© Copyright 2019 LG Electronics U.S.A., Inc.
Lodging Guest Interactive Pro:Centric 
Commercial Mode Setup Guide
Note: Selected features shown in this guide may not be available on all models.
43UT570H
49UT577H
49UT570H
55UT577H
55UT570H
65UT577H
65UT570H
EXPERIENCED INSTALLER
EZ-Manager Wizard
pages 21 – 30
Custom Master TV Setup
pages 46 – 48
Cloning Procedures
pages 49 – 54
P/N: 206-4341 (Rev B)
®
TVs

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pro:Centric 43UT570H and is the answer not in the manual?

Questions and answers

Related Manuals for LG Pro:Centric 43UT570H

Summary of Contents for LG Pro:Centric 43UT570H

  • Page 1 Note: Selected features shown in this guide may not be available on all models. EXPERIENCED INSTALLER EZ-Manager Wizard pages 21 – 30 Custom Master TV Setup pages 46 – 48 Cloning Procedures pages 49 – 54 P/N: 206-4341 (Rev B) © Copyright 2019 LG Electronics U.S.A., Inc.

  • Page 2: Safety Warnings

    • Consult the dealer or an experienced radio/TV technician for help. CAUTION: Do not attempt to modify this product in any way without written authorization from LG Electronics U.S.A., Inc. Unauthorized modification could void the user’s authority to operate this product.

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Read these instructions. 16. Power Cord Caution: Check the TV specifications in the Owner’s Keep these instructions. Manual to determine power requirements. Heed all warnings. Periodically examine the cord of your appliance, and if its Follow all instructions. appearance indicates damage or deterioration, unplug it, discontinue use of the appliance, and have the cord replaced Do not use this apparatus near water.
  • Page 4 IMPORTANT SAFETY INSTRUCTIONS 26. Keep the product away from direct sunlight. (Continued from previous page) 27. When mounting a TV on the wall, make sure that none of the 21. Outdoor Antenna Grounding electrical cabling bears any of the weight of the TV. Install in If an outside antenna or cable system is connected to the accordance with the manufacturer’s instructions.

  • Page 5: Table Of Contents

    Table of Contents Safety Warnings ........2 Exporting a Clone File .

  • Page 6: Commercial Mode Overview

    This document describes how to set up UT570H or UT577H Pro:Centric  TVs for Commercial Mode operation. LG commercial TV functionality is based on “ownership” of the Channel Map; that is, the Channel Map resides in the TV’s CPU, Protocol Translation Controller (PTC), or embedded b-LAN™...

  • Page 7: Ftg Mode

    Commercial Mode Overview (Cont.) Installer Menu To create a Master TV Setup, you will need to know how to access PTC INSTALLER MENU the commercial controller (PTC) Installer Menu and make changes to xxUT570H the default values as required. If necessary, familiarize yourself with CPU - CTV the Installer Menu and how to make and save changes.
  • Page 8 EBL. In this mode, the EBL is the owner of the FTG Channel Map and must be LG’s Cloud Configuration Tool enables you to create configured with an FTG Channel Map and FTG Installer an FTG Configuration (.tlx) file, which may be used to Menu settings using one of the following processes: configure the CPU for FTG Mode.

  • Page 9: Application Tuning Mode / Pro:centric Direct

    137-0). While the TV is in FTG Mode: • Users can still access the Installer Menu using an LG Installer Remote; however, all Installer Menu items will be read-only. • FTG Mode via CPU configuration changes must be made using a “.tlx” file (typically edited in the Cloud Configuration Tool), while FTG Mode via EBL configuration changes must be made using the FTG Device Configuration Application.

  • Page 10: Determining The Tv Operating Mode

    Master TV Setup. See Reference section, “Using the TV Zoning Feature,” for further information. While the TV is in Application Tuning Mode: • Users can still access the Installer Menu using an LG Installer Remote; however, all Installer Menu items will be read-only.

  • Page 11: Pro:centric Operation

    Pro:Centric Operation These TV models support LG’s Pro:Centric Java application, as well as the Pro:Centric Direct HTML application. Only one application may be implemented at a time. The following sections provide an overview of the application features and functionality. Interactive Menu Features...
  • Page 12 Pro:Centric Operation (Cont.) Example: Pro:Centric Java (GEM) Application Portal Example: Pro:Centric Direct HTML Application Portal 206-4341...

  • Page 13: Pro:centric Java Application Setup

    TV in Factory Default State When the TV is in a factory default state, LG’s First Use Wizard provides automated or manual options for configuring the TV’s Pro:Centric server settings. See “First Use Wizard” on pages 16 to 17 for further information.

  • Page 14: Pro:centric Direct Html Application Setup

    TV in Factory Default State When the TV is in a factory default state, LG’s First Use Wizard provides automated or manual options for configuring the TV’s Pro:Centric server settings. See “First Use Wizard” on pages 16 to 17 for further information.
  • Page 15 Pro:Centric Operation (Cont.) TV in Application Tuning Mode If the TV is already in Application Tuning Mode, use a Master TV of the same model to create and export a Clone (.tlx) file with the desired settings for Installer Menu items 098 PRO:CENTRIC and 119 DATA CHANNEL.

  • Page 16: First Use Wizard

    • If you plan to create a customized Master TV Setup using the procedure described on pages 46 to 48, be sure to exit the LG First Use Wizard in order to avoid setup conflicts or setting modes that may cause unintended behavior or restrict the custom setup procedure. See also “Initiate Configuration or Exit the First Use Wizard”...
  • Page 17 First Use Wizard (Cont.) (Continued from previous page) WELCOME TO LG’S FIRST USE WIZARD Select the desired option, and then select START to continue. Basic Settings Quick settings for basic use (language, network, channel tuning). Solution Settings Use the EZ-Manager Wizard to configure the TV for Pro:Centric operation.

  • Page 18: Basic Settings Wizard

    Basic Settings Wizard This section describes the configuration options available when you select “Basic Settings” from the First Use Wizard / Welcome screen. You can select the “BACK” button, where available, to check previous settings, as necessary. Note: Each Basic Settings Wizard step is allotted a 10-second time frame after which the wizard proceeds without user interaction.
  • Page 19 Basic Settings Wizard (Cont.) (Continued from previous page) NETWORK SETTINGS Configure network settings. Network Connection Type Wired (Ethernet) Advanced Options IPv6 Disabled Automatically Assign IP Address IP Address 10.1.2.3 Subnet Mask 255.255.255.0 NEXT BACK NEXT This wizard will continue automatically in 10 seconds. b.
  • Page 20 Basic Settings Wizard (Cont.) (Continued from previous page) Tuning progress will be initiated/shown in a new Channel Tuning screen. The scan typically takes a few minutes. When the channel scan is complete, the TV will launch the IP Environment Menu. See additional information below. •...

  • Page 21: Ez-Manager Wizard

    EZ-Manager Wizard This section describes the EZ-Manager Wizard that is initiated when you select “Solution Settings” from the First Use Wizard / Welcome screen. Note: If the Pro:Centric server is configured on the system/network and if no location-specific settings are required in the TV, for example, TV Zone, Label, and/or Room Number settings, you can simply turn ON the TV, and once initiated, the wizard will proceed through each of the configuration steps with no further user interaction.

  • Page 22: Zone And Room Number Assignments

    EZ-Manager Wizard (Cont.) (Continued from previous page) Use the Up/Down arrow keys on the Installer Remote to navigate between options on this screen. • If you do not intend to install a Pro:Centric server on this system and you do not wish to use the wizard’s Zoning, network settings, or USB configuration options, exit the wizard as follows: Select NO PRO:CENTRIC, and then press OK.

  • Page 23: Network Settings

    EZ-Manager Wizard (Cont.) EZ-Manager Wizard (Cont.) (Continued from previous page) Note: The Zoning feature is only applicable for TVs that will be configured using a “.tlx” file (local or remote configuration). 1. Complete the appropriate field(s) as described below. Use the Up/Down arrow keys on the Installer Remote to navigate between each of the fields.

  • Page 24: Configure Pro:centric Settings

    EZ-Manager Wizard (Cont.) (Continued from previous page) 2. If not already done/detected, select the Wired (Ethernet) option in the Network Connection Type field, and then press OK on the Installer Remote. 3. By default, the TV uses DHCP, and if a LAN is detected, the TV will request an IP address from the DHCP server on the network.
  • Page 25 EZ-Manager Wizard (Cont.) SEARCHING FOR PRO:CENTRIC SERVER This step automatically searches for the Pro:Centric Server. If there is no Pro:Centric Server installed, you do not need to continue with this procedure. In this case, you can either select in the top right corner of the screen to exit or select MANUAL PRO:CENTRIC below to enter the Pro:Centric Server settings manually.
  • Page 26 EZ-Manager Wizard (Cont.) (Continued from previous page) Note: If, after completing the search, the TV is unable to find the Pro:Centric data channel (while the Searching for Pro:Centric Server screen is on display), the wizard will stop and show a Diagnostics screen that enables you to manually return to the previous screen (to reinitiate the configuration) or exit the wizard.
  • Page 27 EZ-Manager Wizard (Cont.) (Continued from previous page) PRO:CENTRIC MANUAL CONFIGURATION Pro:Centric Manual Configuration Screen < > with RF Media Fields Pro:Centric Mode CONFIGURATION ONLY < > Media Type Note: By default, the Pro:Centric Manual < > Data Channel Configuration screen initially shows RF Signal Strength configuration fields.
  • Page 28 EZ-Manager Wizard (Cont.) (Continued from previous page) IP Configuration a) In the Media Type field, use the Left/Right arrow keys to select IP. Note: When you select “IP” as the Media Type, the default RF Data Channel and Signal Strength/Quality fields are replaced with Server Address, IP Type, IP Address, and IP Port fields.

  • Page 29: Usb Configuration

    EZ-Manager Wizard (Cont.) (Continued from previous page) If you opt to initiate a real-time download in the last step, the EZ-Manager Wizard will proceed with the Pro:Centric application and/or E-Z Installation data downloads (see Processing the Pro:Centric Configuration screen example on page 25). When the Pro:Centric configuration is complete, an EZ-Manager Configuration Complete screen (see example on page 26) is displayed, and after 10 seconds, the wizard exits, and the TV turns OFF.
  • Page 30 EZ-Manager Wizard (Cont.) USB Configuration via EZ-Manager Wizard With either the TV Configuration Options or the Zone, Label, and Room Number screen on display, proceed as follows to configure the TV using the USB memory device. 1. Insert the USB memory device with the appropriate file(s) into the TV’s USB port. 2.

  • Page 31: Ez Download Utility

    Ez Download Utility The Ez Download utility, available from the TV Manager, enables you to select multiple files at one time from the files loaded on a USB memory device. You may use this utility to download any one or all of the following to a TV: •...
  • Page 32 Ez Download Utility (Cont.) (Continued from previous page) 3. If the TV is currently in Pass-through Mode, you would like to transfer (import) a “.tlx” file to the TV via the Ez Download utility, and you intend to use the TV Zoning feature, set the appropriate TV Zone # in the TV at this time.
  • Page 33 Ez Download Utility (Cont.) (Continued from previous page) EZ DOWNLOAD < 01 USB 1: Device Name DESELECT ALL DOWNLOAD Select the file(s) to download, and then select DOWNLOAD. Import Clone File None Channel Tuning / Channel None ChMap_IM.tlx Banner Display Download Image File Logical 1 File...
  • Page 34 Ez Download Utility (Cont.) (Continued from previous page) 8. If a Clone/Configuration (.tlx) file that includes an FTG Channel Map is selected, a Channel Tuning / Channel Banner Display field will be displayed at the right of the screen, and you can choose the format for the channel tuning/banner display.

  • Page 35: Installer Menu

    Installer Menu descriptions in this document if you are configuring the TV CPU using an FTG Configuration (.tlx) file created using LG’s Cloud Configuration Tool or configuring the EBL locally (.rml) or remotely (via FMA-LG102 / .fma) using the FTG Device Configuration Application software.

  • Page 36: Navigating Within The Installer Menu

    Installer Menu (Cont.) As part of the Installer Menu header (in all modes), two 3-character acronyms are displayed to indicate the TV’s current configuration mode. The table below lists all possible mode identifiers for these TV models. Acronym Description CPU-CTV Pass-through Mode with Channel Lineup in CPU CPU-FTG FTG Mode via CPU...
  • Page 37 Installer Menu (Cont.) Installer Menu Items 000 through 070 Item Function Value Range Default Value Brief Description of Function INSTALLER SEQ 0 – 3 Leave default set to 0. Selects the number of hours of inactivity allowed before the TV automatically POWER MANAGE 0 –...
  • Page 38 Installer Menu (Cont.) Installer Menu Items 071 through 122 Item Function Value Range Default Value Brief Description of Function BCK. CH-TIME 0 – 7 Chooses custom background color for MPI display characters. If set to 1 and item 028 CH. OVERIDE is set to 0, a “CHANNEL NOT CH NOT AVBLE 0 / 1 AVAILABLE”...

  • Page 39: Detailed Descriptions Of Installer Menu Items

    Installer Menu (Cont.) Detailed Descriptions of Installer Menu Items 000 - INSTALLER SEQUENCE first time the TV is turned OFF after this item is set to 3 or 19, the Specifies entry sequence to the Installer Menu. TV will reboot and initiate an update event (Data Channel Auto Search and/or check for and download of updates—see also 0 = 9876 1 = 4321...
  • Page 40 Installer Menu (Cont.) 005 - CHAN LOCK (Channel Lock) 010 - MUTE DISABLE Channel Lock is ideal if the system must always be on the same Enables or disables the sound Mute function. If set to 1, sound channel. If set to 1, Channel Lock is enabled and it is not possible cannot be muted.
  • Page 41 Disabled External Speaker (Optical) 041 - SIMPLINK EN Enabled LG Sound Sync (Optical) Set to 0 to disable the SIMPLINK feature. Set to 1 to enable Disabled LG Sound Sync (Optical) SIMPLINK functionality (does not enable remote control access to...
  • Page 42 Installer Menu (Cont.) Note: Values 10 & 11 are only available if item 041 SIMPLINK EN 078 - UPN MSB (UPN Most Significant Byte) is set to 1 (enabled). User programmable number, most significant byte readable by MPI command. Note: Not linked to serial number. Note: If a SIMPLINK-enabled device is connected to the TV and item 041 SIMPLINK EN is set to 1 (enabled), the SIMPLINK 079 - UPN MSB-1 (UPN Most Significant Byte-1)
  • Page 43 Installer Menu (Cont.) 092 - HDMI3 ENABLE 097 - AUDIO OUTPUT Set to 1 to enable HDMI 3 input in DTV Mode. Set to 2 to enable Determines availability and signal type/level (fixed speaker, HDMI 3 input in PC Mode. Set to 0 to disable display panel HDMI variable speaker, or fixed line level [amplifier]) of the audio output to 3 input.
  • Page 44 Installer Menu (Cont.) If set to 201 or 202, back lighting can be controlled via the Picture 118 - POWER SAVINGS settings in the TV setup menus. However, each time the TV is Default set to 3—the power circuitry for both the embedded b-LAN turned ON, Picture Mode (set in Picture Menu) is defaulted to module and the GAME CONTROL/MPI port is only powered when Intelligent Sensor.
  • Page 45 Installer Menu (Cont.) 121 - UPDATE TIME HR If the TV display is ON when a Wake For Update event is to occur, Based on the settings of this item and item 122 UPDATE TIME MN, the update will take place the next time the TV is turned OFF. the Wake For Update feature wakes the TV once daily to check for Caution: UPDATE TIME HR should NEVER be set to 255.

  • Page 46: Custom Master Tv Setup

    Custom Master TV Setup This section describes how to create a customized Master TV Setup for cloning purposes when the TV is in Pass-through Mode. All cloning (export and import) processes on the TV are performed via USB memory device / “.tlx” file. The Master TV Setup may be exported to a Clone (.tlx) file, which can then be used (i.e., imported) to configure either TVs that are to remain in Pass-through Mode or TVs that are to be configured for FTG Mode via CPU.

  • Page 47: Custom Master Tv Setup Procedure

    Custom Master TV Setup (Cont.) Custom Master TV Setup Procedure 1. Turn ON the TV. The next step depends on whether the First Use Wizard appears on the screen when you turn ON the TV: • If the wizard is displayed, the TV is in the required factory default state. Exit the wizard, and then continue with step 2.
  • Page 48 Custom Master TV Setup (Cont.) (Continued from previous page) 4. Set up TV features. On-screen setup menus control the features of the TV. Press MENU PICTURE SETTINGS on the Installer Remote, and select the All Settings Picture menu icon from the Quick Settings Menu to access the advanced TV setup menus.

  • Page 49: Cloning Procedures

    Cloning Procedures Cloning typically refers to the process of using a Master TV Setup to configure a Target TV. This section describes how to save (export) a Master TV Setup and then transfer (import) it to a Target TV using a USB memory device / Clone (.tlx) file. You can also create an FTG Configuration (.tlx) file using the Cloud Configuration Tool and then use the Import Clone File procedure to transfer the configuration to Target TVs.
  • Page 50 Cloning Procedures (Cont.) (Continued from previous page) 5. Use the arrow navigation keys to select/highlight either the General menu icon from the TV setup menus or the Safety menu icon from the Function Menu. Then, press the number “7” key a total of seven times to access the TV Manager.

  • Page 51: Importing A Clone File

    Cloning Procedures (Continued from previous page) 9. Modify the filename, as required. While the TV model element of the filename may not be changed, you can differentiate this Clone file from other UT570H/UT577H Clone files by changing the numeric assignment appended to the end of the filename. Select/highlight the filename, and then use the Up/Down arrow keys on the Installer Remote to scroll through numeric assignments until the desired number is shown.
  • Page 52 Cloning Procedures (Cont.) (Continued from previous page) • If the Target TV is currently in Pass-through Mode and you intend to use the TV Zoning feature—i.e., the Clone/Configuration (.tlx) file you are importing contains an FTG Channel Map and/or FTG profile(s) with TV Zone assignments—make sure to set the appropriate TV Zone # in the TV when directed to do so in the procedure below.
  • Page 53 Cloning Procedures (Cont.) (Continued from previous page) • If the wizard is displayed, you can complete the import procedure via the EZ-Manager Wizard, as indicated above (see “Before You Begin”). However, to continue with this procedure and access the “Import Clone File” option from the TV menus, exit the First Use Wizard. Then, continue with step 3.
  • Page 54 Cloning Procedures (Cont.) (Continued from previous page) DATA CLONING < 01 USB 1: Device Name UPDATE Select the file to download, and then select UPDATE. Import Clone File None Channel Tuning / Channel ChMap_IM.tlx Banner Display Logical Physical 9. Use the arrow keys on the Installer Remote to select/highlight the “.tlx” file to import, and then press OK.

  • Page 55: Cloud Configuration Tool Overview

    EBL IS IN FTG MODE, THE CPU CANNOT BE SWITCHED TO FTG MODE. This section provides an overview of LG’s Cloud Configuration Tool web application, which is used for FTG Mode via CPU configuration. For best results, it is recommended that you access the Cloud Configuration ®...
  • Page 56 Cloud Configuration Tool Overview (Cont.) (Continued from previous page) • If you are creating an FTG Configuration file from scratch and this is your first time using the Cloud Configuration Tool, you may wish to select the Wizard Setup, which will guide you through the essential steps of creating the file, i.e., creating the FTG Channel Map and/or the Installer Menu profile(s).
  • Page 57 Cloud Configuration Tool Overview (Cont.) (Continued from previous page) 3. If you need to edit the FTG Channel Map from an existing file (see previous step) or create a new FTG Channel Map, click on CHANNEL MAP in the menu options bar at the top left of the page to access the Channel Map web page (see example on page 59), and edit/create the FTG Channel Map.

  • Page 58: File Manager Web Page Overview

    Cloud Configuration Tool Overview (Cont.) File Manager Web Page Overview The File Manager page (displayed after you select ADVANCED SETUP from the Welcome page) enables you to compile, modify, and save (export) FTG Configuration (.tlx) files. The following example provides an overview reference of the functions available on the File Manager page. Data contained in uploaded FTG Data to be saved in the FTG Configuration (.tlx) file.

  • Page 59: Channel Map Web Page Overview

    Cloud Configuration Tool Overview (Cont.) Channel Map Web Page Overview On the Channel Map page, you can create, view, and edit a Logical Channel Map. Click the RF CHANNEL button Search for existing channels or to add a new RF channel to clear the FTG Channel Map.

  • Page 60: Installer Menu Web Page Overview

    Cloud Configuration Tool Overview (Cont.) Installer Menu Web Page Overview Load default Installer Menu for selected model. Assign Zone as applicable. Once you click on CREATE (Advanced Setup only) Cloud PROFILE, this Installer Menu profile will be listed under Configuration Tool menu bar the Installer Menu Profile List, and Installer Menu items provides access to all utilities.

  • Page 61: Ip Environment Setup

    IP Environment Setup The IP Environment Menu enables you to set up the network features of the TV. If you intend to create a Master TV Setup for cloning purposes (see Master TV Setup procedure on pages 46 to 48), all IP Environment settings, with the exception of network settings, may be cloned. Note: With the exception of network settings, the IP Environment settings are editable (with the Installer Remote) only if the TV is in Pass-through Mode and read-only when the TV is not in Pass-through Mode.
  • Page 62 IP Environment Setup (Cont.) Configuring a Wired Network Connection 1. Connect the appropriate cable between the TV and the network. NETWORK SETT... 2. With the Network Menu on display, use the arrow keys on the Network Installer Remote to select Network Settings. Then, press OK. A Network / Network Settings screen (see example at right) will be displayed.

  • Page 63: Pro:centric Setup

    IP Environment Setup (Cont.) (Continued from previous page) If the network is connected successfully, a “Connected to Internet” message will appear just below the progress display. If the network connection is not successful, the progress display will identify the network element in which the connection failed. Check your cabling and/or verify the configuration data, as necessary.
  • Page 64 IP Environment Setup (Cont.) (Continued from previous page) • When the Data Channel field is set to “MANUAL,” a data entry field is available on the screen, and you can specify the RF channel number that will be used by the Pro:Centric server as its data channel.
  • Page 65 IP Environment Setup (Cont.) (Continued from previous page) 4. Select/highlight the Mode field and press OK on the Installer Remote to display the drop-down list of options. Then, use the Up/Down arrow keys to select the appropriate Pro:Centric Application Mode setting—Configuration Only, GEM (Java), or HTML. If the Pro:Centric Application Mode is set to “Configuration Only,”...

  • Page 66: Remote Jack Pack / Tv Connections & Setup

    Reference: Remote Jack Pack / TV Connections & Setup Remote Jack Pack Setup RJP Available? If you will use a Remote Jack Pack (RJP) in your system, set Installer Menu item 093 RJP AVAILABLE appropriately (for example, on a legacy model RJP: HDMI Mode, set RJP AVAILABLE to 1).

  • Page 67: Updating Tv/Ptc Software Using A Usb Memory Device

    Reference: Updating TV/PTC Software using a USB Memory Device This section describes how to update TV (CPU) and/or PTC software using the TV Manager “Update TV Software” and/or “Update PTC Software” option(s), respectively, though you may also use the Ez Download utility to update software, if desired. See “Ez Download Utility” on pages 31 to 34 for further information.
  • Page 68 Reference: Updating TV/PTC Software using a USB Memory Device (Cont.) (Continued from previous page) Note: Ez Download is always selected by default when you initially access the TV Manager. Also note that Diagnostics is for service use only. 5. Use the arrow keys to select Software Update, and then press OK. 6.
  • Page 69 Reference: Downloading a Boot Logo Image using a USB Memory Device This section describes how to download a boot logo image using the TV Manager “Image Download” option, though you may also use the Ez Download utility to download the boot logo, if desired.
  • Page 70 Reference: Downloading a Boot Logo Image using a USB Memory Device (Cont.) (Continued from previous page) Note: Ez Download is always selected by default when you initially access the TV Manager. Also note that Diagnostics is for service use only. 5.

  • Page 71: Power Consumption Settings

    Reference: Power Consumption Settings The following tables assume that Installer Menu item 099 BACK LIGHTING is set as shown below (default value is 255). 43UT570H 49UT570H 55UT570H 65UT570H Item 099 Power Power Power Power Back Lighting Percent Percent Percent Percent Consumption Consumption Consumption...
  • Page 72 Reference: Power Consumption Settings (Cont.) The following tables assume that Installer Menu item 099 BACK LIGHTING is set as shown below (default value is 255). 49UT577H 55UT577H 65UT577H Item 099 Power Power Power Back Lighting Percent Percent Percent Consumption Consumption Consumption (Static) Savings...

  • Page 73: Tv Aux Input Configuration

    Reference: TV Aux Input Configuration ENABLE MPI DATA MPI DATA DATA STATUS DATA STATUS DIRECT ACCESS STATUS TYPE TYPE 0xD2 TYPE 0x0D Tuning Installer Installer Menu 0x41 SOURCES CURRENT AV Menu Item ENABLED (R/W) SOURCE (R) SOURCE (R) 046 START AUX SRCE Installer Installer...

  • Page 74: B-Lan Setup & Overview

    3 (default) A b-LAN enabled head end device, such as an LG FMA-LG102, broadcasts over the RF distribution system to communicate to multiple TVs. When the TV is first installed, it must be turned ON in order for its embedded b-LAN module to receive communication from the head end device.

  • Page 75: Ftg Mode Via Ebl (Local Configuration)

    (EBL) connection. Refer to the Free-To-Guest (FTG) Device Configuration Application User Guide for further information. FTG Device Configuration Application software is available online at: www.lg.com/us/business/display-solutions/ftg. Note: If the TV CPU is already in FTG Mode, you cannot use this procedure to make changes to the FTG Channel Map and FTG Installer Menu settings.
  • Page 76 Reference: FTG Mode via EBL (Local Configuration) (Cont.) (Continued from previous page) Note: If Installer Menu item 118 POWER SAVINGS is set to 3 (default), the TV must be ON in order for steps 5 and 6 to be successful. 5.

  • Page 77: Auto Input(S) Sensing Feature

    Reference: Auto Input(s) Sensing Feature This section provides detailed settings information for Installer Menu item 042 AUTO INPUTS. To disable auto-sensing for all available Aux inputs, set item 042 to 0. To enable auto-sensing for all available Aux inputs, set item 042 to 255. For specifications on all other available settings (i.e., settings for individual inputs), refer to the Aux Inputs Values table on the following page.
  • Page 78 Reference: Auto Input(s) Sensing Feature (Cont.) The following table shows all available Aux inputs as if each is enabled in the Installer Menu. The Installer Menu text codes for item 042 will be altered accordingly if any of the available Aux inputs are disabled in the Installer Menu.

  • Page 79: Rjp Model List & Input Auto-Sensing Hierarchy

    Reference: RJP Model List & Input Auto-sensing Hierarchy RJP Legacy Models • RJP-101M • RJP-110WBR • RJP-101ML • RJP-110S • RJP-110F • RJP-120G • RJP-110FW • RJP-120T • RJP-110W • RJP-201B/202B RJP Scaler Models • RJP-301B RJP Input Auto-sensing Hierarchy Priority Video Audio...

  • Page 80: Restoring Factory Defaults On The Tv(S)

    This section describes how to restore a single TV, regardless of its mode, to a factory default condition. The following procedure requires that you contact LG technical support to obtain a predefined value/ password for Installer Menu item 117 FACT DEFAULT that enables access to initiate a factory “IN-STOP”...

  • Page 81: Using The Tv Zoning Feature

    Reference: Using the TV Zoning Feature This section describes the TV Zoning feature available with the UT570H/UT577H model TVs. The TV Zoning feature enables you to create localized configurations for TVs in selected “Zones” within the installation site, for example, a hotel lobby, fitness center, restaurant, etc. This feature is primarily intended for use when the TV is configured for FTG Mode via CPU operation;...
  • Page 82 Reference: Using the TV Zoning Feature (Cont.) At the same time, keep in mind that the TV Zone designations are not mutually exclusive. That is, you may opt to place Zone restrictions on selected channels in the FTG Channel Map, but at the same time, you can choose to configure all TVs at the site with the same Installer Menu and/or Setup Menu settings.
  • Page 83 Reference: Using the TV Zoning Feature (Cont.) (Continued from previous page) • Label: Allows you to select a North, South, East, or West text label for this TV. Select/highlight the Label field and press OK. Then, use the Up/Down arrow keys to select the applicable label. Press OK when you are finished.

  • Page 84: Ut570H/Ut577H Rear And Side Jack Panels

    Reference: UT570H/UT577H Rear and Side Jack Panels OPTICAL DIGITAL AUDIO OUT Use for amps and home theater Use for video IP and/or network systems. Note: When the TV is connections. OFF, this port is not enabled. RJP Use Only SPEAKER OUT / LINE OUT Connection for Remote Jack Pack (RJP) (3.5 mm jack) Connect external audio (fixed Control cable.

  • Page 85: External Stereo Speaker Specifications

    Reference: External Stereo Speaker Specifications The SPEAKER OUT / LINE OUT 3.5 mm stereo jack on the UT570H/UT577H rear panel provides stereo speaker signal outputs (fixed speaker, variable speaker, or fixed line level [amplifier]) for external audio equipment. Set Installer Menu item 097 AUDIO OUTPUT as required in accordance with external audio equipment connected to the TV.

  • Page 86: Installer Remote Control Typical Key Functions

    Reference: Installer Remote Control Typical Key Functions The LG Installer Remote is supplied with and dedicated to operate the TV. The LG Installer Remote illustrated below shows typical remote control functions and is provided for reference only. This Installer Remote may vary from the Installer Remote supplied with the TV.

  • Page 87: Tlt Communication Parameters

    Reference: TLT Communication Parameters RS-232C Configuration RS-232C IN (CONTROL) Port Pin Configuration RS-232C IN (CONTROL) Pin Number Description DB9 Serial Port on TV 3.5 V RXD (Receive Data) TXD (Transmit Data) IR Out from TV No Connection No Connection No Connection No Connection If your configuring device has a DB9 serial port, use a DB9-Female to DB9-Female null-modem crossover cable to connect the device to the TV.
  • Page 88 Reference: TLT Communication Parameters (Cont.) Transmitting / Receiving Protocol This communication protocol transmits and receives 1-byte ASCII data representation for each Command, Set ID, and Data character. Therefore, a standard ASCII terminal program can be used to send and receive the protocol.
  • Page 89 Reference: TLT Communication Parameters (Cont.) Data Conversion (Hexadecimal : Decimal) In cases where decimal values are shown in commands, refer to following conversion examples to enter the [Data] value in the terminal program as hexadecimal. Note: The Channel Tune (ma) Command uses two-byte hexadecimal values ([Data]) to represent the channel number.
  • Page 90 Reference: TLT Communication Parameters (Cont.) Acknowledgment Acknowledgment [e][ ][Set ID][ ][OK/NG][Data][x] [j][ ][Set ID][ ][OK/NG][Data][x] 10. Sharpness (Command: k k) 05. Volume Control (Command: k f) To adjust the screen sharpness. To adjust volume. Command Structure Command Structure [k][k][ ][Set ID][ ][Data][CR] [k][f][ ][Set ID][ ][Data][CR] Data Min: 00 to Max: 32 Data Min: 00 to Max: 64...
  • Page 91 Reference: TLT Communication Parameters (Cont.) 14. Color Temperature (Command: x u) [Data1  –   4 ]: Major/Minor Channel number − Data1 & Data2: xx (Don’t care) To adjust color temperature. − Data3 & Data4: xx (Don’t care) Command Structure [Data5]: Input Source (Analog) −...
  • Page 92 Reference: TLT Communication Parameters (Cont.) 20. Input select (Command: x b) Acknowledgment To select input source for main picture.  * [a][ ][Set ID][ ][OK][Data 0][Data1] Command Structure [Data2][Data3][Data4][Data5] [x][b][ ][Set ID][ ][Data][CR] [x][a][ ][Set ID][ ][NG][Data0][x] Data 00: DTV 01: CADTV 17.
  • Page 93 Reference: TLT Communication Parameters (Cont.) Key Codes The following table provides key codes for a typical LG Installer Remote. Note: Some keys are not applicable to all models. Code Function Code Function (Hexa) (Hexa) PAGE (Green) PAGE (Red) (Yellow) (Blue)

  • Page 94: Troubleshooting

    If applicable, connect MPI cable to MPI device. Weak batteries. Replace batteries. Wrong battery polarity. Check that “+” and “-” match in battery compartment. Too much light in room. Dim room light. Wrong Installer Remote. Requires compatible LG Installer Remote. Contact your LG representative. 206-4341...

  • Page 95: Commercial Mode Check / Ftg Operation Troubleshooting

    Troubleshooting (Cont.) Commercial Mode Check / FTG Operation Troubleshooting Commercial Mode Check Use this flowchart to determine whether the TV is currently in Commercial Mode. Press POWER on Installer Remote. connected Plug into AC TV turned to AC Power outlet. Power? Leave the TV set ON, and press MENU...

  • Page 96: Glossary Of Terms

    Refers to a particular commercial mode of Pro:Idiom quiring the dash key. Also, channels (analog operation within an LG TV. See also FTG Zenith proprietary security software that or digital) can be arranged in any order that Mode.

  • Page 97: Notice

    In addition to the source code, all referenced license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping and handling) upon e-mail request to opensource@ lge.com.

  • Page 98: Back Cover

    Pro:Idiom is a registered trademark of Zenith Electronics LLC. Pro:Centric and the “LG” logo are registered trademarks of LG Electronics Inc. b-LAN is a trademark of SONIFI Solutions, Inc. All other trademarks or registered trademarks are the property of their respective owners.
