User's Manual
Arctus Fenja 10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fenja 10 and is the answer not in the manual?

Questions and answers

Related Manuals for Arctus Fenja 10

Summary of Contents for Arctus Fenja 10

  • Page 1 User's Manual Arctus Fenja 10...

  • Page 2: Important Safeguards

    Index  Important Safe Guards  Ambient Environment For Operating  Components Diagrams  Operating Introduction  Functions of Control Panel & Key Pads  Operation of Key Pads  Automatic Defrosting  Water Full  Processions Of Abnormal Compressor ...
  • Page 3 ！ Do not install and use the unit before carefully reading this instruction guide. Please retain this manual for product warranty and future reference. 1）Please be sure your electricity is correct 2） To protect against electrical shock, do not place it in near window or in bathroom.

  • Page 4: Ambient Environment For Operating

    13）Switch off and unplug the unit, empty the water reservoir when not using the unit for a long time. 14）Do not pull power wire by force because it will cause damage to power wire. 15）Never put fingers or other objects in any openings of the unit.

  • Page 5: Components Diagrams

    Components Diagrams Air deflector Control panel...

  • Page 6: Operating Introduction

    Operating Introduction  Functions of Control Panel & Key Pads 1. POWER: Switch on/off the power. 2. Press “HUMID” to select the desired RH, like 40%RH, 60%RH, 80%RH or continuous mode. 3. Press “Speed” to select the fan running at low or high speed . 4.
  • Page 7 1）Press “HUMID” once, the 40%RH is selected. Press “HUMID” for the 2 time, the 60%RH is selected. Press “HUMID” for the 3rd time, the 80%RH is selected. Press “HUMID” for the 4th time, the continuous mode is selected. The circle is repeated like this…… 2 ）...
  • Page 8  Automatic Defrosting A working cycle: When the appliance work in low temperature, frost will be produced on the surface of evaporator. To ensure the appliance performs well, the automatic defrost function is designed with the appliance. 1）When room temperature dropped down to 16℃ or lower, which detected by temperature sensor to generate compressor works 25 minutes on dehumidifying then cut off, fan blower keeps running 7 minutes to defrost in a cycle.

  • Page 9: Failures Of Humidity & Temperature Sensor

    ！ 1. All function keys are out of functions, you should plug off to restart the unit. 2. After the protection mode of extremely low & high temperature, the appliance will not keep its memory function when restart.  Failures Of Humidity & Temperature Sensor 1.

  • Page 11: Maintenance And Cleaning

    Maintenance & Cleaning ◆ For its casing is made of plastic, do not place it in direct sunlight. ◆ Remove the water tank with care. ◆ Only use a soft clean cloth for all cleaning purpose. Do not use gasoline, paint thinner or other chemicals to clean the unit.

  • Page 12: Specification

    Specification Model Arctus Fenja 10 Power Rated 220-240VAC/50Hz Moisture removal 10 L/D (30℃ RH80%) Dehumidifying Power 220W (30℃ RH80%) Max Power Dissipation 240W (35℃ RH90%) Dehumidifying Air Volume L:80m H:100 m Refrigerant R134a 125g Capacity of Water Tank 1.9L Unit Dimension:...
