Worth Data LI50 Specifications

LI50 CCD Scanner Specifications
Model Description
LI50 CCD Scanner - Undecoded
Operational
Light Source 660 nm LED
Scan Speed 50 scans/sec Unidirectional
Scan Angle 4.7" (120mm) maximum scan width
Minimum Bar Width 4 mil
Print Contrast 0.90
Indicators (LED) Bi-Color LED
Special Operation Hands Free Stand Support (Optional Stand)
System Interface TTL - RJ45 Worth Data Decoder Interface
Decoder Compatibility P22, R22, T54, T701, T802
Physical
Height 5.9" (150mm)
Depth 4.6" (117mm)
Width 2.6" (66mm)
Weight 6 oz - 170g
Cable C39 Coiled Cord 2'-5' (610mm-1525mm)
Power
Input Voltage 5VDC ± 10%
Power (nominal) Undecoded: <1mA Idle, 190mA scanning
EMC FCC part 15 class A
EN 55024, 61000-3-2, 61000-3-3 CE Compliant
Environmental
Operating Temperature 14ºF to 122ºF (0ºC to 50ºC)
Storage Temperature -4ºF to 140ºF (-20ºC to 60ºC)
Humidity 5% to 95% non-condensing
Shock 6' drop to concrete
Warranty 2 Years - Parts & Labor
Scan Range for LI50 Long Range CCD Scanner
0"
4"
2"
6 mil narrow bar width
Worth Data Inc. USA Worth Data Inc. Europe
623 Swift St. 21-23 Fenian Street
Santa Cruz, CA 95060 Dublin 2, Ireland
tel. 800-345-4220 tel. 353 1 6614 566
fax. 831-458-9964 fax. 353 1 6614 622
10"
20"
7"
12"
10 mil narrow bar width
http://www.barcodehq.com
email. wds@barcodehq.com
Interface
Decoder Required P22, R22, T54, T701, T802
"
5.9
The LI50 CCD requires one of the
following decoders:
P22 USB/ R22 RS-232
Keyboard Decoder Serial Decoder
30"
40 mil narrow bar width
2.6"
4.6"
T54 T701 T802
TriCoder RF Terminal RF Terminal
40"
MADE IN TAIWAN
