01-10146-00
BEFORE BEGINNING
• Please read all instructions carefully.
• Familiarize yourself with all parts (see "PARTS INCLUDED WITH KIT") and check quantities.
• Follow all safety precautions (see "SAFETY PRECAUTIONS").
• Follow all manufacturer installation requirements in order to comply with the
advertised weight load specifications.
© 2020 ClosetMaid LLC | Ocala, FL 34471 | 1-800-874-0008 | www.closetmaid.com
INSTALLATION INSTRUCTIONS
Primary Configuration
6 FT - 10 FT ADJUSTABLE GARAGE ORGANIZER
What you will need:
4380 & 34380
Primary Configuration Kit Capacity
Whichever load reaches
capacity first:
Maximum Shelving Load*: 100 lbs/ft
Maximum 40 in. Hang Track Load*: 700 lbs
Maximum System Load*: 1,400 lbs
(See pages 6)
*Static Load Evenly Distributed. Must be installed per manufacturer's
specifications or weight load capacity does not apply.
11/19
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ClosetMaid Maxload 4380
Summary of Contents for ClosetMaid Maxload 4380
- Page 1 • Familiarize yourself with all parts (see “PARTS INCLUDED WITH KIT”) and check quantities. • Follow all safety precautions (see “SAFETY PRECAUTIONS”). • Follow all manufacturer installation requirements in order to comply with the advertised weight load specifications. © 2020 ClosetMaid LLC | Ocala, FL 34471 | 1-800-874-0008 | www.closetmaid.com...
- Page 2 72 in. (2) 43719 Screw 3/ 16 in. (45) Toggle Bolt 3/ 16 in. (45) Panhead Screw #12 x 2 in. (45) Anchor 1/4 in. (45) End Cap (48) 90813 © 2020 ClosetMaid LLC | Ocala, FL 34471 | 1-800-874-0008 | www.closetmaid.com...
-
Page 3: Safety Precautions
Consumer Affairs at 1-800-874-0008. Manufacturer Warranty Manufacturer will replace any missing or damaged part due to manufacturer defect for one year after purchase. Please have proof of purchase for warranty claims. © 2020 ClosetMaid LLC | Ocala, FL 34471 | 1-800-874-0008 | www.closetmaid.com... - Page 4 If the wall height is shorter than 99 in., the standards may require cutting. PLEASE NOTE: Any alteration of components voids any advertised performance specifications listed in this manual. © 2020 ClosetMaid LLC | Ocala, FL 34471 | 1-800-874-0008 | www.closetmaid.com...
-
Page 5: Configuration Examples
If your space is less than 80 in. or 120 in. wide, cutting Hang Track to fit space may be required. See Hang Track Location Diagrams for guidelines depending on your closet width. © 2020 ClosetMaid LLC | Ocala, FL 34471 | 1-800-874-0008 | www.closetmaid.com... -
Page 6: Primary Configuration
PARTS NEEDED FOR PRIMARY CONFIGURATION * Installation hardware varies based on wall type © 2020 ClosetMaid LLC | Ocala, FL 34471 | 1-800-874-0008 | www.closetmaid.com... - Page 7 Hit studs in at least 5 holes. STUD STUD STUD STUD STUD Use a toggle bolt on each hole that does not hit a stud. TOGGLE TOGGLE TOGGLE TOGGLE TOGGLE © 2020 ClosetMaid LLC | Ocala, FL 34471 | 1-800-874-0008 | www.closetmaid.com...
- Page 8 D) For Configurations 1 and 2, the minimum hang track installed height is 99 in. from the top of your baseboard. 99 in. © 2020 ClosetMaid LLC | Ocala, FL 34471 | 1-800-874-0008 | www.closetmaid.com...
- Page 9 This will enhance the security of the hang track mounting. IMPORTANT: SECURE HARDWARE THROUGH EACH HOLE! DRYWALL = TOGGLE BOLT DRILL 1/2 IN. HOLES. STUD = SCREW © 2020 ClosetMaid LLC | Ocala, FL 34471 | 1-800-874-0008 | www.closetmaid.com...
- Page 10 B) Insert anchors into 1/4 in. predrilled holes and secure hang track with panhead screws. IMPORTANT: SECURE HARDWARE THROUGH EACH HOLE! SCREWS AND ANCHORS ONLY DRILL 1/4 IN. HOLES. © 2020 ClosetMaid LLC | Ocala, FL 34471 | 1-800-874-0008 | www.closetmaid.com...
- Page 11 16 in. 13 in. 13 in. 7 in. 16 in. 16 in. 8 in. 2 in. 7 in. 16 in. 16 in. 16 in. 16 in. 8 in. © 2020 ClosetMaid LLC | Ocala, FL 34471 | 1-800-874-0008 | www.closetmaid.com...
- Page 12 DRILL 1/4 in. HOLES B) Attach standards by using standard extenders. Slide the standard extenders into the slots as shown. Mark holes for drilling while making sure the standards are level. © 2020 ClosetMaid LLC | Ocala, FL 34471 | 1-800-874-0008 | www.closetmaid.com...
-
Page 13: Install Brackets
INSTALL BRACKETS Attach a bracket to each standard where you expect to place a shelf. © 2020 ClosetMaid LLC | Ocala, FL 34471 | 1-800-874-0008 | www.closetmaid.com... - Page 14 Place shelf on brackets. Allow an equal overhang (from brackets) on both sides. Measure amount to be cut. Remove shelf and cut with hacksaw or bolt cutter. Do not make cuts where vertical spacers are on front lip of shelf. Never allow more than a 6 in. overhang. 6 in. © 2020 ClosetMaid LLC | Ocala, FL 34471 | 1-800-874-0008 | www.closetmaid.com...
-
Page 15: Install Shelves
1) Pull shelf forward and allow front to “drop” over nose of brackets (nose of each bracket will fit between wires). 2) Push shelf backwards so back wire fits into bracket slots. 3) Firmly pull shelf forward at each bracket location to lock shelf into place. © 2020 ClosetMaid LLC | Ocala, FL 34471 | 1-800-874-0008 | www.closetmaid.com...
