- Page 1 Operator’s Manual IP Multi SeaCam ® WARNING! Read this Operator’s Man- ual carefully before using this tool. Failure to under- stand and follow the con- tents of this manual may result in electrical shock, fire, and/or serious per- sonal injury. Original Instructions –...
-
Page 2: Table Of Contents
IP Multi SeaCam ® Table of Contents Table of Contents ........................... 2 Specification Overview ........................3 Safety Symbols ..........................4 General Safety Information......................4 Equipment Use and Care ......................4 Integration Procedure ........................5 Integrating Instruction........................5 Video Output ..........................5 System Setup .......................... -
Page 3: Specification Overview
Operator’s Manual Specification Overview IPMSC-3070 IPMSC-3105 Flat Port Dome Port Optical Specifications Lens 2.7 mm, f/2.9 DOME PORT 6.29 Focus Fixed, 100 mm~infinity 159.8 4.88 124.0 FOV in Water 72° H x 42° V 105° H x 60° V Video Specifications 1.87 2.72 Image Sensor... -
Page 4: Safety Symbols
IP Multi SeaCam ® Safety Symbols In this operator’s manual and on the product, safety symbols and signal words communicate important safety information. This section is provided to improve understanding of these signal words and symbols. This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. -
Page 5: Integration Procedure
Operator’s Manual SD Card Formatting Upon surfacing, the camera can become internally pressurized. If the power remains on when the cam- The IP Multi SeaCam comes with a standard 256 GB era has partially flooded, it is possible for electro- micro SDXC flash memory card for onboard video and lytic generation of an explosive mixture of hydrogen still image storage. -
Page 6: Web Based User Interface
IP Multi SeaCam ® Maintenance and Repair ● Configure the serial interface by setting baud rates, device addresses, switching between EIA- 232 or EIA-485 serial interfaces, and enabling a Flooding Repair Procedure termination resistor for EIA-485 operation. If the camera stops working while underwater, assume ●... -
Page 7: Rma Procedure For Repair
Operator’s Manual reattach the board to the camera or try a spare day or one-year warranty period, the sole obligation of driver board. DeepSea Power & Light LLC shall be to furnish new or repaired parts free of charge in exchange for parts which 5. -
Page 8: Appendix A Seasense Serial Interface Modification
IP Multi SeaCam ® Appendix A SeaSense Serial Interface Modification Revision Description Approved by Date Initial Release E. Bergstedt 1/4/2019 Name Signature Date Originator E. Bergstedt 1/4/2019 Operations SeaSense Serial Interface Modification Engineering Quality Document Control Document Number: 792-004-021 4033 Ruffin Road 4 January 2019 San Diego, CA 92123-1813 Sheet 1 of 3... - Page 9 Operator’s Manual SeaSense Serial Interface Modification 792-004-021 DeepSea Power & Light Version : 1.1 Serial Interface Modification Device Interface Type is supported on the Apex SeaCam, HD ZOOM SeaCam, and LED SeaLite Notes products. RealTerm is recommended when working through the RS232/RS485 interface. TeraTerm is recommend when connected through a USB port.
- Page 10 IP Multi SeaCam ® SeaSense Serial Interface Modification 792-004-021 Version : 1.1 2) Send !001:FPRT? The response will look similar to the image below. The example response above indicates that the device is set to RS232 at 9600 baud rate. 3) Send !001:FPRT=RS4,1 to set the device to RS485 at the default 9600 baud rate.
- Page 11 Operator’s Manual...
- Page 12 DeepSea Power & Light www.deepsea.com 4033 Ruffin Road sales@deepsea.com San Diego, CA 92123-181 T: 1-858-576-1261 F: 1-858-576-0219 © 2020 DeepSea Power & Light. All rights reserved. Rev 05/28/2020 Printed in USA...
