Worksaver T25-42 Specification Sheet

ROTARY TILLERS
T 25 SERIES
MODEL T25-42
HP Rating 25 Max.
HP Req. Range 15 – 18 hp
Working Width 42 in.
Working Depth 5 in. max.
PTO Driveline Shear-bolt
Driveline Options
Oil Bath
Drive
Oversized
Chain
Depth Adjust. Skid Shoes
Hitch – 3 pt. Cat. 0
11 ½" Total
Gearbox and
Offset
hitch move as
one unit
No. of Blades
Type Curved
Parking Stand
Shipping Weight 283 lb.
Stock No. 320200
Information Provided by:
15 to 55 PTO HP
Turn hard ground into a perfect seed bed
quickly and easily using the economical
Worksaver rotary tiller.
landscaping, orchards, or any soil operation.
Each model is designed rugged and built t o
last many years. All models feature curved or
"L" blades, oil-bathed over-sized chain drive,
depth adjustment on skids, and adjustable
lower hitch points. A rear deflector keeps soil
and debris beneath the tiller for through
pulverization. Gearbox is protected by either
a shear-bolt or slip clutch PTO driveline.
T25-50
25 Max.
18 – 22 hp
50 in.
5 in. max.
Shear-bolt
- -
Oil Bath
Oversized
Chain
Skid Shoes
Cat. 0
11 ½" Total
Gearbox and
hitch move as
one unit
20 24
Curved
- -
308 lb.
320205
T 55 SERIES
T40-58 T40-66
40 Max. 40 Max.
32 – 38 hp 35 – 40 hp
58 in. 66 in.
6 in. max. 6 in. max.
Shear-bolt Shear-bolt
Slip-Clutch Slip-Clutch
Oil Bath Oil Bath
Oversized Oversized
Chain Chain
Skid Shoes Skid Shoes
Cat. I Cat. I
7 ½" from 7 ½" from
center left or center left or
right right
28 32
"L" Shaped "L" Shaped
Optional Optional
478 lb. 525 lb.
320215 320220
Ideal for gardening,
T55-74
55 Max.
45 – 55 hp
74 in.
7 in. max.
Slip-Clutch
-
Oil Bath
Oversized
Chain
Skid Shoes
Cat. I
7 ½" from
center left or
right
36
"L" Shaped
Optional
790 lb.
320230
