Samuel Office chair
Hardware
G. Long Bolts*4
H. Short Bolts*4
Tools Required
J. Allen Wrench (Included)
Assembly Picture
Components
A.
*1
Seat
B. Seat Adjuster*1
I. Flat Washers*4
C. Base*1
This page lists all the contents
included in the box. Please take time
to identify the hardware as well as the
individual components of this product.
As you unpack and prepare for
assembly, place the contents on a
D. Casters*5
carpeted or padded area to protect
them from damage.
A - Seat
B - Seat Adjuster
E. Gaslift*1
C - Base
D - Casters
E - Gaslift
F - Armrests
G - Long Bolts * 1.25*4.5CM
H - Short Bolts * 1.25*1.5CM
I - Flat Washers
J - Allen Wrench
F. Armrests*2
K - Parts Pack With two pairs of white
gloves and blue plastic shoe's cover.
1
Parts List
1
1
1
5
1
2
4
4
4
1
1
