What does this warranty cover and how long does it last? Warranty This Limited Warranty is provided by Xantrex Technology, Inc. (“Xantrex”) and covers defects in workmanship and materials in your XDC 6000 Watt Series Slave Power Supply. This warranty lasts for a Warranty Period of 5 years from the date of purchase at point of sale to you, the original end user customer.
Page 5
TM-XDSL-01XN.book Page iii Tuesday, November 5, 2002 3:22 PM Direct returns may be performed according to the Xantrex Return Material Authorization Policy described in your front panel controlled XDC product manual. For some products, Xantrex maintains a network of regional Authorized Service Centers.
Page 6
TM-XDSL-01XN.book Page iv Tuesday, November 5, 2002 3:22 PM Disclaimer Product THIS LIMITED WARRANTY IS THE SOLE AND EXCLUSIVE WARRANTY PROVIDED BY XANTREX IN CONNECTION WITH YOUR XANTREX PRODUCT AND IS, WHERE PERMITTED BY LAW, IN LIEU OF ALL OTHER WARRANTIES, CONDITIONS,...
Page 7
TM-XDSL-01XN.book Page v Tuesday, November 5, 2002 3:22 PM Information WITHOUT LIMITING THE GENERALITY OF THE FOREGOING, UNLESS SPECIFICALLY AGREED TO BY IT IN WRITING, XANTREX a. MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY TECHNICAL OR OTHER INFORMATION PROVIDED IN MANUALS OR OTHER DOCUMENTATION PROVIDED BY IT IN CONNECTION WITH THE PRODUCT;...
Page 8
TM-XDSL-01XN.book Page vi Tuesday, November 5, 2002 3:22 PM Warnings Warnings and cautions are defined and formatted in this manual as shown below. Cautions WARNING Describes a potential hazard which could result in injury or death, or, a procedure which, if not performed correctly, could result in injury or death.
Page 9
TM-XDSL-01XN.book Page vii Tuesday, November 5, 2002 3:22 PM Approvals CE Mark CE-marked units meet the following standards: • IEC 1010-1-92 including Amendments 1 and 2: • Overvoltage Category II • Permanently Connected Equipment • Pollution Degree 2 • EN50081-2-1996 Electromagnetic Generic Emission - Industrial Equivalent •...
Page 10
TM-XDSL-01XN.book Page viii Tuesday, November 5, 2002 3:22 PM Operating Manual for XDC Series Slave Power Supply viii...
TM-XDSL-01XN.book Page ix Tuesday, November 5, 2002 3:22 PM About This Manual This Operating Manual contains operating instructions for the XDC Series Slave power supplies. This power supply is based on the XDC Series of digital, programmable power supplies, with the same high level of accuracy and reliability, but specifically designed with no front panel interface for use as a slave unit controlled via CANbus (Control Area Network bus).
Page 12
TM-XDSL-01XN.book Page x Tuesday, November 5, 2002 3:22 PM About This Manual Operating Manual for XDC Series Slave Power Supply...
TM-XDSL-01XN.book Page 13 Tuesday, November 5, 2002 3:22 PM Section 1. Overview The XDC series Slave power supply is designed for use in current sharing systems as a slave module connected in parallel with an XDC 6000 Watt series full digital controlled front panel unit.
TM-XDSL-01XN.book Page 14 Tuesday, November 5, 2002 3:22 PM Overview Front Panel Front Panel Figure 1.1 Slave Front Panel 1. Rack mount brackets 2. Handles 3. ON/OFF Switch 4. Power On status LED (green) 5. Ouput Off status LED (red) Lit when the output is disabled 6.
TM-XDSL-01XN.book Page 15 Tuesday, November 5, 2002 3:22 PM Section 2. AC Input Power WARNING Disconnect AC power from the unit before removing the connector cover. Live line voltages may be exposed when the cover is removed. WARNING A safety ground wire must be connected to the unit as shown in Figure 2.1 to ensure operator safety.
TM-XDSL-01XN.book Page 16 Tuesday, November 5, 2002 3:22 PM AC Input Power AC Input Connector AC Input Connector The AC input connector is a standard wire clamp terminal block with 3-phase connectors and a chassis ground connector. The safety ground wire, alternatively, may be connected to the chassis using a ring tongue on the ground stud as shown in Figure 2.1.
TM-XDSL-01XN.book Page 17 Tuesday, November 5, 2002 3:22 PM AC Wire Input Connection See Figure 2.2, on page 18. To connect the AC input wires: 1. Ensure that the AC input cord is de-energized, and that the power switch on the front of the power supply is OFF.
Page 20
TM-XDSL-01XN.book Page 18 Tuesday, November 5, 2002 3:22 PM AC Input Power AC Wire Input Connection Figure 2.2 Attaching the AC Input Wires Operating Manual for XDC Series Slave Power Supply...
TM-XDSL-01XN.book Page 19 Tuesday, November 5, 2002 3:22 PM Section 3. Current Sharing Overview Power supplies equipped with the CANbus interface will allow current sharing between units connected in parallel. Current sharing can use a maximum of 5 supplies, including the master. All power supplies must be the same model. Every unit must have a unique address, if they do not then they will automatically readdress themselves.The slave units are shipped with the current share feature already...
TM-XDSL-01XN.book Page 20 Tuesday, November 5, 2002 3:22 PM Current Sharing Overview CANbus The CANbus port is a one male, one female DB9 connector to support “daisy chain” Setup connections. The CAN (Controller Area Network) is an ISO standard (ISO11898) for a serial communication network.
TM-XDSL-01XN.book Page 21 Tuesday, November 5, 2002 3:22 PM Current Share Units are programmed in a mode such that it is already in current sharing mode on Configuration power up. This feature is not user-modifiable. Please contact the manufacturer for assistance if you wish to change this.
TM-XDSL-01XN.book Page 22 Tuesday, November 5, 2002 3:22 PM Current Sharing Operation Operation There can only be one master unit and 4 slave units current sharing. All other units will not current share. Units must have the same output ratings or they will not current share.
TM-XDSL-01XN.book Page 23 Tuesday, November 5, 2002 3:22 PM Appendix A. Specifications and Characteristics Notes • These specifications are represented over the full operating temperature range. • Nominal line input voltage assumed unless otherwise stated. • All sense lines are configured for default local operation.
TM-XDSL-01XN.book Page 24 Tuesday, November 5, 2002 3:22 PM Specifications and Characteristics Electrical Specifications—Summary Electrical Specifications—Summary Table A.1Specifications for 10V to 60V Models Models Output Ratings: Output Voltage Output Current Output Power Line Regulation: Voltage (0.01% of Vmax) Current (0.05% of Imax) Load Regulation: Voltage (0.05% of Vmax + 5 mV)
Page 27
TM-XDSL-01XN.book Page 25 Tuesday, November 5, 2002 3:22 PM Table A.3Specifications for 80V to 600V Models Models Output Ratings: Output Voltage Output Current Output Power Line Regulation: Voltage (0.01% of Vmax) Current (0.05% of Imax) Load Regulation: Voltage (0.05% of Vmax + 5 mV) Current (0.1% of Imax + 20 mA)
TM-XDSL-01XN.book Page 26 Tuesday, November 5, 2002 3:22 PM Specifications and Characteristics AC Line Input Specifications AC Line Input Specifications The input to the power supply requires the following specifications. AC Line Input Voltage Operating Ranges Table A.5AC Line Input Specifications...
TM-XDSL-01XN.book Page 27 Tuesday, November 5, 2002 3:22 PM Output Performance Specifications These specifications define the electrical performance specifications of the power supply output. These specifications apply to both local and remote sense configurations, except where noted. These specifications apply to all programming sources, except where noted.
Page 30
TM-XDSL-01XN.book Page 28 Tuesday, November 5, 2002 3:22 PM Specifications and Characteristics Output Performance Specifications Typical Programming Resolution Remote Digital Interface Voltage Current Power Over Voltage Protection Typical Measurement Resolution Remote Digital Interface Voltage Current Power Programming Accuracy Remote Digital Interface...
Page 31
TM-XDSL-01XN.book Page 29 Tuesday, November 5, 2002 3:22 PM 8 Hour Drift Temperature Stability Voltage Current Power Temperature Coefficients Remote Digital Interface Voltage Programming Current Programming Power Programming Voltage Readback Current Readback Power Readback Switching Frequency Typical 31 kHz; 62 kHz output ripple Rise Time 5 to 95% step in output voltage.
Page 32
TM-XDSL-01XN.book Page 30 Tuesday, November 5, 2002 3:22 PM Specifications and Characteristics Output Performance Specifications Time Delay From Output Enable Until Output Stable 2 s maximum (Within regulation envelope) Output Hold-Up Time – Power Off Minimum 4 ms (at full load) Output Hold-Up Time –...
TM-XDSL-01XN.book Page 32 Tuesday, November 5, 2002 3:22 PM Specifications and Characteristics Mechanical Specification Mechanical Specification Weight Approx. 75 lb. (34 kg) for 10 V-600 A unit, without packaging Size Figure A.1 Power Supply Dimensions Operating Manual for XDC Series Slave Power Supply...
Page 36
TM-XDSL-01XN.book Page 34 Tuesday, November 5, 2002 3:22 PM Xantrex Technology Inc. 8999 Nelson Way Burnaby, British Columbia Canada V5A 4B5 604 422 2777 Tel 604 420 2145 Fax 800 670 0707 Toll Free North America customerservice@xantrex.com www.xantrex.com TM-XDSL-01XN PRINTED IN CANADA...
