- Page 1 Xantrex Automatic Generator Start Control System Owner's Manual...
-
Page 2: Table Of Contents
Xantrex is a registered trademark of Xantrex International. Disclaimer UNLESS SPECIFICALLY AGREED TO IN WRITING, XANTREX TECHNOLOGY INC. (“XANTREX”) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER DOCUMENTATION. -
Page 3: Introduction
You can also set allowable generator run times, so that the AGS does not turn on the generator at inconvenient times. SAFETY SUMMARY General safety information for installation and operation is contained throughout this manual where it applies and is not completely included in this summary. -
Page 4: Things You Should Know
The Automatic Generator Start Control System (AGS) has the following features: Starts the generator automatically in response to a low battery. The AGS continuously monitors the house battery and will start the generator automatically if the battery is low. Starts the generator automatically in response to air condi- tioning/heating requests. -
Page 5: Theory Of Operation
1. If the generator is started by the AGS, which is in AUTO or AUTO QUIET TIME mode, the selection of OFF at the AGS Remote Panel will stop the auxiliary generator. -
Page 6: Operation
DEFAULT: Light OFF GEN FAULT Light The generator has failed to start or has stopped during AGS control. This will happen if the generator is manually stopped by a generator start/stop switch that is independent of the AGS. Cy- cling the ON/OFF switch will clear the fault. -
Page 7: Set Time Switch
Use the SET TIME switch to select the time in hours Quiet Time is to end. SELECT changes the time displayed by the AGS Remote and is used to set the TIME/ HOUR. In LOCAL TIME mode the user can set the “Time/Hour” display to the local hour. (Min- utes are preset at the factory and do not require user adjustment). -
Page 8: Installation
Control Module. The Remote Panel comes on automatically when power is applied to the AGS Control Module. The AGS Remote Panel measures 5.75'' (W) X 3.75'' (H) X 0.65'' (D). Use the supplied template to cut the proper size hole. Mount the Remote Panel unit using the screws supplied. - Page 9 #18 AWG wire should be used. The in-line connector for the Controller has the following DC connections. DESCRIPTION START: Generator start signal contact. STOP: Generator stop signal contact. GENERATOR DC HOUR METER. RESERVED (Future ignition lock-out). POWER POSITIVE: Connect to house battery positive. 2-amp fuse required.
-
Page 10: Installation Diagram
INSTALLATION DIAGRAM INSTALLATION NOTE: It is advised to interlock the AGS system so that the AGS unit is turned off when the coach is in motion. This may be done by removing power from the AGS Controller. To accomplish this the AGS Controller... -
Page 11: Ags Remote Panel
AGS REMOTE PANEL AGS CONTROLLER DATA CABLE 4 CONDUCTOR SUPPLIED... -
Page 12: Common Questions
The Low Battery set point is around 11.5 VDC. The battery voltage must stay at or below 11.5 volts for approximately 15 seconds before the AGS will start the generator. PARAMETER VALUES Low battery voltage set point... -
Page 13: Troubleshooting
SOLUTION Check data cable connected to AGS Remote Panel and AGS Control Module. Check for 12 VDC at AGS Controller (wires #5 and #13). Verify that the Generator Hour Meter Signal (wire #3) is connected to the AGS Control Module. -
Page 14: Glossary
AGS Controller The part of the AGS Control System that connects to the wiring of the coach. It contains a micro-controller and a real-time clock. AGS Remote Panel The user interface part of the Automatic Generator Start Control System. -
Page 15: Limited Warranty
What does this warranty cover? This Limited Warranty is provided by Xantrex Technology, Inc. (“Xantrex”) and covers defects in workmanship and materials in the Automatic Generator Start Control System. This warranty lasts for a Warranty Period of 12 months from the date of purchase at point of sale to you, the original end user customer. -
Page 16: Limited Warranty
LIMITED WARRANTY What does this warranty not cover? This Limited Warranty does not cover normal wear and tear of the product or costs related to the removal, installation, or troubleshooting of the customer’s electrical systems. This warranty does not apply to and Xantrex will not be responsible for any defect in or damage the product if it has been misused, neglected, improperly installed, physically damaged or altered, either internally or externally, or damaged from improper use or use in an unsuitable environment;... -
Page 17: Return Material Authorization Policy
Please refer to your product user manual for limitations on uses of the product. Specifically, please note that the Automatic Generator Start Control System (AGS) is not intended for use in connection with life support systems, and Xantrex makes no warranty or representation in connection with any use of the product for such purposes. -
Page 18: Return Procedure
This warranty will not apply where the product is damaged due to improper packaging. Include the following: The RMA number supplied by Xantrex Technology Inc clearly marked on the outside • of the box. A return address where the unit can be shipped. Post office boxes are not •... -
Page 19: Specifications
INSTALLATION Mating Connector ... AMP 770583-1 Mating Pins (16) ... AMP 770988-1 Crimping Tool ... AMP 90759-1 The Xantrex AGS Harness (P/N 76-0090-01) includes these three items. MECHANICAL Controller Size: 6.57'' (W) X 4.25'' (H) X 1.875'' (D) Remote Panel Size: 5.75'' (W) X 3.75'' (H) X 0.93'' (D) Remote Panel Cutout size: 4.875'' (W) X 2.875'' (H) - Page 20 Xantrex Technology Inc. Toll free 1 800 670 0707 Direct 1 604 422 2777 Fax 1 604 420 2145 CustomerService@xantrex.com www.xantrex.com 445-0190-01-01 Rev. 1 Printed in the U.S.A.
