- Page 1 Brukerveiledning Installation manual Installationsanvisning Asennusohje Montageanleitung Manuel d’installation Praha / Praha high Art.no: FP-PRA00-100 Last updated: 14.06.2019 Test Report No: SPFR 20012-20B1...
-
Page 2: Important Safety Precautions
2. Before use, please carefully read the user manual and follow the instructions. is installed. Nordpeis AS is not responsible for incorrect installation. never be reduced or partially obstructed. This may Important to check... - Page 3 All safety distances are minimum distances. Fresh air supply (accessory) Installation of the insert must comply with the rules and regulations of the country where installed. Nordpeis AS ATTENTION! The product can only be connected to is not responsible for wrongly assembled inserts.
- Page 4 Du trenger følgende verktøy You need the following tools SE Du behöver följande verktyg FI Tarvitset seuraavia työkaluja DE Folgende Werkzeuge sind notwendig. Vous avez besoin des outils suivants 10 mm 13 mm 17 mm...
- Page 5 FIG 1a - Praha / N-20U =mm...
- Page 6 FIG 1b - Praha high / N-20U =mm...
- Page 7 Praha / Praha high / N-20U = Air / Chimney connection = mm FIG 1B...
- Page 8 Praha/ Praha High / N-20U FIG 2 =Firewall/ Hitzenschutzwand / Mur parfeu / Parete non combustibile =Combustible material / Brennbarem Material / Matières combustibles/ Parete combustibile >700 mm >400 >1000 mm >1000 >700 mm >1000 mm >700 mm...
- Page 9 Praha / N-20U FIG 3 CO-PRA00-010 x1 CO-PRA00-020 x1 Praha / N-20U FIG 4 Air (*) (*) Air / Luft / Ilma...
- Page 10 Praha / N-20U FIG 4b Se egen monteringsanvisning for innsatsen / See separate instruction for the insert Se egen monteringsanvisning för insatsen / Voir le manuel d’installation séparé pour le foyer Beachten Sie die seperate Montageanleitung für den Kamineinsatz / Katso takkasydämen erillinen ohje...
- Page 11 Praha / N-20U FIG 5b 13 mm Praha / N-20U FIG 5c TORX 20 22-CAN00-120 - x1...
- Page 12 Praha / N-20U FIG 6 CO-PRA00-030 x1 Praha / N-20U FIG 7 22-PRA01-110 x2 10 mm 21-50001-018 x8 21-30004-016 x8...
- Page 13 Die Schienen werden mit der Verkleidung verschraubt. Bitte die Schrauben nur so fest anziehen, dass es noch möglich ist, die Schienen in den Langlöchern zu verschieben. Les équerres doivent être vissées sur l’habillage de manière lâche de façon à pouvoir ajuster l’habillage en alignant les trois pièces. Praha / N-20U FIG 8...
- Page 14 FIG 9 +/- 3 mm 13 mm Praha / N-20U FIG 10...
- Page 15 Praha / N-20U FIG 10a Praha / N-20U FIG 11 22-PRA00-050...
- Page 16 FIG 11a 22-PRA00-060 x1 21-40009-013 x2 Praha / N-20U FIG 12 22-CAN01-050 x2 21-50001-018 x2 10 mm 21-30004-016 x2...
- Page 17 Praha / N-20U FIG 12 a CO-PRA00-040 Viktig: For at peisen ikke skal slippe veggen er det viktig å påføre rikelig med akryl mellom omramning og vegg. Viktigt: För att inte kaminen skall släppa från väggen är det viktigt att använda rikligt med Acryl mellan omramning och vägg.
- Page 18 Praha / N-20U FIG 13 21-50001-018 x6 x3 A x3 B 21-30004-016 x6 Praha / N-20U FIG 13 a 10 mm 21-30004-035 x2 21-50001-018 x4 21-00000-006 x2...
- Page 19 Praha / N-20U FIG 13 b +/- 3 mm +/- 0 mm FIG 14 10 mm Stram til alle mutterne tilhørende x3 A från botten A & B Kiristä kaikki kiinnitysruuvit. Aloita alimmista - kohdat A&B. Fasten all screws with the rails to the x3 B concrete parts tightly.
- Page 20 Praha / N-20U FIG 15 22-PRA00-010 x1 Praha / N-20U FIG 15b 236 mm >...
- Page 21 Praha high / N-20U FIG 16 CO-PRA00-060 CO-PRA00-07L CO-PRA00-07R Praha high / N-20U FIG 16b 236 mm >...
- Page 22 Praha high / N-20U FIG 17 CO-PRA00-080 Praha high / N-20U FIG 18 CO-PRA00-090...
- Page 23 Praha; Praha high / N-20U FIG 19 FIG Z...
- Page 24 Nordpeis AS, Gjellebekkstubben 11, N-3420 LIERSKOGEN, Norway www.nordpeis.no...
