • Page 51 Printing envelopes from other applications on a Macintosh Follow the instructions in the application documentation. If the envelope address prints upside-down, change the Page Setup settings in your printer driver before printing on another envelope: From the File menu, select Page Setup. Select the following Page Attributes: Paper: select your envelope size.

  • Page 52: Printing On Letterhead Paper

    Two-sided job — Place the letterhead paper face up with the letterhead entering the manual-feed slot last. Wait until you are prompted again before adding the next sheet of paper. Phaser 860 Color Printer...

  • Page 53: Printing Two-Sided Jobs

    Printing Two-Sided Jobs You can have the printer automatically print two-sided (duplex) jobs using Letter-size, A4-size, or Legal-size paper in the paper trays or the manual-feed slot. Refer to page 14 for the weights and types of paper you can use. Do not print two-sided jobs on transparencies, labels, business cards, envelopes, heavy paper, card stock, index stock, or high-resolution photo paper.
  • Page 54 When the printer prints a two-sided job, the paper partially exits then is fed back in to print on the second side. To avoid paper jams, do not touch the paper before it completely exits the printer. Phaser 860 Color Printer...
  • Page 55 Setting the printer driver for two-sided printing Macintosh LaserWriter 8.6 LaserWriter 8.7 Windows 95 Windows 98 Windows 2000 Windows NT User Guide From the File menu, select Print, and then select Layout. Select Print on Both Sides. Select a binding preference. From the File menu, select Print.

  • Page 56: Troubleshooting Print Quality

    Scroll to Printable Pages Menu by pressing the Scroll Up or Scroll Down key. Press the OK key. Scroll to Print Diagnostic Pages. Press the OK key. Note You can also print the Diagnostic Pages from the Troubleshooting tab in the driver. Phaser 860 Color Printer...
  • Page 57 Band of colors prints correctly One or more color bars are missing On the front panel, select Eliminate Light Stripes to clean the printhead and print a test print: With Menus highlighted, press the OK key. Scroll to Support Menu by pressing the Scroll Up or Scroll Down key.
  • Page 58 Repeat up to three times in a row, if necessary. If the problem persists: Turn off the printer for at least 4 hours. When you turn on the printer, print the Diagnostic Pages and, if necessary, select Eliminate Light Stripes. Phaser 860 Color Printer...

  • Page 59: Smudges Or Smears Appear On The Print

    Smudges or smears appear on the print On the front panel, select Remove Print Smears. Repeat as needed. With Menus highlighted, press the OK key. Scroll to Support Menu by pressing the Scroll Up or Scroll Down key. Press the OK key. Scroll to Improve Print Quality?.

  • Page 60: Images Are Too Light Or Too Dark

    Select another print quality mode in the printer driver, then print the job again; refer to page 11. Select another color correction in the printer driver, then print the job again; refer to page 12. Transparency 0726-04 Phaser 860 Color Printer 0726-05...

  • Page 61: Paper Jams

    If paper is still jamming, flip the paper over in the paper tray. Clean the printer's rollers if they are visibly dirty. For more information, print the Help Guide from the printer’s front panel (as described on page 9) or visit the Xerox Customer Support website at www.xerox.com/officeprinting/support Clearing jams When there is a paper jam, the printer’s front panel displays a message...

  • Page 62: Paper Jam - Open Exit Cover To Clear

    If the paper has partially exited the printer at the exit slot: Using both hands, remove the jammed paper. If it cannot be removed easily, refer to Solution 2. Remove the entire sheet of paper; any pieces left in the printer may cause more jams. 0726-16 Phaser 860 Color Printer...
  • Page 63 Solution 2 If the paper has partially exited the printer but cannot be removed easily: Open the exit cover. Using both hands, remove the jammed paper. If the paper is still caught inside the printer, skip to Solution 3 (Step 2). Remove the entire sheet of paper;...
  • Page 64 Handle the Rapid Release Guide carefully to avoid bending or damaging the clear plastic edge. Lift up on the green tabs and remove the Rapid Release Guide. Do not use any sharp objects in this area of the printer. 0726-19 0726-20 Phaser 860 Color Printer...
  • Page 65 Remove the jammed paper. Make sure the thin, white dust shield is lying on top of the metal shaft. Then, reinstall the Rapid Release Guide, pressing down on the green tabs to snap the guide into place. Note Verify that the Rapid Release Guide is fully installed by gently tugging on it.

  • Page 66: Paper Jam - Open Front Cover To Clear

    If there is any resistance to removing the jammed paper, turn the green thumbwheel to help feed the paper. Remove the entire sheet of paper; any pieces of paper left in the printer may cause more jams. Close the front cover. 0726-23 0726-24 Phaser 860 Color Printer...

  • Page 67: Paper Jam - Remove Upper Tray Or Paper Tray To Clear

    Paper jam - Remove upper tray or paper tray to clear Completely remove the upper tray or paper tray. Using both hands, carefully remove the jammed paper. Re-insert the upper tray or paper tray. Paper jam - Remove middle tray to clear Completely remove the middle tray.

  • Page 68: Paper Jam - Remove Lower Tray To Clear

    Do not use tools to remove jammed paper from the exit area. Using tools in this area could damage the printer's imaging surface. Follow the steps that start on page 48 to remove the jam from the exit area. 0726-27 Phaser 860 Color Printer...

  • Page 69: Paper Jam - Retry Manual Feed

    Paper jam - Retry manual feed Using both hands, remove the jammed paper, transparency, label, or business card sheet. Verify that the paper (or other media) is the correct size and is within specifications; refer to page 14. Verify that the manual-feed slot is fully extended by gently pushing it downward.

  • Page 70: Maintenance And Cleaning

    Maintenance and Cleaning Adding ink Refer to page 2 for information on Phaser 860 ColorStix II ink. Caution Use only Phaser 860 ColorStix® II ink; the use of other ink or ink designed for other Phaser® color printers may affect print quality and reliability.
  • Page 71 Determine which ink-loading bin needs ink. A label above each bin indicates the color and color number of that bin. Remove the ink stick from its packaging. Note Because the magenta, cyan, and black ink sticks are all dark, refer to its color number; this number corresponds to the bin for that the color.

  • Page 72: Emptying The Waste Tray

    Caution The printer’s interior may be hot. Do not touch the hot surfaces! Open the front cover. Pull out the maintenance drawer (labeled A), if it is not locked. 0726-23 0726-33 Phaser 860 Color Printer...
  • Page 73 Note The maintenance drawer is locked during the warm-up cycle whenever the printer is turned on and while the ink cools after the Eliminate Light Stripes troubleshooting routine. If the maintenance drawer is locked, close all covers and wait 15 minutes before repeating steps 1 and 2. Lift the waste tray (labeled B) from the maintenance drawer.
  • Page 74 Re-insert the maintenance drawer in the printer. Close the front cover. Note Do not attempt to reuse the waste ink in the printer; it may damage the printer. This damage is not covered under the printer warranty. Phaser 860 Color Printer...

  • Page 75: Replacing The Maintenance Kit

    Replacing the Maintenance Kit The Maintenance Kit is a consumable that consists of the maintenance roller (labeled C1) that maintains the surface of the imaging drum and counter (labeled C2). The kit is located in the maintenance drawer (labeled A), which is accessed from the printer's front cover. Order a new Maintenance Kit when the front panel displays a message telling you that the Maintenance Kit is low.

  • Page 76: Cleaning The Rapid Release Guide

    Cleaning the Rapid Release Guide Open the exit cover. Tilt up the green paper guide. Caution Handle the Rapid Release Guide carefully to avoid bending or damaging the clear plastic edge. 0726-17 0726-19 Phaser 860 Color Printer...
  • Page 77 Remove the Rapid Release Guide by lifting up on the green tabs. Do not use any sharp objects in this area of the printer. Gently clean the plastic Rapid Release Guide by wiping it with a pre-soaked alcohol cloth (using 90% isopropyl alcohol). User Guide 0726-20 0726-37...
  • Page 78 Note Verify that the Rapid Release Guide is fully installed by gently tugging on it. If it isn’t snapped into place, it may cause jams and print quality problems. Close the exit cover. 0726-22 Phaser 860 Color Printer...

  • Page 79: Cleaning The Maintenance Drawer Wiper Blade

    Cleaning the maintenance drawer wiper blade Open the front cover. Remove the maintenance drawer (labeled A). Use a lint-free cloth to clean the top and upper edges of the flexible plastic wiper blade located on the top of the maintenance drawer between the roller and waste tray.

  • Page 80: Cleaning The Exit Rollers

    Open the exit cover. Clean the exit rollers using a pre-soaked alcohol cloth (using 90% isopropyl alcohol). To turn the rollers, turn the green thumbwheel. Close the exit cover. Cleaning the paper-feed rollers Open the front cover. 0726-53 0726-23 Phaser 860 Color Printer...
  • Page 81 Remove the maintenance drawer (labeled A). To clean the rollers in rows 1, 2, and 3, use a pre-soaked alcohol cloth (using 90% isopropyl alcohol). To turn the rollers in rows 1 and 3, turn the green thumbwheel. Clean any ink from the polished metal guide (located between rollers 1 and 2) using a pre-soaked alcohol cloth (using 90% isopropyl alcohol).

  • Page 82: Moving And Shipping The Printer

    After the ink has cooled, unplug the printer. Remove the upper paper tray to provide a place for your hands when lifting the printer. Note Always move the printer separately from its High-Capacity Paper Tray Assembly. 0726-80 Phaser 860 Color Printer...

  • Page 83: Shipping The Printer

    Have two people move the printer to the new location. Shipping the printer To prepare the printer for shipment, complete steps 1 through 5 starting on page 68, then: Open the front cover. Remove the Maintenance Drawer (labeled A) and place it in a plastic bag for storage.
  • Page 84 If you don’t have the original carton or packing material, order replacement packaging from Xerox (part number 065-0594-00). To avoid shipping damage, refer to the instructions on the printer’s CD-ROM or the following Xerox web site: www.xerox.com/officeprinting/support Phaser 860 Color Printer...

  • Page 85: Getting Help

    Phaser color printer. Read Me release notes Printer drivers Driver installers (for Mac and Windows) Phaser 860 Color Printer User Guide (this manual) Advanced Features and Troubleshooting Manual Setup Guide poster How-to videos Networking information...

  • Page 86: Xerox Web Sites

    Troubleshooting Guide. To access the Phaser 860 printer driver: Click Start, select Settings, then click Printers. In the Printers folder, right-click the icon for your Phaser 860 printer. From the popup menu, select Properties. Xerox web sites www.xerox.com/officeprinting/...
  • Page 87 Link to information about CentreWare IS Requires network connection via TCP/IP Other online services Subscribe to email update notices: Technical Support: To find a local reseller See www.xerox.com/officeprinting/contacts for the most updated information. U. S. 1-800-835-6100 User Guide www.colorconnection.xerox.com/ www.xerox.com/officeprinting/support...

  • Page 88: Customer Support Centers

    Customer support centers See www.xerox.com/officeprinting/support for the most updated contact information. U. S. and Canada 1-800-835-6100 Argentina 54-114-378-5444 Australia 1-800-811-177 Austria 017956 7083 Belgium-Dutch 070 222 047 Belgium-French 070 222 045 Bolivia +(5913)472662 Brazil 0800-21-8400 Caribbean (305)716-3925 (Miami) Central America...

  • Page 89: Specifications

    II Ink, Magenta ® ColorStix II Ink, Yellow Four color "rainbow" pack Supplies Start-up Kit Product Use: XEROX Phaser SECTION 2 - INFORMATION ON INGREDIENTS ® Xerox Phaser 860 ColorStix fatty amide waxes, resins, and dyes. The specific identity of ingredients is withheld as a trade secret.
  • Page 90 TOXICITY: Oral LD >5 g/kg (rats); practically non-toxic SKIN IRRITATION: Primary Dermal Irritation Index = 0.0; not skin irritants. CARCINOGENICITY: Components not listed by IARC, NTP, or OSHA. SECTION 12 - ECOLOGICAL INFORMATION No known impact Phaser 860 Color Printer...

  • Page 91: Material Safety Data Sheet For Silicone Intermediate

    Xerox part number 016-1932-00 (replacement extended maintenance kit) Product Use: Xerox Phaser SECTION 2 - INFORMATION ON INGREDIENTS Xerox Silicone Intermediate Transfer Layer Fluid is a proprietary blend of silicone oils. Specific identities of components, and their percentage composition, are withheld as a trade secret.
  • Page 92 SECTION 3 - HAZARDS IDENTIFICATION ROUTES OF EXPOSURE: Skin, eyes POTENTIAL HEALTH EFFECTS: Health effects from this product are expected to be negligible, when product is used as intended in Xerox Phaser Color Printers. Immediate Effects: Inhalation: Not an expected route of entry Skin: May cause mild irritation.
  • Page 93 SECTION 14 - TRANSPORT INFORMATION DOT: Not regulated. SECTION 15 - REGULATORY INFORMATION The following information pertains to the ingredients of Xerox Silicone Intermediate Transfer Layer Fluid: TSCA (Toxic Substances Control Act): Listed in the TSCA inventory as verified by our suppliers.

  • Page 94: Material Safety Data Sheet For Cleantex® Alcopad

    INGESTION: In the unlikely event of ingestion of a wiper, first aid measures should focus on removal of the object and preventing choking. Once removed, keep affected person at rest. Call physician immediately. Xerox Part Number: 016-1845-00 ® 860 Color Printer Phaser 860 Color Printer ® Alcopad...
  • Page 95 SECTION 5 – FIRE-FIGHTING MEASURES FLASH POINT (TCC): 56 degrees F FLAMMABLE LIMITS (% BY VOLUME): LEL: NA AUTOIGNITION TEMPERATURE degrees F (degrees C): NA EXTINGUISHING MEDIA: Isopropyl-alcohol fires may be extinguished using carbon dioxide, dry chemical or alcohol foam. Water may be used to cool containers exposed to the fire.
  • Page 96 SECTION 15 – REGULATORY INFORMATION SARA TITLE III REPORTING: Toxic Chemical (Section 313): Extremely Hazardous Substance: Section 302, 304, 311, 312) Hazard Class: Chronic Health: Yes Acute Health: Yes Will not occur. Caustics, amines, Not Listed. Not Listed. Phaser 860 Color Printer...
  • Page 97 Fire Hazard: Yes Pressure Hazard: No Reactivity Hazard: No TSCA INVENTORY STATUS: inventory. SECTION 16 – OTHER INFORMATION The information provided herein is compiled from internal reports and data from professional publications. It is furnished without warranty of any kind, expressed or implied.
  • Page 98 Phaser 860 Color Printer...

  • Page 99: Index
