Xerox DocuPrint 4050/4090 IPS

Master Index

Version 7.1

August 2000

721P88900

Need help?

Do you have a question about the DocuPrint 4050 IPS and is the answer not in the manual?

Questions and answers

Summary of Contents for Xerox DocuPrint 4050 IPS

Page 1 Xerox DocuPrint 4050/4090 IPS Master Index Version 7.1 August 2000 721P88900...
Page 2 Printing Systems Documentation and Education 701 South Aviation Boulevard, ESM1-058 El Segundo, CA 90245 ©1997, 1998, 1999, 2000 by Xerox Corporation. All rights reserved. Copyright protection claimed includes all forms and matters of copyrightable material and information now allowed by statutory or...
Page 3 Numerics 1.25 MB Data Streaming, CMS 3-4 1/4-inch cartridge tape drive, IPG 2-6 10Mb/sec twisted pair standard, IPG 4-7 2.5 MB Data Streaming, CMS 3-4 240 dpi resolution, SOG 1-6 300 dpi resolution, SOG 1-6 4 mm cartridge tape drive, IPG 2-3, IPG 5-8 4090 printer, high-capacity feeder, IPG 3-4 4mm cartridge tape drive, cleaning, PRM 6-2 50 Hz voltage requirements...
Page 4 INDEX IPS main window Reset Now, CMS 1-22 Save, CMS 1-22 PQA, CMS 4-17 using, CMS 1-5 bypass connectors, SOG 2-5 bypass transport option, IPG 1-4 cables bus, IPG 2-10 IBM channel, IPG 7-2 locations, IPG 7-2 power, IPG 6-2 tag, IPG 2-10 Cancel Job button, CMS 1-20 cartridge tape...
Page 5 IBM, IPG C-2 IBM channel connections, IPG 7-2 MVS, IPG E-17 MVS references, IPG E-17 OS/2, IPG E-35 Xerox, IPG C-1 documentation, other, IPG C-1 double-byte fonts, SOG 1-11 drives cartridge tape, IPG 2-3, IPG 2-6, IPG 5-8 CD-ROM, IPG 2-3, IPG 2-5...
Page 6 PRM 1-2–PRM 1-5 installation planning checklist, IPG 4-4–IPG 4-6 preparation, IPG 4-1–IPG 4-3 process, IPG 8-1 Xerox responsibilities, IPG 4-1 instruction labels, SOG 4-9 interface, CMS 1-11 IOCA (Image Object Content Architecture), SOG 1-4 IOCA Replicate and Trim, SOG 1-9...
Page 7 Initialization Dataset commands example, IPG printer definitions, IPG D-1 JES3 configuring, IPG E-4 FSS statement parameters, IPG E-4–IPG E-6 initialization dataset commands example, IPG job integrity, checking after paper jam, TRB 2-9 keyboard, IPG 2-4, IPG 2-7, IPG 5-9, SOG 2-4 keyboard, cleaning, PRM 6-1 labels selecting, IPG A-2, SOG A-2...
Page 8 INDEX NPS mode, switching, CMS 3-13 null modem connection, CMS 1-12 Number of Sets field, CMS 4-16 Number of Sheets field, CMS 4-16 N-Up, enhanced, SOG 1-10 Offline field, CMS 4-19 offline, taking, CMS 1-14, CMS 2-5, CMS 4-25 Online field, CMS 4-19 online, placing, CMS 1-14, CMS 2-5 operating systems supported, IPG 1-1 Operator Mode, CMS 4-2...
Page 9 supply, SOG 2-5 power outage, CMS 2-4 power saver mode, exiting, CMS 2-7 powering off, CMS 2-3–CMS 2-4 powering on, CMS 2-1–CMS 2-2 PQA button, CMS 4-17 PQA status window, CMS 4-17 predrilled paper, IPG A-2, PRM 1-2, SOG A-2 preprinted paper, IPG A-2, SOG A-2 pressure roll wiper, replacing, PRM 4-4–PRM 4-8 print job...
Page 10 INDEX changing, CMS 4-61 creating, CMS 4-57–CMS 4-60 deleting, CMS 4-61 dry ink, adding, PRM 5-1–PRM 5-4 duplex mode specifying simplex value, CMS 4-7, CMS 4-10 feed belt, cleaning, TRB 2-4–TRB 2-5 feeder trays, loading, PRM 1-3–PRM 1-5 fuser lubricant, adding, PRM 4-1–PRM 4-4 host jobs, printing, CMS 2-6 input configuration changing, CMS 4-44...
Page 11 CMS 3-4 site personnel, customer responsibility, IPG 4-2 preparation, customer responsibility, IPG 4-2 selection, Xerox responsibilities, IPG 4-1 Sixth Sense, IPG 1-5 Sixth Sense Remote Service, IPG B-2 Sixth Sense Technology, SOG 1-14, TRB 1-2 disabling a modem, TRB 1-3...
Page 12 CMS 2-5, CMS 3-5 TCP/IP Interface window, CMS 3-5 telephone numbers service, IPG B-1 Xerox Parts and Product Support Center, IPG Xerox Supply Center, IPG A-12, SOG A-12 test patterns, printing, CMS 4-13 Testdocs menu, CMS 4-14–CMS 4-17...
Page 13 Sun UltraSPARC, SOG 2-1 workstations see Sun workstations Xerox Customer Documentation Catalog, IPG B-3 Xerox Customer Education, IPG B-4, PRM 7-3 Xerox Customer Parts and Product Support Center, Xerox Customer Service Support Center, IPG B-1, Xerox Documentation and Software Services...
Page 14 INDEX CMS = Guide to Configuring and Managing the System IPG = Installation Planning Guide PRM = Guide to Performing Routine Maintenance SOG = System Overview Guide TRB = Troubleshooting Guide INDEX-12 MASTER INDEX FOR MODEL 4050/4090 IPS...
