Wolf WSPR1 Features

Model WSPR2F
CSA design certified. NSF listed.
Approved by _______________________
Date: _____________________________
SPECIFY TYPE OF GAS WHEN ORDERING.
SPECIFY ALTITUDE WHEN ABOVE 2,000 FT.
F-39065 (04-07)
Item #_____________ C.S.I. Section 11420
MODEL: WSPR
STOCKPOT RANGES
BASIC MODELS:
WSPR1
WSPR2
WSPR2F
KEY FEATURES:
Stainless steel front and sides. Legs finished in black epoxy
➤
powdercoat paint.
Heavy cast iron top grate(s).
➤
Two concentric 55,000 BTU/hr ring-type burners per 18"
➤
section; 110,000 BTU/hr input per section.
Standing pilot ignition system.
➤
Two infinite heat control valves per section.
➤
Heat shield to protect control valves.
➤
3/4" rear gas connection and gas pressure regulator per
➤
section (only one for WSPR2F).
One year limited parts and labor warranty.
➤
OPTIONAL FEATURES:
Stainless steel legs.
➤
INSTALLATION REQUIREMENTS:
1. A gas pressure regulator sized for this unit was included.
Natural Gas 5" W.C., Propane Gas 10" W.C.
2. Gas line connecting to appliance must be 3/4" diameter or
larger. If flexible connectors are used, the inside diameter
must be the same as the 3/4" pipe.
3. An adequate ventilation system is required for commercial
cooking equipment. Information may be obtained by writing
to the National Fire Protection Association, 1 Batterymarch
Park, Quincy, MA 02169, www.NFPA.org. When writing refer
to NFPA No. 96.
4. These units are manufactured for installation in accor-
dance with National Fuel Gas Code, ANSI-Z223.1/NFPA
#54 (latest edition). Copies may be obtained from The
American Gas Association, Accredited Standards Com-
mittee Z223 @ 400N. Capital St. NW, Washington, DC
20001, or the Secretary Standards Council, NFPA, 1 Bat-
terymarch Park, Quincy, MA 02169-7471.
NOTE: In the Commonwealth of Massachusetts
All gas appliances vented through a ventilation hood or
exhaust system equipped with a damper or with a power
means of exhaust shall comply with 248 CMR.
5. Clearances:
Combustible
Rear
Sides
Wolf Range Company
Division of ITW Food Equipment Group LLC
(800) 366-9653
www.wolfrange.com
One section, 18" wide x 24.5" deep
Two sections, 36" wide x 24.5" deep
Two sections, 18" wide x 49" deep
Non-Combustible
24" 4"
18" 0"
