Xerox WorkCentre 7346 Specifications

Xerox WorkCentre 7346 Specifications

Color multifunction printer
Hide thumbs Also See for WorkCentre 7346:

Advertisement

Quick Links

Download this manual
WorkCentre
Color Multifunction Printer
WorkCentre 7346
shown with High-Capacity
Tandem Tray and Professional Finisher options.
WorkCentre
Output Speed – Printing and Copying
Black and White
Up to 45 ppm 8.5 x 11 in. (A4/210 x 297 mm),
Up to 27 ppm 8.5 x 14 in. (216 x 356 mm),
Up to 22 ppm 11 x 17 in. (A3/297 x 420 mm)
Color
Up to 40 ppm 8.5 x 11 in. (A4/210 x 297 mm),
Up to 24 ppm 8.5 x 14 in. (216 x 356 mm),
Up to 20 ppm 11 x 17 in. (A3/297 x 420 mm)
Print Specifications
System
Memory
1.5 GB
System Disk
Minimum 40 GB
Network Printing – Network Controller
Processor
667 MHz
Printer Languages
Adobe Postscript
(auto sensing/
TIFF
switching)
PCL5c
PDF 1.5
PCL 6
HP-GL2™
XPS
Network Printing – Resolution
Print Engine: 1200 x 1200 dpi
7346
®
7346
®
3
®
®
Detailed Specifications
1

Advertisement

loading

Related Manuals for Xerox WorkCentre 7346

Summary of Contents for Xerox WorkCentre 7346

  • Page 1 WorkCentre ® Color Multifunction Printer WorkCentre 7346 shown with High-Capacity Tandem Tray and Professional Finisher options. WorkCentre ® Output Speed – Printing and Copying Black and White Up to 45 ppm 8.5 x 11 in. (A4/210 x 297 mm), Up to 27 ppm 8.5 x 14 in. (216 x 356 mm), Up to 22 ppm 11 x 17 in.
  • Page 2 Network Printing – Printing features Print Calibration Secure print Delay print (specific time) Sample set Booklet creation Cover selection Paper selection by attribute N-up Saddle-stitch booklet making (requires Professional Finisher) Hole Punch (requires Professional Finisher or Advanced Office Finisher) Booklet Fold / V Folding (requires Professional Finisher) Watermark Fit to new paper size Transparency Separators...
  • Page 3 ® ® • Provides the ability to see the current status of discovered Xerox printers/devices under a Xerox PrinterMap and IP Map via color-coded icons • Provides traps and message updates to the OpenView alarm browser and the ability to launch CentreWare Internet...
  • Page 4 Provides built-in process intelligence that allows the printing of barcodes on any appropriately configured PostScript Intelligent Barcode printer on the SAP R/3 4.x (or higher) network. Used in conjunction with Xerox Device Types for SAP R/3 Environment Utility (Optional) and Xerox Font Center Barcode Fonts. Utility automatically calculates checksum, placement of start/stop characters, and...
  • Page 5 • ScanSoft PaperPort (for desktop/client installation) – image viewing and file management software • ScanSoft OmniPage (for desktop/client installation) – OCR and file format conversion software • Image Retriever – provides fully automated retrieval of scanned images direct from a scan enabled Xerox WorkCentre to individual desktops.
  • Page 6 • ScanSoft OmniPage Pro (for desktop/client installation) – OCR and file format conversion software • Image Retriever – provides fully automated retrieval of scanned images direct from a scan enabled Xerox WorkCentre to individual desktops. Also includes an Email inbox polling capability.
  • Page 7 Fax Send Features Fax from print driver Auto fax transmission reduction Page-by-page job status at the machine Fax from platen Delay start Automatic memory resend Automatic cover sheets Priority send Broadcast up to 200 recipients Booklet Scan PSTN Fax Internet Fax LAN Fax Fax Receive Features One- or two-sided printing Reduction at reception to fit available paper...
  • Page 8 Copy Specifications First-Image-Out Time – letter size, from platen to center tray Black and White As fast as 4.8 Seconds Color As fast as 6.7 Seconds Copying Document Scanner Duplex Automatic Document Feeder with 75-sheet capacity (based on 80 gsm paper) Sides (input:output) 1:1, 1:2, 2:2 and 2:1 Quantity...
  • Page 9 ID Card Copy Foreign Device Interface to third-party access control devices, coin machines and card readers Interface Supports a variety of vending stations available through the Xerox Custom Application Service Device Specifications Paper Handling – Duplex Automatic Document Feeder Capacity...
  • Page 10 WorkCentre 7346 Types Plain Paper Recycled Bond Custom Type 1 through 5 Lightweight Heavyweight Extra Heavyweight Transparency Heavyweight Gloss Labels Gloss Extra Heavyweight Gloss Punched Letterhead Pre-printed Envelopes Paper Handling – Input Tray Options - Three Tray Option (Tray One and Two plus Two Tray Module)
  • Page 11 WorkCentre 7346 Types Plain Paper Recycled Bond Custom Type 1 through 5 Lightweight Heavyweight Extra Heavyweight Transparency Heavyweight Gloss Labels Gloss Extra Heavyweight Gloss Punched Letterhead Pre-printed Envelopes Total Capacity* 3,140 sheets (Includes Tray 1, Tray 2, Bypass Tray and High Capacity Feeder) Output –...
  • Page 12 WorkCentre 7346 Output – Professional Finisher Option Top Tray 500 sheets Stacking Stapling 1,500 sheets Tray Sizes 8 x 10 in./B5 to 11 x 17 in./A3 Weights 17 to 110 lb index/60 to 220 gsm Stapling Single Auto stapling (50 sheets maximum) – 24 lb/90 gsm...
  • Page 13 Xerox Extensible Interface Platform™ (EIP) Xerox Extensible Interface Platform (EIP) is an embedded software platform built with state of the art web technologies. This platform provides the means for software developers to quickly build solutions that are more intuitive and user- friendly for the office workers.
  • Page 14 © 2010 Xerox Corporation. All rights reserved. XEROX ® , CentreWare trademarks of or licensed to Xerox Corporation. In support of Xerox environmental leadership goals, these models may contain some recycled components that are reconditioned. XPS is a registered owner of Microsoft Corporation. Adobe, PostScript ®...
