Techni Mobili RTA-0097M Assembly Instructions

PARTS LIST
ATTENTION: Before you begin to assemble the
product, please make sure that all the parts are
included in the package and in good condition.
Backrest Covers for
A H
Gas Lift (Set)
x1 x1
B Seat
I Backrest support
with plastic covers
x1 x1
J Lock Pin Set
C Star Base
x1
x1
(Mechanism)
Mechanism
D K Spring Knob
x1 x1
E Screws 6x16mm
Hydraulic L
Gas Lift
x1
x4
(Mechanism)
M
Screws 6x25mm
x10
F Casters
x5
(Backrest, Armrests)
N
Allen wrench
x1
G Armrest
x2
O
Screw 10mm
x4
(Backrest covers)
ASSEMBLY INSTRUCTIONS
CHAIR STYLE RTA-0097M
• Follow the instructions step by step.
ATTENTION:
• To avoid misalignments, leave the screws loose and do not tighten them until all are in their respective places.
• Do not overtighten or force the screws as they could break, strip, or damage the threads of the holes.
• Using the wrong size of screws on a part could result in damage to the screw or the part
1
Insert the casters (F) in the legs of the
base (C) using pressure, then place the
gas lift (E) in the middle of the base and
cover it with (H) as shown.
4
Disassemble the spring knob (K):
K1 K2 K3 K4 K5
Then insert its bolt (K1) thru the small hole
on the mechanism (D) from underneath as
shown, and re-assemble IN THE EXACT
ORDER SHOWN IN THE ILLUSTRATION.
WASHER
K5 ----
GOES
K
K4 ----
AFTER
D
K3 ----
SPRING!
WARNING:
K2 ----
DON'T PUT
WASHER
HERE!!!
---- K1
2
Assemble the support (I) to the backrest
(A) using screws (M) and attach the
covers using screws (O) as shown.
A
H
I
E
O
C
F
5
Assemble to the seat (B):
- The mechanism (D) using screws (L).
- The armrests (G) using screws (M).
M
A
D
G
D
L
3
Assemble the mechanism (D) to the
support (I) by inserting the lock pin set
(J) and bending the pin as shown.
M (x4)
J
6
Place the top parts over the base parts
making sure the tip of the gas lift enters
into the hole of the mechanism.
A
M
G
Before seating and using the chair for
the first time, make sure that all
B
screws are properly tightened.
A
I
D
