On-Screen Display (OSD) Menu

Using the OSD Menu

18
3 On-Screen Display (OSD) Menu
To create the best picture, your XM7 series has been preset at
the factory with the Preset Mode Timing shown on page 27.
The OSD (On-Screen Display) Menu allows the user to adjust
various settings and options by following the steps below.
1
Press the MENU button to display the OSD. The OSD main
menu provides an overview of the selection of controls
available.
advanced
audio
options
utilities
source
reset
exit
2
Press the DOWN or UP button to highlight the desired icon.
Then, press the MENU button to activate the highlighted
icon.
3
Press the DOWN or UP button to select the desired
adjustment icon. Then, press the MENU button.
4
Press the DOWN or UP button to change the value of the
selected item.
5
Select the exit icon to exit the OSD.
6
Repeat steps 1 through 4 to make further adjustments. All
changes are stored immediately.
auto adjust
brightness
contrast
h position
v position
phase
clock
exit
Xerox© LCD Monitor User's Manual
<up>to select
