Wolf ARS108 Specification Sheet

Model ARS96
shown with compressor on left (optional)
UL Listed.
UL Sanitation Approved to NSF 7.
Approved by ______________________
Date: _____________________________
F-39277 (9/05)
ACHIEVER COLD REFRIGERATED BASES
SELF-CONTAINED SERIES (ARS)
R
Item #_____________ C.S.I. Section 11420
BASIC MODEL:
ARS36 36" wide self-contained base
ARS48 48" wide self-contained base
ARS60 60" wide self-contained base
ARS72 72" wide self-contained base
ARS84 84" wide self-contained base
ARS96 96" wide self-contained base
ARS108 108" wide self-contained base
KEY FEATURES:
Stainless steel base, top, front, sides & interior.
25" unit height.
6" capacity on all drawers.
Compressor on right.
4" heavy-duty casters.
Galvanized back.
New adjustable caster channel.
Magnetic drawer gaskets.
Self-contained models provided with an electric conden-
sate evaporator.
OPTIONAL FEATURES:
6" adjustable legs.
Compressor on left.
Curb mount.
DESCRIPTION:
Wolf Model No. _____. Base exterior front, sides and interior
are 20 gauge stainless steel. Back is 20 gauge #304 and bot-
tom is 18 gauge galvanized metal. Interior has coved corners.
4" casters are provided along with a 2" dial thermometer.
2 1 / " thick foamed-in-place polyurethane. Self-contained R404a
4
or R134a hermetic condensing unit is provided for refrigerated
base. All 115V single phase ARS-48 are equipped with 15 amp
cord and plug. All 115V single phase ARS-60, 72, 84, 96
and 108 are provided with 20 amp cord and plug. All hookups
at right rear. Models provided with an electric condensate
evaporator.
Wolf Range Company
Division of ITW Food Equipment Group LLC
(800) 366-9653
www.wolfrange.com
