- Page 1 MINI BRICK ARC USER’S MANUAL rel. 1.0 GB...
- Page 2 Le informazioni contenute in questo documento sono state attentamente redatte e controllate. Tuttavia non è assunta alcuna responsabilità per eventuali inesattezze. Tutti i diritti sono riservati e questo documento non può essere copiato, fotocopiato, riprodotto per intero o in parte senza previo consenso scritto della D.T.S . D.T.S.
-
Page 3: Table Of Contents
INDEX: 1- SYMBOLS ......................... 4 2- GENERAL WARNING ....................5 3- GENERAL WARRANTY CONDITIONS ..............5 4- TECHNICAL FEATURES ..................5 5- ACCESSORIES ......................6 6- IMPORTANT SAFETY INFORMATION ..............7 6.1 Fire prevention...................... 7 6.2 Prevention of electric shock .................. 7 6.3 Safety ........................ -
Page 4: 1- Symbols
1- SYMBOLS Graphic symbols used on this manual: THIS SYMBOL INDICATES A HOT SURFACE THIS SYMBOL INDICATES ELECTRIC SHOCK RISK THIS SYMBOL INDICATES GENERAL RISK THIS SYMBOL INDICATES THE MAXIMUM OPERATING AMBIENT TEMPERATURE THIS SYMBOL INDICATES THE MINIMUM DISTANCE FROM THE ILLUMINATED OBJECTS THIS SYMBOL MEANS “DO NOT STARE AT THE OPERATING LIGHT SOURCE”... -
Page 5: 4- Technical Features
4- TECHNICAL FEATURES DTS product codes: 03.LDB121E28FC08 MINI BRICK ARC FC UN lenses RAL 9006 ACC finishing 03.LDB121E28FC10 MINI BRICK ARC FC SP lenses RAL 9006 ACC finishing 03.LDB121E28FC25 MINI BRICK ARC FC MF lenses RAL 9006 ACC finishing 03.LDB121E28FC40... -
Page 6: 5- Accessories
DIMENSIONS 5- ACCESSORIES As standard 1 x M12 female IP67 cable connector (code 0520P050) 1 x User’s Manual Optional (on request) - Lenses set Ultra-Narrow 8° (code 03.LK.269.44) - Lenses set Narrow 12° (code 03.LK.270.44) - Lenses set Medium 28° (code 03.LK.271.44) - Lenses set Wide 38°... -
Page 7: 6- Important Safety Information
-High voltage is present inside the unit. Unplug the unit prior to performing any function which involves touching the inside of the projector. -The level of technology inherent in the MINI BRICK ARC requires the assistance of specialised personnel for all servicing. -
Page 8: 7- Installation
7- INSTALLATION The unit is suitable for wet locations. MINI BRICK ARC can be installed on a truss or on the ceiling. It is recommended the use of appropriate clamps to fix the unit to the mounting surface. The supporting structure from which the unit is hung should be capable of bearing the weight of the unit, as should any clamps used to hung it. -
Page 9: 8- Connections
8- CONNECTIONS LED INPUT 0,7 m cable with M12 male connector... -
Page 10: 9- Holographic Filter Installation
9- HOLOGRAPHIC FILTER INSTALLATION Attention: the holographic filter installation must be made by DTS personnel or experienced person. Wrong operations can damage the IP65 protection. 1 - Remove the front screen with the protection glass by loosing the 6 marked screws. -
Page 11: 10- Lenses Set Replacement
10- LENSES SET REPLACEMENT Attention: the lenses set replacement must be made by DTS personnel or experienced person. Wrong operations can damage the IP65 protection. 1 - Remove the front screen with the protection glass by loosing the 6 marked screws. -
Page 12: 11- Visor Installation
11- VISOR INSTALLATION The Visor for MINI BRICK ARC (code 03.LA.230.28) is available on demand. Fix the Visor on the MINI BRICK ARC by using the 4 marked screws previously removed from the unit body. Once installed, fix the safety cable on the side cap by using the marked screw and the... -
Page 13: 12- Connection Diagrams
12- CONNECTION DIAGRAMS The maximum number of MINI BRICK ARC connectable to each output of DRIVENET 28 EZ, 416, 832 or 1664 is 1 piece. The maximum distance between DRIVENET and the unit should not exceed 100 meters. DRIVENET 1664 (code 03.LA.198) - Page 14 NOTES...
- Page 15 NOTES...
- Page 16 ISO 9001:2015 DTS quality system is certified 9001:2015 standard 0517I338 D.T.S. Illuminazione s.r.l. ● Via Fagnano Selve 12- 47843 Misano Adriatico (RN) Italy ● Tel.: +39 0541 611131 Fax +39 0541 611111 info@dts-lighting.it www.dts-lighting.it Product and specifications subjects to change without notice.
